CHAPTER 12: ADVANCED ADMINISTRATION 187

more [-p <page_size>]

Make paging

pingdevice <[-id <device_id>] | [host]>

Ping device

restartcc minutes [message]

Restart CC-SG

restartdevice <[-id <device_id>] | [host]>

Restart device

restoredevice <[-host <host>] | [-id <device_id>]> [backup_id]

Restore device configuration

shutdowncc minutes [message]

Shutdown CC-SG.

ssh [-e <escape_char>] <[-id <device_id>] | [host]>

Open SSH connection to an SX device

su [-u <user_name>]

Change a user.

upgradedevice <[-id <device_id>] | [host]>

Upgrade device firmware

exit

Exit SSH session.

Typing the command followed by the

–h switch displays help for that command, such as

listfirmwares –h.

Command Tips

The following describes several nuances of the SSH commands:

• For commands that pass an IP address, such as upgradedevice, you can substitute the

hostname for an IP address. For hostname rules, please refer to

Terminology/Acronyms in

Chapter 1: Introduction.

• The copydevice and restartdevice commands apply only to some Raritan devices, for example,

Dominion SX. IPMI servers, generic devices are not supported by these commands.
