218 COMMANDCENTER SECURE GATEWAY ADMINISTRATOR GUIDE

Each CC-SG in the cluster may be on a separate LAN. However, the inter-connection between

the units should be very reliable and not prone to periods of congestion.

Communication Direction Port

Number

Protocol Configurable?

CC-SG → Local Broadcast 10000 UDP no

CC-SG → Remote LAN IP 10000 UDP no

CC-SG ↔ CC-SG 5432 TCP no

CC-SG ↔ CC-SG 8732 TCP

CC-SG ↔ CC-SG 3232 TCP

Access to Infrastructure Services

The CC-SG can be configured to use several industry-standard services like DHCP, DNS, and

NTP. In order for CC-SG to communicate with these optional servers, these ports and protocols

are used:

PC Clients to CC-SG

PC Clients connect to the CC-SG in one of these three modes:

• Web / Java Applet CC-SG GUI interface

• CC-SG Command Line Interface via SSH

• CC-SG Diagnostic Console

Communication Direction Port

Number

Protocol Configurable?

DHCP Server → CC-SG 68 UDP no

CC-SG → DHCP Server 67 UDP no

NTP Time Server ↔ CC-SG 123 UDP no

CC-SG → DNS 53 UDP no
