Table Of Contents

CommandCenter

Secure Gateway Release 5.1.0

Contents

Introduction ............................................................................................................................. 2

Applicability.............................................................................................................................. 2

Upgrade Path........................................................................................................................... 2

About Licensing ...................................................................................................................... 3

New Features and Updates in This Release................................................................. 5

Minor Features & Maintenance......................................................................................... 6

Security and Compliance Information........................................................................... 7

Updated Product Documentation..................................................................................... 7

General Notes.......................................................................................................................... 7

Limitations and Restrictions .............................................................................................. 8

(Note – numbers in parentheses throughout this document are reference numbers internal to Raritan.)

CC-SG 5.1.0 Release Notes Doc. #

255-80-0005-00 Page 1 of 9

Summary of content (9 pages)

PAGE 1
CommandCenter® Secure Gateway Release 5.1.0 Contents Introduction ............................................................................................................................. 2 Applicability .............................................................................................................................. 2 Upgrade Path........................................................................................................................... 2 About Licensing ...................
PAGE 2
Introduction These Release Notes contain important information regarding a new release of this product. Please read the entire document and the related documentation available for this release. Release 5.1.0 includes several enhancements and maintenance items. It also establishes a common release for both the Hardware Appliance and Virtual Appliance. Release 5.1.0 documentation and upgrade firmware is available at http://www.raritan.com/support/commandcenter-secure-gateway/.
PAGE 3
Hardware Appliance 3.1.1 3.0.2 3.1.0 3.2.0 4.0.0.5.5 5.0.0 5.1.0 5.0.0 5.1.0 5.0.0 5.1.0 5.0.0 5.1.0 5.0.0 5.1.0 3.2.1 Or 4.0.1.5.3 Or 4.1.0.5.10 Or 4.2.0.5.17 Or 4.3.0 Virtual Appliance 5.0.5 5.1.0 Please back up your CC-SG before and after any upgrade step. For detailed step by step instructions on upgrading, refer to the Readme file available with this CC-SG release. You may also need to upgrade your other Raritan devices.
PAGE 4
created and added to the base license. The created Add-On license is rounded up, based on the following license levels: CCL-64 CCL-128 CCL-256 CCL-512 CCL-1024 CCL-2048 CCL-4096 CCL-8192 64 node license 128 node license 256 node license 512 node license 1024 node license 2048 node license 4096 node license 8192 node license For example, if there are 400 nodes in the database, an add-on license for 512 nodes will be established – in addition to the 128 node base license.
PAGE 5
If direct access to devices is needed while the CC-SG is not in the fully operational state and the device indicates it is still under CC-SG management: Shut down the CC-SG application using System Maintenance > Shutdown. After the timeout period the devices will be directly accessible. Note: If your CC-SG unit is relatively new, the database may include considerably less nodes than those for which licensing was purchased.
PAGE 6
conflicts between the two CC-SGs if both are inadvertently brought on line. This can be done by accessing the Diagnostic Console Operation Menu > Admin > Factory Reset > Full CC-SG Database Reset option. Notes: • All appliances must be running the same version (5.1.0 or higher) • This does not pertain to clustering. A CC-SG “Cluster” cannot include a virtual appliance. Only hardware units can be clustered. Failover for virtual appliances is implemented by utilizing the VMware “High Availability” feature.
PAGE 7
Security and Compliance Information Refer to the CC-SG Administrators Guide ‘Appendix B: CC-SG and Network Configuration’ for specific settings. Updated Product Documentation Updated documents available with this release include: • CC-SG 5.1.0 Upgrade Readme File • Compatibility Matrix • Administrators Guide • Users Guide • Quick Setup Guide General Notes 1. If using Windows XP or Vista, CC-SG supports the 64 bit OS. However, if using a Java plug-in, only the 32 bit plug-in is supported.
PAGE 8
Limitations and Restrictions 1. Supported JRE versions for this release include 1.6.0_10 thru 1.6.0_20. 2. The “Bookmark Node” feature is not supported when using Internet Explorer version 8 (IE8). (20053, 20237) 3. The "Exit" option in the MPC client’s "Connection" menu does not function when running on Linux. Use the X in the corner of the window as an alternative. This issue has been seen when using the following: • Fedora Core 6: JRE 1.6.0_13; Firefox 3.0.10 • Fedora Core 7: Firefox 2.0.0.14, JRE 1.
PAGE 9
• o Intel Pentium D with Windows Vista o Intel Celeron with Windows 2003 Server o AMD Opteron with Windows 2003 Server o AMD Opteron with Windows 2003 Server o AMD Opteron with Windows 7 o AMD Opteron with Windows 2008 Server o AMD Athlon 64 with Windows Vista Raritan’s testing has shown the following processor/OS combinations to be unfavorable: o Intel Xeon with Windows 2003 Server o Intel Xeon with Windows 2003 Server o Intel Pentium 3 with Windows 2003 Server (32514) CC-SG 5.1.
