User's Manual

P25net Channel Controller Operations Manual
2-6
2.5.4.5 RJ45 Ethernet port
This jack is normally used for connection to a BSC .
P25 Channel Controller
LAN
AC power DC power channel 1 processor
tx
rx
channel 2 processor
tx
rx
channel 3 processor
tx
rx
channel 4 processor
tx
rx
etherstack powered
1.75
12.4
16.75
19.0
Figure 2-1 P25net CC Outline Dimensions
Figure 2-2 Front Panel
