OWNER’S MANUAL Read and understand this entire manual BEFORE riding! For assistance contact Razor. DO NOT RETURN TO STORE. NOTE: Manual illustrations are for demonstration purposes only. Illustrations may not reflect exact appearance of actual product. Specifications subject to change without notice. Please have your product and 19 digit product I.D. code ready before contacting Razor for warranty assistance and/or replacement parts. Product I.D.
CONTENTS Safety Warnings ............................................................ 1 Before You Begin ........................................................... 2 Assembly and Set-Up ................................................. 3-4 Repair and Maintenance ............................................. 5-6 Troubleshooting Guide................................................ 8-9 EcoSmart Metro Scooter Parts.................................... 11 Safety Reminders ......................................
BEFORE YOU BEGIN Remove contents from box. Remove the foam separators that protect the components from damage during shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during shipping. Because the EcoSmart Metro electric scooter was 95 percent assembled and packed at the factory, there should not be any problems, even if the box has a few scars or dents.
ASSEMBLY AND SET-UP q Attaching the Front Wheel A B B 1 Remove the packing material from the front fork. A 3 Insert the tab on the safety washer (B) into the hole on the front fork and tighten axle nuts using two 15mm open wrenches. 2 Remove axle nuts (A) from the axle bolt and insert the wheel into the front fork. Safety washers should face outside of the fork.
ASSEMBLY AND SET-UP q Attaching the Basket 1 2 2 WARNING: Do not exceed weight limit of 11lbs (5kg) on luggage rack. 1 WARNING: The carrier should not be used to carry people or pets. 1 Slide the basket hooks (1) under the bar located on the luggage rack. 2 Align the hole in the basket (2) with the hole on the luggage rack (1). 3 Insert the washer and bolt into the hole in the basket and through the bracket on the luggage rack.
REPAIR AND MAINTENANCE q Charging the Battery Your electric scooter may not have a fully charged battery. Therefore it is a good idea to charge the battery prior to use. • Initial charge time: 12 hours • Recharge time: up to 12 hours, even if the light turns green. Recommended maximum charging time is 24 hours. • Always charge the battery immediately after riding. • Fully charge battery before storing for extended periods of time. • Unplug charger from the wall outlet when not in use.
REPAIR AND MAINTENANCE qChecking Spoke Tension Spoke Flange Spoke Hub Flange Spoke Flange Rim Nipple Nipple 1 Verify spoke tension by grasping and shaking each spoke. Spoke should not be loose from hub. Look for any play between spoke flanges where it mates with hub. Try to turn nipple using your fingers. You should not be able to spin any nipple by hand. If one or more spokes are loose, or if you can turn any nipple using your fingers, all spokes must be checked and need to be tightened.
SB 1918 (CALIFORNIA) DECLARATION YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER/ELECTRIC RIDE-ON PRODUCT. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.
TROUBLESHOOTING GUIDE Problem Possible Cause Solution Scooter does not run Undercharged battery Charge the battery. A new battery should have been charged for at least 12 hours before using the scooter for the first time and up to 12 hours after each subsequent use. Check all connectors. Make sure the charger connector is tightly plugged into the charging port and that the charger is plugged into the wall. Make sure power flow to the wall outlet is on.
TROUBLESHOOTING GUIDE Problem Possible Cause Solution Sometimes the scooter Loose wires or connectors doesn’t run, but other times it does Motor or electrical switch damage Check all wires around the motor and all connectors to make sure they are tight. Charger gets warm during use No action required. This is normal for some chargers and is no cause for concern. If your charger does not get warm during use, it does not mean that it is not working properly.
ECOSMART METRO PARTS Keep your EcoSmart Metro electric scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Specifications subject to change without notice.) 1. Handle grip 9. Front fork 16. On/Off switch 24. Motor (36v 500w) 2. Throttle 10. Nut 17. Charger port 25. Clamp 3. Handlebar 11. Socket head cap screws 18. Kick stand 26. Seatpost 4. Brake lever (left) 12. Front wheel complete 19. Control module 27.
SAFETY REMINDERS PRE-RIDE CHECKLIST q q q Loose Parts Check and secure all fasteners before every ride. Make sure steering stem clamp bolts are locked properly in place. There should not be any unusual rattles or sounds from loose parts or broken components. If you are not sure, ask an experienced mechanic to check. Brake Check the brakes for proper function. When you squeeze the levers, the brake should provide positive braking action.
