Child Safety Guide 1
Child Safety Guide Use una montura que se ha recomendado por el fabricante de monitor y/o listado por un laboratorio independiente (como UL, CSA, ETL). Siga todas las instrucciones ofrecidas por el fabricante de monitor y montaje de pared.
Table of Contents Child Safety Guide ........................................................................................................................................1 Caution and Warning ................................................................................................................................... 5 FCC Notice ..................................................................................................................................................... 5 Safety Precautions .
Table of Contents OSD Menu Operations .............................................................................................................................. 23 Adjust the OSD Screen .............................................................................................................................. 23 Picture Menu ............................................................................................................................................. 23 Sound Menu .......................
Caution and Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Caution: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product enclosure that may be of sufficient magnitude to consitute a risk of electric shock.
Safety Precautions 1. 2. 3. 4. 5. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. For example, do not use near a laundry tub, in a wet basement, or near a swimming pool, and the like. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Safety Precautions 23. WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. 24. To reduce the risk of electric shock, the grounding of center pin of plug must be maintained. 25. If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA NO.
1SFQBSBUJPO GPS :PVS /FX 57 #FGPSF 5VSOJOH 0O 57 $IFDL "DDFTTPSJFT $IFDL UIF BDDFTTPSJFT UIBU BSF QBDLFE XJUI ZPVS 57 3&.05& $0/5301"35 /0 3& 21 """ #"55&3*&4 57 45"/% 4$3&84 %0$6.&/54 4$3&84 . Y NN QDT 1BSU 34 5# ) CH . LIST 0ART .O 2. 2 English ,%$ ,#$ 46 5SER S -ANUAL . Y NN QDT 1BSU 34 18" )5 PICTURE 57 45"/% #"4& 26*$, 45"35 (6*%& 64&3 4 (6*%& -ODEL .
TV Stand Installation TV LED32B30RQ is packaged with the TV stand separated from the cabinet. To setup the TV table stand, please carry out the installation according to the instructions below. Step One Place the TV faced down on a soft cloth or cushion to prevent the panel from being damaged. The panel can be scratched easily, so please: 1. Choose an absolutely flat surface to place the TV on. 2. Use soft cloth or cushion to face the TV panel. Do not put TV on the table directly.
TV Signal Connection The first step in connecting your TV is obtaining the signal. Your TV LED32B30RQ has a side panel, which allows you to receive analog and/or digital television channels via ANT/CABLE jack. Before connecting your TV, determine using an antenna or a cable service to obtain the signal. A. Antenna Connect the antenna to TV via coaxial cable on ANT/CABLE jack of the side panel. You are ready to receive air local digital and analog channels. B.
Cable Connections Choose Your Connections TV supports various connections to other devices (such as DVD, VCR, Set-top box, etc.). Please follow the table to choose the cables which adapt to your device. Jacks Cables Further Information Go to page 12 AV IN VIDEO, R-AUDIO-L Video/Audio cable Audio Cable Go to page 13 COMPONENT IN Y, Pb, Pr R-AUDIO-L COMPONENT video cable HDMI-DVI cable HDMI IN 1/DVI, 2, 3 Go to page 14 HDMI cable Audio cable with 3.
Side Panel Connections Connecting AV Composite device (Good Video Quality) To connect a composite AV device, such as a DVD player, follow these steps: 1. Connect the VIDEO jack on the back of TV to the video output jacks of device via video cable (yellow). 2. Connect the R-AUDIO-L jacks on the back of TV to the audio output jacks of device via audio cable. Notice the left channel jack and plugs are white and the right channel jack and plugs are red. Note: AV signal belongs to composite video.
Side Panel Connections Connecting YPbPr Component device (Better Video Quality) To connect a component device, such as a DVD player, follow these steps: 1. Connect the COMPONENT IN Y/Pb/Pr jack on the side of TV to the video output jacks of device via video cable (green, blue and red). 2. Connect the AUDIO IN R-AUDIO-L jacks on the side of TV to the audio output jacks of device via audio cable. Notice the left channel jack and plugs are white and the right channel jack and plugs are red.
Side Panel Connections Connecting HDMI device (Best Video Quality) To connect a HDMI device, such as a DVD player, please Connect the HDMI 1/DVI, 2, or 3 jack on the back of TV to the output jacks of device via HDMI cable. To connect a DVI device, such as a computer via DVI port of PC and HDMI jack of TV: 1. Connect the HDMI 1/DVI, 2, or 3 jack on the back of TV to the DVI port of PC via HDMI-DVI cable. 2. Connect the SOUND/DVI jack on the side of TV to the audio output jack of computer with audio cable (3.
Side Panel Connections Connecting a computer To connect a computer, follow these steps: 1. Connect the PC INPUT VGA port on the back of TV to the VGA output jack of device via D-sub 15-pin cable. 2. Connect the SOUND/DVI jack on the back of TV to the audio output jack of computer with audio cable (3.5mm). Note: If you want to use your TV as a monitor, please notice that the maximum resolution for LED32B30RQ is 1366*768. Please set the computer graphic correctly.
USB TV Jacks Explanation HEAD PHONE: Connect a 3.5mm headphone for personal audio. SOUND/DVI: Use to obtain sound when a PC is connected to TV. Use 3.5mm stereo mini-pin cable to connect PC to TV. ANT/CABLE: Connect to receive the signal from your antenna or cable via coaxial cable. PC INPUT VGA: Connect your computer or other device with a VGA output to this jack using a 15-pin, D-sub cable.
Bottom Keypad and Front Panel Bottom Side Keypad If you cannot locate your remote, you can use the keypad buttons on your TV to operate many TV features. INPUT: Displays the Source Select List. MENU: Displays the TV Main Menu. CH : Scans up through the channel list. In the TV menu system, it acts like the up arrow on the remote control and can be used to select menu options. CH : Scans down through the channel list.
Remote Control Instructions Inserting Batteries in the Remote • Remove the cover of battery cabin on the back of the remote control by lifting the cover. • Insert two AAA batteries, making sure the polarities (+ and -) are aligned correctly. • Place the cover back. If the remote control does not work, check these points: CAUTION: • Are the polarities (+, -) correct? • Used batteries should be recycled. • Are the batteries worn out? • Keep out of children’s reach.
Learning about Remote Control Remote Control Buttons MUTE ( ): Reduces the TV volume to its minimum level. Press again to restore the volume. POWER ( ): Turns the TV on or off. CH . LIST CH.LIST: Displays the channel list. FAV.: Adds the current channel to your favorite list, or erases the current channel from your favorite list (if this channel is a favorite channel already). FAV.+ or FAV.- : Scans up or down through the current favorite channel list.
*OJUJBM 4FUVQ *G JU JT UIF mSTU UJNF ZPV UVSO PO ZPVS 57 PS ZPV IBWF EPOF $MFBS $IBOOFM -JTU PQUJPO TFF QBHF UIF JOJUJBM TFUVQ NFOV BQQFBST BVUPNBUJDBMMZ Initial Setup Initial Setup Initial Setup Signal Type Please select Menu Language Please select Home mode if you are installing this TV at home Please choose between Energy Saving and Dynamic mode.
Basic Operations Turning On and Off Connect the AC cord to power the LED LCD TV. At this time the TV will enter standby mode and power indicator will turn red. Use Power button ( ) on the top panel of TV or on the remote control to turn on the TV. After switching off the TV for 5 seconds, you can turn on TV again. Choosing TV Channel Tuning To Analog Channels An analog channel has a channel number beginning with “A”. Input the digital number with numeric buttons directly and press ENTER button to confirm.
Basic Operations Channel Bar Press the DISPLAY button on the remote control, the channel bar will appear on the top right corner of the screen. It displays the current channel’s information. The following list describes the items on the channel bar. A2 Air MTV Mono 480i Oct-31 23.14 Mon ATV A2/D50-1 MTV/KOCE-HD Mono/English 480i/1080i 16:9/CC/TV-PG D50 - 1 Air KOCE-HD English 1080i Oct-31 23:14 Mon DTV If the channel is analog, A is displayed. If it’s a digital channel, D is displayed.
04% .FOV 0QFSBUJPOT "EKVTU UIF 04% 4DSFFO 5IF 04% 0O 4DSFFO %JTQMBZ NFOV FOBCMFT ZPV UP BQQSPBDI UP UIF 57 GVODUJPOT 5P VTF 04% NFOV TZTUFN QSFTT .
04% .FOV 0QFSBUJPOT 4DSFFO 4J[F PICTURE SOUND CHANNEL PARENTAL SETUP OTHERS PICTURE Picture Settings Screen Size 4DSFFO 4J[F 4FMFDU B TDSFFO BTQFDU SBUJP "WBJMBCMF SBUJP 8JEF $JOFNB ;PPN BOE /PSNBM 1MFBTF DIPPTF UIF SBUJP UIBU BQQMJFT UP ZPVS WJEFP TJHOBM GPSNBU CFTU Wide PC Settings Color Temperature Warm Advanced Picture Settings Adjust settings to affect picture quality.
04% .FOV 0QFSBUJPOT 4PVOE .FOV 5IF 4PVOE .FOV MFUT ZPV BEKVTU BVEJP PVUQVU 5P BDDFTT UIF 4PVOE .FOV QSFTT .&/6 PO UIF SFNPUF BOE UIFO TFMFDU 406/% GSPN UIF .BJO .
04% .
04% .FOV 0QFSBUJPOT 4JHOBM 5ZQF 4FMFDU ZPVS 57 TJHOBM UZQF "JS PS $BCMF "VUP $IBOOFM 4FBSDI &YFDVUF BO BVUP DIBOOFM TFBSDI TFF QBHF 1BSFOUBM .FOV 5IF 4FUVQ .FOV FOBCMFT ZPV UP MPDL QSPHSBN XJUI TQFDJBM DPOUFOU QBOFM LFZ CPBSE BOE JOQVU TPVSDF 1SFTT .&/6 BOE DIPPTF 1"3&/5"- GSPN UIF .
04% .FOV 0QFSBUJPOT .
04% .
04% .
04% .FOV 0QFSBUJPOT 4FUVQ .FOV 5IF 4FUVQ .FOV MFUT ZPV DPOmH UIF 57 XJUI ZPVS QSFGFSFODFT 4FMFDU 4&561 GSPN UIF .BJO .
04% .FOV 0QFSBUJPOT %JHJUBM $$ 4UZMF PICTURE SOUND CHANNEL PARENTAL SETUP OTHERS CLOSED CAPTION CC Size Default CC Font Default CC Opacity Default Text Color Default CC Background Opacity Default CC Background Color Default 4FMFDU UIF JUFN ZPV XBOU UP BEKVTU JO %JHJUBM $$ 4UZMF NFOV XJUI VQ EPXO BSSPXT "GUFS DIBOHJOH ZPV DBO QSFWJFX UIF DBQUJPO TUZMF IFSF CLOSE CAPTION Adjust the size of the digital Closed Captioning font. MOVE SELECT : Exit .
04% .FOV 0QFSBUJPOT 0UIFST .FOV 5IF 0UIFST .FOV MFUT ZPV DPOmH UIF 57 XJUI ZPVS QSFGFSFODFT JO PUIFS GFBUVSFT $IPPTF 05)&34 GSPN UIF .BJO .
Frequently Asked Questions (FAQs) What’s the most convenient way to view High Definition (HD) video? Connect an antenna to the TV Input jack to view free local digital channels. You may need to purchase an antenna. (See page 10 for more information about antenna setup). Visit www.antennaweb.org for assistance in deciding what type of antenna to use to receive the local digital channels available to you.
Troubleshooting Identifying Problems If there are any problems when using the product, please consult the list below. If the list does not solve the problem, call our Customer Service Center immediately. TV Problems The TV can’t be turned on. • • • • Make sure the AC cord is plugged in. Check the wall outlet, make sure the AC output works normally and stably. The side panel may be locked (disabled). Use the remote control to turn on the TV.
Troubleshooting Can’t select a certain channel. • The channel may be blocked or not approved in the PARENTAL Menu. • The channel may be skipped in channel list in CHANNEL Menu. Check the blocking and skipping status of channel. The stereo sound performance is bad. • It may be a weak station. Use the SOUND Menu and set Analog Sound as Mono. A black box appears on the screen. • Closed captioning might be on. Check Closed Caption in the SETUP menu. Go to page 32 for more instructions.
V-Chip Rating Explanations US V-Chip Rating System TV-MA (Mature Audience Only): Specifically designed to be viewed by adults and may be unsuitable for children under 17. It contains one or more of the following content themes: crude indecent language (L), explicit sexual activity (S), or graphic violence (V). TV-14 (Parents Strongly Cautioned): Contains some material that many parents would find unsuitable for children under 14.
V-Chip Rating Explanations C8+ (Children 8 and older): Programming generally considered acceptable for children 8 years and over to watch on their own. Violence Guidelines: Violence will not be portrayed as the preferred, acceptable, or only way to resolve conflict or encourage children to imitate dangerous acts which they may see on television. Any realistic depictions of violence will be infrequent, discreet, of low intensity and will show the consequences of the acts.
Wall Mounting Unit Specification Model Unit Dimension (unit:mm) Screw LED32B30RQ VESA 200 x 100 M6 screws, length 14mm 200 mm 100 mm Note: A. The wall mount is not contained in the accessories sold with television. We only provide the installing specifications but not the wall mount itself. If you need the mount, please consult with the local dealer for a VESA wall mount. B. We strongly suggest to set the wall mount with equipments of specification we ordered.
USB Media Play With USB Media Play, you can enjoy music and photo files stored in a USB storage device on your RCA TV. Connecting a USB storage device Connect a USB storage device to the USB port in the back of the TV. Press “INPUT” and select “Media”. “USB Media Play” menu will appear. Music Photo Media Setting Now Playing Playing back Music files Press arrow ( / ) to select “Music” and press “ENTER”. The file or folder list will show up. Press arrow ( / ) to select a file or folder.
Product Specification Model LED32B30RQ Diagonal Display Size 32 inches Television System American TV standard ATSC/NTSC system Channel Coverage VHF: 2~13 Operating Temperature is 0℃~+50℃ (+32℉~+122℉) Storage Humidity: Less than 85% RH (No condensation) Humidity Operating Humidity: Less than 80% RH (No condensation) Power Supply AC 100-120V, 50-60Hz RF Input Cable/Antenna x 1 HDMI 3 Component 3 x 1 + Audio R, L (RCA) (Component sound is shared with AV) AV-IN (Composite) Video + Audio R, L
Made for Today. Limited Warranty for USA and Mexico Coverage – Labor For a period of 12 months from date of purchase of your RCA pr oduct, we will pay an authorized RCA service center the labor charge to repair any defects in materials or workmanship in your television. If your television is unrepairable we will provide you with a refurbished unit of the same or better model.
Items Not Covered By Limited Warranty Your limited warranty does not cover the following items: Un-installation, installation and adjustment of customer controls and operating instruction. Batteries and customer replacement fuses. Damage due to misuse, abuse, negligence or neglect including but, not limited to, damage resulting from exposure to moisture, humidity or salt. Inability to receive a signal due to problems not caused by the product. Damage to the product due to images burnt into the screen.
Hecho para Hoy. Garantía limitada para EE.UU y Mexico. Cobertura-Trabajo Durante un período de 12 meses desde la fecha de compra de su producto RCA, pagaremos a un centro autorizado de servicio de RCA el cargo de mano de obra para reparar cualquier defecto en materiales o mano de obra en el televisor. Si su televisor es irreparable que le proporcionará una unidad reacondicionada del mismo modelo o superior.
Elementos no cubiertos por la garantía limitada Su garantía limitada no cubre los siguientes temas: Un-instalación, montaje y ajuste de controles del cliente e instrucciones de funcionamiento. Las pilas y los fusibles de repuesto al cliente. Daños por uso indebido, abuso, negligencia o descuido incluyendo pero no limitado a, los daños derivados de la exposición a la humedad, la humedad o la sal. Incapacidad para recibir la señal debido a los problemas que no son causadas por el producto.
