USER’S MANUAL 39” RLDED3950A LED TV
Contents Introduction Warning Caution Important Information Attaching or Removing the Stand Installing Batteries to the Remote Control Identifying Front and Rear Panel Connection Suggestion Main Unit Description Remote Control OSD Basic Adjustment How Do I Clean The TV Troubleshooting Specifications FCC Compliance Statement 1
Introduction Thank you very much for purchasing your LED TV. It serves as a normal colour TV and a PC monitor. To enjoy your set fully from the very beginning, read this manual carefully and keep it handy for future reference. INSTALLATION ① Locate the receiver in the room where direct light does not strike the screen. Total darkness or a reflection on the picture screen can cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.
Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to avoid the risk of electric shock. This equipment may only be disassembled by qualified service personnel.
Caution Caution - High voltages are used in the operation of this product. Do not open the product's casing. Refer servicing to qualified service personnel . Caution To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture，do not place objects filled with liquids, such as vases, on the apparatus. Caution Do not drop or push objects into the television cabinet slots or openings. Never spill any kind of liquid on the television receiver.
Caution Caution Never stand on, lean on or suddenly push the product or its stand. You should pay special attention to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual and damage to the television may result if it should fall. Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power from the AC outlet.
Important Information Television Antenna Connection Protection External Television Antenna Grounding If an outside antenna or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.
Attacthing or Removing the Stand 1. To attach the base place the display unit flat on a table. Afterwards attach the stand onto the bottom of the stand. Screw in the 5 screws to secure the stand.
2. To remove the stand, remove the 4 screws in the area and the stand will come off. Installing Batteries to the Remote Control Please insert two AAA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment. Afterwards, re-attach the battery cover. Please note: � Only use AAA batteries. � Do not mix new and old batteries.
Identifying Front and Rear Panel Front View INDICATOR LIGHT – The light is red when power is plugged in but the TV is not turned on. The light turns blue when the TV is turned on. Because of the LED in the panel, the TV might take 10 – 12 seconds to power on. REMOTE SENSOR – The remote sensor receives all the commands from the remote control. Rear View Mounting Pattern Mounting Specification : 200mm x 200mm using screw size M6. Length of screw should not exceed 8mm.
Connection Suggestions If You Have Digital Cable without Cable Box or Antenna… 1. 2. 3. 4. Make sure the power of HDTV is turned off. Connect the RF cable from your antenna or digital cable to the TV port on the back of your HDTV. Turn on the HDTV. Follow the first time on screen instructions. Please Note: Not all broadcasts are in High Definition (HD). Please refer to your local broadcasting stations for more information.
Connecting DVD Player with Component YPbPr… 1. Make sure the power of HDTV and your DVD player is turned off. 2. Obtain a Component Cable. Connect the green color connector to both your DVD player and YPbPr’s green connector port on the back of your HDTV. 3. Connect the blue color connector to both your DVD player and YPbPr’s blue connector port on the back of your HDTV. 4. Connect the red color connector to both your DVD player and YPbPr’s red connector port on the back of your HDTV. 5.
Connecting Wii™ with Composite… 1. 2. 3. 4. 5. 6. Make sure the power of HDTV and your Wii™ is turned off. Obtain a Yellow Video Cable. Connect the Yellow Video connector to both your Wii™ and AV’s Yellow Video connector port on the back side of your HDTV. Obtain a RCA Audio Cable. Connect the white color connector to both your Wii™ and AV’s white connector port on the back side of your HDTV. Connect the red color connector to both your Wii™ and AV’s red connector port on the back side of your HDTV.
Connecting Cable or Satellite boxes with HDMI… 1. Make sure the power of HDTV and your set-top box is turned off. 2. Connect a HDMI cable to the HDMI output of your set-top box and the other end to the HDMI port on the back of your HDTV. 3. Turn on the HDTV and your set-top box. 4. Use the remote control’s source button or the source button on the TV to switch to HDMI. Please Note: Please reference the set-top box’s manual, to make sure the set-top box is configured to output correctly to the TV.
Connecting to a PC with VGA and 3.5 mm minijack … 1. Make sure the power of HDTV and your PC is turned off. 2. Obtain a 15-pin D-Sub VGA cable; connect to the VGA output of your PC and the other end to the VGA port on the back of your HDTV. 3. Obtain a 3.5 mm Mini-jack, connect to the audio out of your PC and the other end to the VGA Stereo Input port. 4. Turn on the power of the HDTV and your PC. 5. Use the remote control’s source button or the source button on the TV to switch to PC. 6.
Connecting a Digital Audio Receiver with Coaxial... 1. 2. 3. Make sure the power of HDTV and your receiver is turned off. Obtain a COAXIAL cable, connect it to your receiver’s COAXIAL digital input and the COAXIAL connection on the LINE OUT port on the back of the HDTV. Turn on the HDTV and your receiver. Please Note: If you want pure digital stream for your receiver to decode, you must also configure the TV’s OSD Sound->Digital Audio Out function. Make sure the option is on 5.1CH.
Main unit description Control Panel Button Function VOL+ : Volume up. VOL- : Volume down. CH+ : TV channel up. CH- : TV channel down. MENU : Press to select the main menu. TV/AV : Select the input signal. POWER : Switch on when at standby mode or enter the standby mode. TV Terminal Connections 1. Coaxial out terminal. 2. RF antenna. 3. VGA input terminal of simulation signal of PC. 4. PC AUDIO input terminal. 5. Video input terminal. 6. AUDIO input terminal（Audio input terminal for Component and Video）.
Remote control POWER: Power on/off button, press once to turn the TV on and press again to turn the TV off. MUTE: Press this button to mute or restore sound. MTS/AUDIO: When stereo program is received, press this key to switch sound system between mono and stereo. When SAP program is received, press this button to switch sound system between mono and SAP When stereo and SAP program is received, press this key to switch among mono, stereo and SAP.
Installation Guide Press MENU button to display the MAIN OSD MENU; Press ◄ / ►button to select the MENU you want; Press ENTER button to enter the sub menu; Press ▼ / ▲ button to select the option and then press ◄ / ► to adjust the value in the sub menu; You can press MENU button to go back to the upper menu or EXIT button to close the OSD. PICTURE Press ENTER when the Picture Settings item is highlighted. Then you will go to the sub-menu as following. Press ▼ / ▲ to select the desired menu item.
Press ▼ / ▲ button to select Brightness, then press ◄ / ► button to adjust. . Press ▼ / ▲ button to select Contrast, then press ◄ / ► button to adjust. . Press ▼ / ▲ button to select Color, then press ◄ / ► button to adjust. . Press ▼ / ▲ button to select Tint, then press ◄ / ► button to adjust. Press ▼ / ▲ button to select Sharpness, then press ◄ / ► button to adjust. . Screen Size Press ▼ / ▲ button to select Screen Size, then press ◄ / ► button to adjust.
Press ▼ / ▲ button to select Auto Adjust, then press ENTER button to start auto adjusting. Press ▼ / ▲ button to select Horizontal Position, then press ◄ / ► button to adjust. Press ▼ / ▲ button to select Vertical Position, then press ◄ / ► button to adjust. Press ▼ / ▲ button to select Clock, then press ◄ / ► button to adjust. Press ▼ / ▲ button to select Phase, then press ◄ / ► button to adjust. Press ▼ / ▲ button to select Reset, then press ENTER button to reset the options above.
SOUND Sound Settings Press ENTER when the Sound Settings item is highlighted. Then you will go to the sub-menu as following. Press ▼ / ▲ to select the desired menu item. Press ENTER to proceed if necessary. Press / to adjust the item the desired level. When you have changed the settings, you can exit from the menu by pressing MENU. Bass Press ▼ / ▲ button to select the item Bass, then press ◄ / ► button to adjust. Treble Press ▼ / ▲ button to select the item Treble, then press ◄ / ► button to adjust.
AVL Press ▼ / ▲ button to select the item AVL, then press ENTER button to adjust. Analog Sound Press ▼ / ▲ button to select the item Preferred Analog Sound, then press ◄ / ► button to select the prefer audio Digital Sound Press ▼ / ▲ button to select the item Preferred Digital Sound, then press ◄ / ► button to select the prefer audio Digital Audio output Press ▼ / ▲ button to select the item Digital Audio output, then press ◄ / ► button to select the Audio output mode.
CHANNEL MENU Note: This menu is only shown when the input source is TV. Channel List Press ▼ / ▲ button to select Channel List, then press enter scan the Channel List. If you select the press enter button to option “In Channel List” On, the channel label will display in the list. Favorite List Press ▼ / ▲ button to select Favorite List, then press ENTER button to scan the Favorite Channel List.
Skip Set the channel to be skipped when using CH+/Ch- to view channels. Favorite Set the channel to your favorite list. Label Rename label of the channel. Signal Type Press ▼ / ▲ button to select Signal Type, then press button ◄ / ► to select the type you want to set. There are two selections: Air and Cable. Auto Channel Search Press ▼ / ▲ button to select Auto Channel Search, then press ENTER button to search channel. A Channel Search Menu will appear as below.
PARENTAL CONTROL Input password to enter, default password is “0000”. V-CHIP Press ▼ / ▲ button to select V-CHIP, then press ENTER button to adjust. A Sub Menu Will appear as below.
US V-CHIP Press ▼ / ▲ button to select US V-CHIP, then press ENTER button to adjust. A Sub Menu Will appear as below. Movie Rating Press ▼ / ▲ button to select Movie Rating, then press ENTER button to adjust. A Sub Menu Will appear as below. Press ▼ / ▲ button to select Rating, then press ENTER button to lock TV Rating Press ▼ / ▲ button to select TV Rating, then press ENTER button to adjust. A Sub Menu will appear as below. Press ▼ / ▲ / ◄ / ► button to select Rating, then press ENTER button to lock.
CANADA V-CHIP Press ▼ / ▲ button to select CANADA V-CHIP , then press ENTER button to adjust. A Sub Menu Will appear as below. The operation of CANADA V-CHIP is the same as the operation of US V-CHIP. Block Unrated Show Press ▼ / ▲ button to select Block Unrated Show, then press ENTER button to set the rating locked. Downloadable Rating Press ▼ / ▲ button to select Downloadable Rating, then press ENTER button to set the rating.
Clear Downloadable Data Press ▼ / ▲ button to select Clear Downloadable Data, then press ENTER button to set the rating. Note: The above two operation only valid when playing the downloadable data stream. The operations are the same as US V-CHIP. CHANGE PASSWORD Press ▼ / ▲ button to select Change Password, then press ENTER button to adjust the value. A Sub Menu Will appear as below. If the password is changed, all of the passwords in the menu will be changed at the same time.
Setup Menu Closed Caption Press ▼ / ▲ button to select the item Closed Caption, then press ◄ / ► button to adjust.
Caption Display Press ▼ / ▲ button to select Caption Display, then press ◄ / ► button to select ON or OFF. Analog Caption Type Press ▼ / ▲ button to select Analog Caption Type, then press ◄ / ► button to select the type. Digital Caption Type Press ▼ / ▲ button to select Digital Caption Type, then press ◄ / ► button to select the type. Digital CC Preset Press ▼ / ▲ button to select Digital CC Preset, then press ◄ / ► button to select Default or Custom.
CC Opacity Press ▼ / ▲ button to select CC Opacity, then press ◄ / ► button to select the Opacity. Text Color Press ▼ / ▲ button to select Text Color, then press ◄ / ► button to select the color. CC Background Opacity Press ▼ / ▲ button to select CC Background Opacity, then press ◄ / ► button to select the Opacity. CC Background Color Press ▼ / ▲ button to select CC Background Color, then press ◄ / ► button to select the Color.
OTHERS MENU Blue Back Press ▼ / ▲ button to select Blue Background, then press ENTER button to select when there is no signal, whether set the background in blue or not. No Signal Power Off Press ▼ / ▲ button to select No Signal Power Off, then press ENTER button to select it On or Off. When set it on, if there is no signal input, it will go into standby. No Operation Power Off Press ▼ / ▲ button to select No Operation Power Off, then press ENTER button to select it On or Off.
How do I Clean the TV? IMPORTANT 1. The power cable has to be removed from the socket before cleaning the TV. 2. Do not use volatile solvent (alcohol, rosin, and toluene) to clean the TV. These types of chemicals might damage the housing and the LED glass. Cleaning the bezel and remote control 1. Use a 100% cotton cloth or micro-fiber cloth for cleaning. 2.
Troubleshooting Troubleshooting The following table contains the common problems and the solutions to these problems. Please check this list before you contact the technicians. Problems Solutions Connect power cord correctly. Turn on power. NO PICTURE Connect video cable correctly. Select the input signal source with proper cable connection with the source button. ABNORMAL Match the colors on the cables to the ports off the back of the television. I.E. red cable to red colored COLORS port.
Problems Solutions TV CHANNELS ARE Check your auto lock function’s settings inside the OSD. You may have locked up some channels but forgot BLOCKED about them. UNIVERSAL REMOTE This TV follows NEC’s universal remote code. Please check your hand book for NEC’s codes then apply CODE them. THE TV TURNS ON OR This TV is a High Definition liquid crystal display panel TV. It requires a few more seconds than normal TVs OFF SLOWLY AND THE to power up and show the picture.
Problems Solutions A Different channels and inputs will sometimes have this effect because the channel signal’s own volume SWITCHING CHANNEL SOURCE OR is already loud. There is no way remove this completely. The TV has an AUTO VOLUME LEVEL CHANGES function that can combat this type of effect. Please make sure that function is turned on.
Specifications Display panel Illustration Item Active Area / Screen Size Diagonal 39 inches Aspect Ratio Widescreen 16:9 Pixel Pitch 0.176 (H) x RGB x 0.530 (V) um per one triad Max. of Pixels (Resolution) FHD (1920 x 1080 pixels) resolution Brightness 280 nits (Typical) Contrast 1500:1 (Typical) with Auto Contrast Enhancement Response Time 8 ms (gray to gray) Typical 178/178 Degree Viewing Angle (Horizontal/Vertical) Lamp Life of Backlight > 30,000hrs TV DISPLAY 35.00” x 20.76” x 3.
(2)Audio Sound Mode Dynamic/Standard/Soft/User Auto Volume Control Yes Tone Bass / Treble / Balance COAXIAL Out Yes (coax) Speakers 6 watt per channel (3) General Hybrid TV Tuner NTSC / ATSC / QAM (Digital Cable Ready) Channel auto scan Yes Sleep timer Off/10mins/20mins/30mins/40mins/50mins/60mins/90mins/120mins Standby power Under 1W Timing support-Video 480i / 480p / 720p / 1080i / 1080p 1920 0*1080@60 Hz (NATIVE) 1024*768@60 PC timing 800*600@60 640*480@60 720x400@70 (4)NTSC/ATSC So
FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: This device may not cause harmful interference This device must accept any interference received, including interference that my cause undesired operation. Please Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
