RS2610-EN rev.1 7/23/02 3:11 PM Page 2 IMPORTADOR Comercializadora Thomson de México, S.A. de C.V. Miguel de Cervantes Saavedra 57 Col. Ampliación Granada C.P. 11529 Mexico D.F. Telefono: (55)25 81 53 20 RFC: CTM-980723-KS5 0151 EXPORTER Thomson multimedia Inc. P.O. Box 1976 Indianapolis, IN 46206-1976 © 2002 Thomson multimedia Inc. Trademark(s) ® Registered Marca(s) ® Registrada(s) Marque(s) ® Deposée(s) 55392950 Rev.1 (EN/F/E) www.rca.com www.rca.
RS2610-EN rev.1 7/23/02 3:11 PM Page 3 u s e r m a n u a 1/2 l RS2610 It is important to read this instruction book prior to using your new product for the first time. Es importante leer este manual antes de usar por vez primera su euipo.
RS2610-EN rev.1 7/23/02 3:11 PM Page 4 FCC Information EN FCC Information Technical specification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. In accordance with FCC requirements, changes or modifications not expressly approved by Thomson multimedia Inc.
RS2610-EN rev.1 7/23/02 3:11 PM Page 5 Safety Information For Your Records Service Information In the event that service should be required, you may need both the model number and the serial number. In the space below, record the date and place of purchase, and the serial number: Model No. Remote Control No. Date of Purchase Place of Purchase Serial No. This product should be serviced only by those specially trained in appropriate servicing techniques.
RS2610-EN rev.1 7/23/02 3:11 PM Page 6 Getting Started EN Unpacking the system: Connecting the Speakers Match the red wire (on the left speaker) to red terminal for the left speaker (L) on the back of the unit and the black wire (on the left speaker) to the black terminal for left speaker (L). Follow the same procedure to connect the right (R) speaker.
RS2610-EN rev.1 7/23/02 3:11 PM Page 7 Controls and Indicators Main Unit EN 1/2 STANDBY / POWER — Turns power on or off (Standby mode). Tip: In STANDBY mode (press STANDBY/POWER off), the system displays the time. Press STANDBY/POWER to turn the system on in the previously used mode. Press CD, TAPE, TUNER, or AUX (Remote only) to select the corresponding mode. Look at the display icons to identify the current mode. PROG./SET - Enters program or setting mode for CD & tuner mode.
RS2610-EN rev.1 7/23/02 3:11 PM Page 8 Controls and Indicators Remote Control EN TUNER SOURCE TAPE AUX CD B BO EQ OST POWER X-SURROUND VOL NE EV XT PR RE D V FW VOL RECORD STOP MUTE SHUFFLE DISC SKIP INTRO REPEAT FM ST. PRESET DOWN UP SLEEP POWER — Turns the power on and off from Standby mode. CD — Selects CD player. TUNER — Selects radio tuner. TAPE — Selects tape player. AUX — Selects external input. EQ— Selects equalizer presets. B.BOOST — Turns on or off Bass Boost.
RS2610-EN rev.1 7/23/02 3:11 PM Page 9 Display Settings EN Showing the Demonstration Not operational in CD mode. Press DEMO/DIMMER to turn on/off demonstration mode. The demonstration scrolls through all display operations. Display Clock / Timer Setting the Clock 1. Press and hold CLOCK until the hour flashes on the display. 2. Press SKIP FORWARD / SKIP BACKWARD to set the hour and then press CLOCK to shift to minute digits. 3. Press SKIP FORWARD / SKIP BACKWARD to set the minute. 4. Press PROG.
RS2610-EN rev.1 7/23/02 3:11 PM Page 10 Sound Features EN Using Preset Equalizer Curves BASS BOOST Press ROCK/CLASSIC, CUSTOM/FLAT, POP/JAZZ on the main unit or EQ on the remote to toggle among FLAT, ROCK, POP, JAZZ, CLASSIC & CUSTOM. The display shows briefly the selection. Press BASS BOOST to turn on/off boosting the bass frequency. Creating a Custom Curve Press MUTE on the remote to cut the sound. (Remote Only) 1. Press CUSTOM/FLAT on the main unit or EQ on the remote to select CUSTOM mode. 2.
RS2610-EN rev.1 7/23/02 3:11 PM Page 11 CD Player Skipping a Disc Press DISC SKIP. Searching Through a CD Press and hold SKIP FORWARD / SKIP BACKWARD to search through a CD while it is playing. Tip: While playing a CD, press and hold SKIPFORWARD or BACKWARD for more than 2 seconds to search through the CD. Shuffling the Play Order Press SHUFFLE to turn on/off the playing of tracks in random order.
RS2610-EN rev.1 7/23/02 3:11 PM Page 12 Tuner EN Selecting Tuner Manually Setting Presets 1. Press SOURCE to select TUNER. 2. Press BAND to select between FM/AMradio band. Tip: Your audio system has 32 preset stations. Tuning to a Station Press SKIP FORWARD / SKIP BACKWARD to select frequencies. 87.50 MHz Using Presets Suppressing Stereo Signal The tuner can be either TUNE or PRESET mode. When in PRESET mode, the PROG light is on. • Press TUNE/PRESET to toggle between Preset and Tune mode.
RS2610-EN rev.1 7/23/02 3:12 PM Page 13 Tape Player Playing a Tape Tip: You can play a tape from either deck. 1. Press SOURCE repeatedly to select TAPE. 2. Press the cassette door to open it. 3. Insert a tape into the door and push the door closed. 4. Press BAND/DECK 1/2 to select deck 1 or 2. 5. Press SKIP FORWARD / SKIP BACKWARD to position the tape to the desired starting position. 6. Press PLAY to begin playback. Continuous Play 1. Press PRESET UP . on the remote control to enable continuous play.
RS2610-EN rev.1 7/23/02 3:12 PM Page 14 Troubleshooting Tips Problem Solution Problem Solution System will • Check power cord for a secure not turn on connection. • Unplug the unit for a moment, and then plug into power source again. • Check the outlet by plugging in another device. CD button • Switch to another function (TAPE, will not Tuner) and then back to CD. respond, or does not change discs when you press DISC SKIP No sound • Increase the volume setting. • Check connection to speakers.
RS2610-EN rev.1 7/23/02 3:12 PM Page 15 Maintenance Disconnect the audio system from the power source before performing any maintenance. Cleaning Clean the exterior of the system using a soft dust cloth. CD Player Handling CDs EN • Do not touch the signal surfaces. Hold CDs by the edges, or by one edge and the hole. Do not affix labels or adhesive tapes to the label surfaces. Do not scratch or damage the label. CDs rotate at high speeds inside the player.
RS2610-EN rev.1 7/23/02 3:12 PM Page 16 Important Information Safety Precautions Headset Safety • Never open the cabinet under any circumstances. Any repairs or internal adjustments should be made only by a trained technician. • Never operate this product with the cabinet removed. •Do not use your System immediately after transporting it from a cold place to a warm place, as condensation may cause the system to malfunction. • Keep your unit away from humid areas and abnormally hot places.
RS2610-EN rev.1 7/23/02 3:12 PM Page 17 Limited Warranty (U.S.) EN What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase for labor and parts • Warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
RS2610-EN rev.1 7/23/02 3:12 PM Page 18 Limited Warranty (U.S.) Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
RS2610-EN rev.1 7/23/02 3:12 PM Page 19 Limited Warranty (Canada) What your warranty covers: EN • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase for labor and parts • The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
RS2610-EN rev.1 7/23/02 3:12 PM Page 20 Limited Warranty (Canada) Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA LTD., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. • REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON MULTIMEDIA LTD.
