USER INSTRUCTION DSS-R-CL1100 SERIES TABLE OF CONTENTS CHAPTER 1 PRODUCT OVERVIEW ..................................................................... 2 1.0 PRODUCT INTRODUCTION............................................................................................................. 2 2.0 FEATURE AND SPECIFICATION ...................................................................................................... 2 3.0 PANEL LAYOUT ...................................................................
USER INSTRUCTION DSS-R-CL1100 SERIES Chapter 1 Product Overview 1.0 Product Introduction As new generation visual information recording and transmission equipment, characterized by compact size and portability, it integrates the input interfaces of video, audio and DVI signals, supporting random combined recording of one-way DVI or VGA signal, one-way video and one-way audio signal. The recorded file is saved in single-flow mode.
USER INSTRUCTION DSS-R-CL1100 SERIES 2.0.2 Specification Item Definition Technical Index 720p, 1080i 1080p; 640*480, 800*600, 1024*768, 1280*1024 Frame rate Input Signal Loop output Network interface Control interface 1-30 frame/second Analog VGA / digital DVI-I; RCA composite analog video; analog S-Video; RCA analog audio; 1/4” TRS audio 15-pin D model interface (Female) 10/100/1000Mbps Ethernet interface (RJ45) Web interface, Panel display, RS-232 Serial interface, third party control (ex.
USER INSTRUCTION DSS-R-CL1100 SERIES 3.0 Panel Layout 3.0.1 Front Panel As shown in the figure below, press on the front panel of Multimedia Recorder and the unit begins recording. If you want to stop it, press . 3.0.2 LED Name Description POWER it will be ON during normal power-on RUN it will be ON when the system is running LAN it will be ON when there is network connection LCD it will display the operating status and relevant information during operation 3.0.
USER INSTRUCTION DSS-R-CL1100 SERIES Chapter 2 Quick User Guide 1.0 Modify IP Address 1.0.1 Identify IP Address LCD at the front panel shows IP address and subnet mask. 1.0.2 Modify IP Address Reset computer Internet Protocol (TCP/IP). 【Start】→【Control Panel】→【Network Connections】 right click【Local Area Connection】→【Properties】 select【Internet Protocol(TCP/IP)】→【Properties】 select【Use the following IP address】 Entering an IP address (ex: 60.251.158.59; 60.251.158.
USER INSTRUCTION DSS-R-CL1100 SERIES Logout: After you logon to the system, if you click on the page, you will be logged out of the system management or client interface. And your logout will not affect the operation of the server, and the current working information of the server will be provided as soon as you logon to the system next time. Re-logon: if you click system logon interface.
USER INSTRUCTION DSS-R-CL1100 SERIES After entering valid IP address, subnet mask and default gateway, click . The new IP address will take effect after the server restarts. 2.0. Preview 2.0.1 Plug-in Installation If you have never installed this monitoring software to your computer, the system will prompt you to install it after you logon to Multimedia Recorder interface.
USER INSTRUCTION DSS-R-CL1100 SERIES 2.0.2 Interface Layout The default interface of the Multimedia Recorder will be displayed after installation of the plug-in software. The left upper section is the video play control field. The right upper section is the file list play and download field. The bottom section is the parameter view and setting field. Click , in the parameter view and setting field will be shown as below. Instant viewing is available by clicking [Preview]. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 3.0. Quick Recording 3.0.1 LCD Panel Quick Recording As shown in the figure below, press upper button on the front panel of Multimedia Recorder and the unit begins recording. If you want to stop it, press lower button . This function is very convenient, for it can record easily even if Multimedia Recorder is not connected to the network. 3.0.2 WEB Recording Mode Click , then the current state of recorded documents will display at the right section of the page.
USER INSTRUCTION DSS-R-CL1100 SERIES Chapter 3 Installation and Configuration 1.0 System Information Click the [Advanced] button on the home page, and then the server's system information can be viewed on the prompted new page. 2.0 Parameters Setting 2.0.
USER INSTRUCTION DSS-R-CL1100 SERIES Video Mode: D1 (large) / CIF (medium) / QCIF (small) Ps. the following suggested logo resolution is based on VGA resolution 1024 x 768 1. D1 (large) Suggested logo resolution 753 x 304 2. CIF (medium) Suggested logo resolution 535 x 730 3. QCIF (small) Suggested logo resolution 266 x 946 www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 2.0.2 Video Bit Rate Setting Display the current video mode setting information, as shown in the following figure, the higher the bit rate, the better the quality video. Rate Mode: 128 ~ 20000kbps Quality Mode: 10 ~ 90 Video Frame Rate: 1 ~ 30 2.0.
USER INSTRUCTION DSS-R-CL1100 SERIES 2.0.5 Image Adjust As shown in the figure below, press source. Click to correct green screen of VGA for adjusting color of VGA source. 2.0.6 Control As shown in the figure below, press to control video source viewing position or direction including up/down, right/left, zoom in and zoom out. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 3.0 Record 3.0.1 LCD Panel Quick Recording As shown in the figure, press on the front panel of Multimedia Recorder, the unit begins recording. If you want to stop it, press . This function is very convenient, for it can record easily even if Multimedia Recorder is not connected to the network. 3.0.2 WEB Recording Mode Click , then the current state of recorded documents will display at the right of the page.
USER INSTRUCTION DSS-R-CL1100 SERIES 4.0 File Management 4.0.1 File List All the file lists are displayed in the upper right of the main interface. In this dialog box, you can view the file information and perform such operations as renaming files, playing on demand files, downloading files, and deleting files, as shown in the following figure: To delete the file stored in the server, please select the file in the list, click and then click [OK] in the prompted confirmation dialog box.
USER INSTRUCTION DSS-R-CL1100 SERIES 5.0.2 Authority Maximum number of users that can simultaneously preview and download online is 5. 5.0.3 Multicast Management Turn On / Turn Off the multicast function. Multicast Content can’t be viewed via INTERNET. It’s available over Intranet because it’s point to point service. Multicast Address: 234.3.4.5 Multicast Port Number: 11000 5.0.4 PTZ Protocol Upgrade Unless it's necessary, please do not update PTZ Protocol. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 5.0.5 FTP configuration Type in FTP server’s IP address, port, username and password, and choose [allow to upload]. After you active this function, the system will transmit the recorded file automatically to FTP server, as soon as the recording completed. 6.0 System Restart Stop file recording first before restarting server, or system will stop file recording automatically. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 7.0 User Management 7.0.1 Modify password Change password: Designated user’s system login password can be easily changed by clicking [Modify] button. 7.0.2 Add new user Click [Add new user], enter the user’s name and password, and then click [Save] www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 7.0.3 User authorities The administrator may authorize the common user to play on demand or download files at any time. Click [Detail] button to view all the files stored in the server, and select and set the related play on demand / download authorities in the list. 7.0.4 Delete user In the user list dialog box, click the corresponding user and select [Delete] button, and then click [OK] in the prompted confirmation dialog box.
USER INSTRUCTION DSS-R-CL1100 SERIES 7.0.6 Guest user (This function will be temperately disable.) Both user name and password are [guest]. Click [Multicast] to preview data. Multicast Content can’t be viewed via INTERNET. It’s available over Intranet because it’s point to point service. NOTE: Broadcast function will require more bandwidth and transmit data among members in local area network. NOTE: Guest can only view multicast after administrator turn on the function. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES Chapter 4 WMS - Windows Media Server (Optional Function) Thank you for purchasing DSS-R-CL1100 Multimedia Recorder. Please read this document in detail so that you can understand and implement the required function of the system. WMS Address: Windows Media Server's media server address. The text of User Name and Password keep nil. Click [Turn On] and send the signal collected by the DSS-R-CL1100 Multimedia Recorder Server to the Media Server.
USER INSTRUCTION DSS-R-CL1100 SERIES (2) Enter IIS to modify FTP IP Address Right click [FTP] → [Rec] → [Properties] www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES 2. DSS-R-CL1100 Multimedia Recorder (1) Modify [WMS Address] (2) Modify [FTP Configuration] server upload address http://60.251.158.111:6066/meicheng Note: before clicking the [Turn On] button, please make sure if the Windows Media Service server is configured well and if the site release parameters are correct. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES Brief Introduction to WMS Parameter Settings (1) Add release site on the Windows Media Server: [Start Menu] -> [ All Programs] -> [Administrative Tools] -> [Windows Media Services] (2) Right-click on [Publishing Points] on the left menu -> [Add a Publishing Point (Advanced)] www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES (3) Set publishing point parameter meicheng [Publishing point type]: Broadcast [Publishing point name]: meicheng (it should be the same with we set in DSS-R-CL1100 Multimedia Recorder), here is meicheng [Location of content]: must be PUSH:* [Content type examples]: choose Encoder (push) in. Click OK. www.meicheng.com.
USER INSTRUCTION DSS-R-CL1100 SERIES (4) Set WMS port and user authority Click Properties, Control protocol, set the parameters of WMS HTTP Server Control Protocol, set the port here 6066 (it should be the same with we set in DSS-R-CL1100 Multimedia Recorder) 6066 Note: after changing any parameters of DSS-R-CL1100 Multimedia Recorder signal source, the receiving client is required to reconnect the connection with the media server.
USER INSTRUCTION DSS-R-CL1100 SERIES (5) Windows Media Server's media server address: http://servers IP address:6066/meicheng http://60.251.158.111:6066/meicheng (6) Use MediaPlayer to view content. http://60.251.158.111:6066/meicheng Note: after changing any parameters of DSS-R-CL1100 Multimedia Recorder Server signal source, the receiving client is required to reconnect the connection with the media server. For the client receiving, it is recommended to use versions above Windows Media Player 10.
USER INSTRUCTION DSS-R-CL1100 SERIES The following items are contained in shipping carton: 1. 2. 3. 4. 5. 6. 7. 8. DSS-R-CL1100 x1 Power Cable x1 RS-232 Cable x1 DVI Cable (male/male) x1 DVI (female) to VGA (male) adapter x1 LAN Cable x1 RCA Audio Cable x1 RCA/3.5mm Audio Cable x1 9. User Manual x1 10. User Manual CD Document x1 If the enclosed item(s) were damaged, please contact Meicheng immediately: TEL : +8862-8228-0311 E-mail : mei.cheng@msa.hinet.net www.meicheng.com.
