User manual

4 Specifications
Main Chipset Atheros INT6400
Computer Interface IEEE802.3 ; IEEE802.3u
Data PHY Rate Up to 200 Mbps
Standards HomePlug AV
Network Interface One RJ-45 (10/100Base-T Ethernet)
One 200Mbps Power Line Port supporting co-existence with HomePlug 1.0
(14/85Mbps)
Security 128-bit AES Link Encryption with Key Management
Frequency Band 2-28 Mhz
Modulation Schemes OFDM Symbol Modulation on Line synchronization
1024/256/64/16/8—QAM, QPSK, BPSK, ROBO Carrier Modulation
Additional Protocols
Mix of TDMA and CSMA/CA channel access scheme; CO device generates a
periodic beacon carrier for channel access scheme
Operation Range Estimated range of 300 meters in wall power lines
Cabling 100Base-T; Cat. 5 UTP Cable
Operating Temperature
0° C to 40° C ambient temperature
Storage Temperature
-20° C to 70° C ambient temperature
Humidity
10% to 90% maximum (non-condensing)
Power Input 100 ~ 240V @ 50/60Hz Internal
Housing Plastic (98mm x 63mm x 28mm)
Status Lights Power: On/Off
PLC(Powerline) Link: Red/Orange/Green/Off
Ethernet Link: Solid/Blinking/Off
Certifications HomePlug AV Powerline Certification
FCC Class B / CE Mark
