Specifications

Dimensions
Downrod A B C D
1.00ODX4.50 17.00 13.00 10.25 6.25
AvailableFinishes
Finish Fixture Glass Blade1 Blade2
ProductInformation
Finish BrushedNickel
BladeFinish Black/Silver
Specifications
NumberofBlades 5
BladesIncluded Yes
BladePitch 13Degrees
BladeSweep 52"
BladesReversible No
BladeMaterial WOOD
OptionalBladesAvailable No
Downrod1 1.00ODX4.50
PrimaryControlSystem
3SpeedWallControlLtd
Function
RemoteIncluded No
WallControlIncluded Yes
LowCeilingAdaptable No
LeadWireLength 78.00"
MotorSize 172MMX20MM
MotorType AC
Downlight
DownlightIncluded Yes
LightSource LED
DownlightBulbIncluded Integrated
DownlightBulbType LED
NumberofLights/LEDs 1
Watts 70/11
InitialLumens 1600
GlassDescription EtchedCasedOpal
OptionalLightKitAvailable No
KelvinTemperature 3000K
ColorRenderingIndex 80
SafetyListings&Certifications
Installation
Theelectricaljunctionbox
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
ProjectName:
Location:
Type:
Qty:
Comments:
Notes:
1)Informationprovidedissubjecttochangewithoutnotice.
Allvaluesaredesignortypicalvalueswhenmeasuredunder
laboratoryconditions.
2)IncandescentEquivalent:Theincandescentequivalentas
presentedisanapproximatenumberandisforreferenceonly.
52InchLEDCeilingFan
(BrushedNickel)
SafetyRated Dry
Warranty
