Assembly Instruction

ManualsBrandsRed Barrel Studio Manuals4 Seat Kitchen & Dining TablesKeanna Contemporary Counter Height Solid Wood Dining Table

ASSEMBLY RATING







 



O O





Tools Required For Assembly:



�

(Included) 





(Not Included)

2 PERSONS RECOMMENDED

Page 1 of 7

ASSEMBLY INSTRUCTION

Summary of content (7 pages)

PAGE 1
ASSEMBLY INSTRUCTION ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
PAGE 2
ASSEMBLY & CARE ADVl CE 1 FOR YOUR FURNITURE TO LAST.CORRECT ASSEMBLY AND PROPER MAINTENANCE ARE NECESSARY. PLEASE FOLLOW THE INFORMATION PROVIDED BELOW TO FULLY ENJOY YOUR FURNITURE. BASIC ASSEMBLY TECHNIQUES When lock or spring washer is used in an assembly, please make sure the lock or spring washer is placed between the larger flat washer and the head of the screw or bolt.
PAGE 3
PAGE 4
I. With the help of another person, carefully place the table top (#1) facing down on a protected surface. II. Insert two legs (#3) into the designated slots located under the table top (#1). III. Insert the shelf (#2) into the slots located along the sides of the legs (#3).
PAGE 5
Insert the third leg (#3) into the designated slot located under the table top (#1), as well as inserting it into the the shelf (#2). Make sure all parts are firmly secure.
PAGE 6
I. Prepare 6 bolt assemblies by FIRST inserting the lock washer (#B) onto the bolt (#A) and the the flat washer (#C) onto that SAME bolt (#A), in that order. II. Insert prepared bolt assemblies into the center pre-drilled holes and secure using the Allen wrench (#D).
PAGE 7
I. Align the bass L (#F) with the pre-drilled holes on the corners where the shelf (#2) and legs (#3) meet. II. Insert screws (#E) and secure using a Phillips screwdriver. Repeat with remaining screws (#E). III. Carefully turn the completed table upright. Make sure the table is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts are secured and properly tightened.
