505645 LAF CHAISE

SECTIONAL

This sectional has a reversible chaise, and it

can be assembled on the left or right side as

needed. The assembly instructions below refer

to the chaise on the LEFT SIDE, as you are

facing the sectional.

1a of 5a

(LAF Chaise)

ASSEMBLY INSTRUCTION

Summary of content (5 pages)

PAGE 1
(LAF Chaise) SECTIONAL This sectional has a reversible chaise, and it can be assembled on the left or right side as needed. The assembly instructions below refer to the chaise on the LEFT SIDE, as you are facing the sectional.
PAGE 2
CHAISE ( LAF) ASSEMBLY INSTRUCTION PARTS IDENTIFICATION M F E C B A I H D D A CHAISE SEAT FRAME 1PC B 1PC CHAISE ARM FRAME Z HARDWARE PACKAGE NO DESCRIPTION FIGURE C D CHAISE BACK FRAME LEG 1PC 2PCS 1 SMALL SCREW 2 LARGE SCREW 3 LOCK WASHER 6PCS+1PC SPARE 4 FLAT WASHER 6 PCS+1PC SPARE 5 ALLEN KEY 1-3 8" 4PCS E BACK CUSHION 1PC F CHAISE LEFT BACK CUSHION 1PC M CHAISE RIGHT BACK CUSHION 1PC G 1PC PILLOW QTY H CHAISE SMALL SEAT CUSHION 1PC I CHAISE LARGE SEAT CUS
PAGE 3
CHAISE ( LAF) STEP 1 2 4 ASSEMBLY INSTRUCTION STEP 2 3 5 X4 X4 X4 X1 1 4 3 5 X2 X2 X2 X1 A C B 2 A 3 4 5 5 STEP3 1 3 4 STEP 4 Remove the 4 legs that are packed in the corner of the wooden frame as shown in the image M F E Attach the legs onto the chaise and turn tightly to secure D D D D I D 3a of 5a H
PAGE 4
SOFA ( RAF) ASSEMBLY INSTRUCTION PARTS IDENTIFICATION E J N K D D D Z HARDWARE PACKAGE J SOFA BACK FRAME 1PC K SOFA SEAT FRAME 1PC L SOFA ARM FRAME 1PC 1 SMALL SCREW D LEG 4PCS 2 LARGE SCREW E BACK CUSHION 3PCS 3 LOCK WASHER 6PCS+1PC SPARE 4 FLAT WASHER 6 PCS+1PC SPARE 5 ALLEN KEY G PILLOW 1PC N SEAT CUSHION 3PCS NO DESCRIPTION FIGURE 4a of 5a QTY 2PCS 1-3 8" 4PCS 2-3 16" 1PC
PAGE 5
SOFA ( RAF) ASSEMBLY INSTRUCTION STEP 1 2 4 STEP 2 3 5 X4 X4 1 4 X4 X1 3 5 X2 X2 X2 X1 K L J 3 K 4 5 2 5 STEP 3 1 3 4 STEP 4 Remove the 4 legs that are packed in the corner of the wooden frame as shown in the image D E D D J D D N K D Attach the legs onto the sofa and turn tightly to secure D D 5a of 5a
