Frame Body
None
Response
The second 16-bit word of the descriptor (W1[15:0]) of the received
packet is used to identify the frame‟s success or failure. A value of „0‟ for the
W1[15:0] is interpreted as a success and a non-zero value is interpreted as a
failure. The reason for the init failure is also indicated by the non-zero value of
this byte.
4.9.3 Scan
Description
This request makes the module scan in the channel specified. If the user wants
to join a hidden Access Point (SSID not being broadcast), the SSID of the Access
Point is passed as the parameter. Otherwise the SSID field is NULL („\0‟).
Relevance
This command is relevant both when the TCP/IP stack is enabled or bypassed.
Frame Body
The structure and description of the scan request structure is as follows.
struct WiFi_CNFG_Scan
{
UINT32 uChannelNo;
UINT8 uSSID[32];
UNIT8 pScan_bitmap
1
[4];
};
Structure Member
Name
Description
uChannelNo
Channel Number of the Access Point.
This value can be one of many values,
as listed.
uSSID
SSID of the Access Point. To be
used to scan hidden SSIDs or a
specific known SSID. For
example, if the user wants to scan
an SSID “Test_Network” in
1
In versions earlier than 4.7.x, this field was not present. Users can use the earlier
structure without this field and the original scanning process will not be affected.
