Send : ff Dummy Recv : 58
Send : 00 Dummy Recv : 58
Send : c0 Dummy Recv : 58
Send : a8 Dummy Recv : 58
Send : 01 Dummy Recv : 58
Send : 01 Dummy Recv : 58
Send : 00 Dummy Recv : 58
wait for interrupt
Interrupt received, Do master read
Read descriptor
Send : 5c Recv : 00
Send : 00 Recv : 58
Send : 10 Recv : 58
Send : 00 Recv : 58
Wait for start token
Send : Dummy 00 Recv : 58
Send : Dummy 00 Recv : 58
Send : Dummy 00 Recv : 55
Send : Dummy 00 Recv : 18
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 02
Send : Dummy 00 Recv : 00
Read the payload
Send : 5c Recv : 00
Send : 00 Recv : 58
Send : 18 Recv : 58
Send : 00 Recv : 58
.....................................
..................................... continue till start token is received
Send : Dummy 00 Recv : 58
Send : Dummy 00 Recv : 58
Send : Dummy 00 Recv : 55
Send : Dummy 00 Recv : 01 .... IPconfig command response code
Send : Dummy 00 Recv : 00
Send : Dummy 00 Recv : 00 ....
Send : Dummy 00 Recv : 23
Send : Dummy 00 Recv : a7
Send : Dummy 00 Recv : 1d 6 Bytes MAC address
Send : Dummy 00 Recv : 0a
Send : Dummy 00 Recv : 6d ....
Send : Dummy 00 Recv : c0 ....
Send : Dummy 00 Recv : a8
Send : Dummy 00 Recv : 01 IP address
Send : Dummy 00 Recv : 78 ....
Send : Dummy 00 Recv : ff ....
Send : Dummy 00 Recv : ff
Send : Dummy 00 Recv : ff Subnet mask
Send : Dummy 00 Recv : 00 ....
Send : Dummy 00 Recv : c0 ....
