INFRASTRUCTURE/IBSS is sent as an ASCII string.
type: 0 indicates IBSS Joiner and 1 indicates IBSS Creator
chan_num: Indicates the channel in which the IBSS network has to be created.
If the module is intended to be an ad-hoc joiner, this field can be set to „0‟ or to
the specific channel in which the creator is present.
For 2.4 GHz
Actual
Channel
Number
chan_num
parameter
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
For 5 Ghz
Channel
Number
chan_num
parameter
36
1
40
2
44
3
48
4
52
5
56
6
60
7
64
8
100
9
104
10
108
11
112
12
116
13
120
14
124
15
128
16
