Parameters
bitval - Note that the default values of the bits described below is „0‟.
Bit[0] – „1‟ - Add DNS Server Address to the Response for Network Param
Query command. This command is not used for DNS configuration, it is
used to query DNS parameters using the at+rsi_nwparams command
„0‟ – Do not add DNS Server Address to the Response for Network Param
Query.
Bit[1:2] – Always set to all „0‟
Bit[3] –
„1‟- 63 byte mode enabled for WPA/WPA2-PSK. Keys that are equal to or
less than 63 bytes are accepted in the at+rsi_psk command in this mode.
„0‟ – Only 32 byte mode enabled for WPA/WPA2-PSK. Keys that are equal
to or less than 32 bytes are accepted in the at+rsi_psk command in this
mode. Note: Even if this bit is not set to „1‟, a PSK of less than or equal to
63 bytes will work successfully while associating to an access point, but
there will be a wrong length of PSK returned in the command
at+rsi_nwparams. It is advisable to set the bit to „1‟ if the
at+rsi_nwparams is planned to be used.
Bit[4:6] – Always set to all „0‟
Bit[7] – If this bit is set to „1‟, the WEP authentication mode,WEP
index,WEP keys(2,3,4) are returned in at+rsi_cfgget? command.
Bit[8] – Always set to „0‟
Bit[9] – Always set to „0‟
Bit[10]- LED in RS9110-N-11-22-04/05 modules is disabled if this bit is
set to „1‟. The LED will stop glowing after the at+rsi_init command is
issued.
Bit[11]- Controls the relevance of the command at+rsi_authmode.
This command can be issued after the at+rsi_band command. The
decimal value of the bitval word is supplied as the input as shown in the
example below. If the command is not issued, the default value of this
parameter in the system would be „0‟. The command is not applicable in
IBSS mode.
Example 1: To turn off the LED to save current consumption, the word for
bitval is “1 00000 00000‟, the decimal value of which is 1024.
at+rsi_feat_sel=1024\r\n
………………………………………………..
0x61 0x74 0x2B 0x72 0x73 0x69 0x5F 0x66 0x65 0x61 0x74 0x5F
0x73 0x65 0x6C 0x3D 0x31 0x30 0x32 0x34 0x0D 0x0A
Response
