3. Click on the “Get Configuration” button. It displays the currently
stored configuration parameters. These parameters can be ignored
for now.
4. Fill the values of the parameters
a. Channel: Channel number of the AP or Adhoc network that
the module should connect to. Refer tables Channel
Number Parameter (2.4 Ghz) and Channel Number
Parameter (5 Ghz).
b. Network Type
c. Security Mode- Security mode of the Access Point or Adhoc
network
d. uRate (refer table Data Rate Parameter)
e. Tx Power
f. Pre shared key- This can be left unfilled if the security
mode is “Open”.
g. SSID- This is the SSID of the Access Point or Adhoc
network to which the module should join
h. IBSS mode (Adhoc)- Set it to “Joiner” is NetworkType is
IBSS
i. uChannel- this field can be ignored
j. DHCP Enable/Disable- Used in infrastructure mode
k. Source IP Address, Source Subnet Mask, Source Gateway
Address: If DHCP is disabled, an IP address, subnet mask
and gateway address should be entered for “Source IP
Address”, “Source Subnet Mask” and “Source Gateway”
respectively. The module will get configured with these
parameters.
l. Feature Bitmap- The decimal value of the parameter bitval
of the command Feature Select can be entered here. It can
be set to „0‟ for most use cases.
m. Auth mode- If “WEP” is selected in “Security Mode”, then
the options of “WEP Open” or “WEP Shared” should be used
here.
5. Click on the button “Set Configuration”. The configuration
information is stored in non-volatile memory of the module and
can be accessed by the Host at any time using the at+rsi_cfgget
command.
6. The GUI will send the message “Configure Success”. The module
sends the message “AT+REMOTE_CFG” to the Host
1
PC (P). Once
the message is received, the module can be power cycled or hard
reset. The module sends the message – “Firmware upgrade
1
The message is sent in uppercase alphabets
