User’s Manual H8/36912, H8/36902 Group DP-32S User System Interface Cable for E6000 Emulator HS36902ECS61HE User’s Manual HS36902ECS61H Renesas Microcomputer Development Environment System H8 Family / H8/300H Tiny Series Rev.1.00 2004.
Keep safety first in your circuit designs! 1. Renesas Technology Corp. puts the maximum effort into making semiconductor products better and more reliable, but there is always the possibility that trouble may occur with them. Trouble with semiconductors may lead to personal injury, fire or property damage.
IMPORTANT INFORMATION READ FIRST • READ this user's manual before using this user system interface cable. • KEEP the user's manual handy for future reference. Do not attempt to use the user system interface cable until you fully understand its mechanism. User System Interface Cable: Throughout this document, the term "user system interface cable" shall be defined as the following product produced only by Renesas Technology Corp. excluding all subsidiary products.
LIMITED WARRANTY Renesas warrants its user system interface cables to be manufactured in accordance with published specifications and free from defects in material and/or workmanship. Renesas will repair or replace any user system interface cables determined to be defective in material and/or workmanship. User system interface cables are wearing parts which Renesas will not repair or replace if damaged and/or worn through use.
State Law: Some states do not allow the exclusion or limitation of implied warranties or liability for incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which may vary from state to state.
SAFETY PAGE READ FIRST • READ this user's manual before using this user system interface cable. • KEEP the user's manual handy for future reference. Do not attempt to use the user system interface cable until you fully understand its mechanism. DEFINITION OF SIGNAL WORDS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
WARNING Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1. Do not repair or remodel the emulator product by yourself for electric shock prevention and quality assurance. 2. Always switch OFF the E6000 emulator and user system before connecting or disconnecting any CABLES or PARTS. 3.
Preface Thank you for purchasing this user system interface cable (HS36902ECS61H) for the Renesas’ original microcomputer H8/36912, H8/36902 group. The HS36902ECS61H is a user system interface cable that connects an H8/36912, H8/36902 group E6000 emulator (HS3664EPI61H or HS3664EPI62H; hereinafter referred to as the emulator) to the IC socket for a DP-32S package for the H8/36912, H8/36902 group MCU on the user system.
Contents Section 1 Configuration.....................................................................................1 Section 2 Connection Procedures ......................................................................3 2.1 2.2 2.3 2.4 Connecting User System Interface Cable to Emulator Station ......................................... 3 Connecting User System Interface Cable to User System ................................................ 5 2.2.1 Installing IC Socket ....................................
Section 1 Configuration CAUTION Use an IC83-3204-GS4 socket (manufactured by YAMAICHI ELECTRONICS Co., Ltd.) for the DP-32S package IC socket on the user system. Figure 1 shows the configuration of the HS36902ECS61H user system interface cable for the DP-32S package. To emulator station CTS screws (M3 x 6 mm) for fastening the emulator station Cable body Cable head IC socket (IC83-3204-GS4 manufactured by YAMAICHI ELECTRONICS Co.,Ltd.
Table 1 lists the HS36902ECS61H components. Please make sure you have all of these components when unpacking. Table 1 HS36902ECS61H Components No.
Section 2 Connection Procedures 2.1 Connecting User System Interface Cable to Emulator Station WARNING Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1. Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part.
Emulator station 0 00 E6 Cable body connector CTS screws (M3 x 6 mm) User system interface cable Figure 2 Connecting User System Interface Cable to Emulator Station 4
2.2 Connecting User System Interface Cable to User System WARNING Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part. Before connecting, make sure that pin 1 on both sides are correctly aligned. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST.
Pin 1 Cable head IC socket (IC83-3204-GS4 manufactured by YAMAICHI ELECTRONICS Co., Ltd.
2.2.3 Fastening Cable Body Connect the cable body to the cable head. Removing Cable body Push the two remove jigs.
2.3 Dimensions for User System Interface Cable Head The dimensions for the user system interface cable head are shown in figure 5. 76.2 12.7 18.4 31.75 29.2 66.0 Unit: mm Tolerance: ±0.
2.4 Resulting Dimensions after Connecting User System Interface Cable The resulting dimensions, after connecting the user system interface cable head to the user system, are shown in figure 6. 29.2 IC socket (for protection) (IC83-3204-GS4 manufactured by YAMAICHI ELECTRONICS Co., Ltd.) 12.3 Cable head User system IC socket (IC83-3204-GS4 manufactured by YAMAICHI ELECTRONICS Co., Ltd.) Unit: mm Tolerance: ±0.
Section 3 Verifying Operation 1. Turn on the emulator according to the procedures described in the H8/3664 E6000 Emulator User’s Manual (HS3664EPI61HE-U2 or HS3664EPI62HE-U2). 2. Verify the user system interface cable connections by accessing ports and checking the bus states of the pins. If an error is detected, recheck the soldered IC socket and the location of pin 1. 3.
Figure 7 shows the system clock oscillator on the user system interface cable and the subclock input specifications. R5 3.3 MΩ R1 1 MΩ HCU04 HCU04 OSC1 R13 10 kΩ R12 2.
Section 4 Notice 1. Make sure that pin 1 on the user system IC socket is correctly aligned with pin 1 on the cable head before inserting the cable head into the user system IC socket. 2. The dimensions of the recommended mount pad for the user system IC socket are different from those of the MCU. 3. This user system interface cable is specifically designed for the HS3664EPI61H or HS3664EPI62H emulator. Do not use this cable with any other emulator station. 4.
7. SW1 and SW2 are used to switch OSC2 or PC1 and OSC1 or PC0. Turn SW1 and SW2 to the OSC1 and OSC2 sides, respectively, when they are used as OSC1 and OSC2. Turn SW1 and SW2 to the PC0 and PC1 sides, respectively, when they are used as PC0 and PC1. At shipment, SW1 and SW2 are turned to the OSC1 and OSC2 sides. The emulator does not support the internal RC-oscillation clock function.
