Instructions / Assembly

Platform Bed

Assembly Instructions

Contains One Bed and Hardware

STEP 4

STEP 5

ASSEMBLY INSTRUCTIONS (CONTINUED)

A A

Roll out the Wood Slat System (Part F) and secure it in place

using nine 32mm Screws (Part N). Use the pre-drilled holes

and a screwdriver.

Insert the Center Rail (Part E) into the brackets on the

Headboard and Footboard. Using a screwdriver, secure the

center rail using two 16mm Screws (Part M).

PAGE 1
ASSEMBLY INSTRUCTIONS (CONTINUED) STEP 4 Platform Bed Assembly Instructions E Contains One Bed and Hardware E M Insert the Center Rail (Part E) into the brackets on the Headboard and Footboard. Using a screwdriver, secure the center rail using two 16mm Screws (Part M). STEP 5 F N Roll out the Wood Slat System (Part F) and secure it in place using nine 32mm Screws (Part N). Use the pre-drilled holes and a screwdriver.
PAGE 2
IMPORTANT NOTE: ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: Carefully remove all the parts from the box. Arrange on a flat surface and verify you have all of the following parts and hardware. Phillips Screwdriver STEP 1 PARTS LIST A2 A1 A. Headboard Top (1 pc) B. Footboard (1 pc) C. Side Rail (2 pcs) A2 K A1 H A1 D D. Leg (4 pcs) I E. Center Rail (1 pc) J Assemble the Legs (Part D) to the Headboard (Part A1) by turning the Legs clockwise until tight.
