connect the VGA port inside the back shell with the VGA of PC end by a VGA cable,

and connect PC-USB with PC-TOUCH by an USB cable. Press the POWER button,

the power indicator light turns red and the IQTouchScreen is in standby mode, and

then press ON/OFF button on the controller or the front key board of the machine, the

power indicator light turns green and images will be shown on screen in several

seconds.

For the IQTouchScreen with built-in PC, the channel will be set to PC source by

default. Please press PC Power to turn on PC and show the images.

If you don’t want PC images when turning on IQTouchScreen, you can set the OSD

input manually (Refer to 7.1 Input Source.).

4.3 Turn off Power

Press ON/OFF button to make the machine into standby mode, shut down I/O switch,

pull out the power plug from the power socket.

For the IQTouchScreen with built-in PC, please also press PC Power to turn off PC .

Attention

If you will not use the machine for long time, please turn off the power, and pull out the

power plug from the power socket.

4.4 Back Shell TV port

Attentions

● Be careful when connecting to other devices.

● Please read the manual of the external devices carefully before connecting with

the machine.

● Make sure the machine in power-off mode when connecting other devices and the

correct input and output connection is required.
