Operating Guide

www.rev-a-shelf.com
37
WASTE
CONTAINERS
19"
482 mm
9"
230 mm
18
3
/4"
475 mm
CONTAINER
DIMENSIONS
The Rev-A-Shelf recycling center is the ideal waste container for the environmentally conscious with four divided sections for
plastic, glass, metal and paper…and it’s now available with Compagnucci Aluminum Slides. The 5349-9WM Series is available
in your choice of three color-coded or three white 25 Qt. polymer containers for plastic, glass and metal with a canvas bag for
paper items. This Recycle Center features heavy-duty brushed aluminum soft-closing slides that provide exceptional support
and stability eliminating that side-to-side movement and a fully adjustable door mount frame.
5349-9WM-W White Recycle Center 19⁄" (507 mm)W x 21⁄" (557 mm)D x 20½" (521 mm)H Polymer 1 23 lbs. $497.35
5349-9WM-C Tri-Color Recycle Center 19⁄" (507 mm)W x 21⁄" (557 mm)D x 20½" (521 mm)H Polymer 1 23 lbs. $497.35
5345-DM-KIT-52 Door Mount Extenders Chrome 1 2 lbs. $37.85
6770-11-52 Replacement Canvas Bags Canvas 1 2 lbs. $24.65
9700-60*-52 Replacement Containers * = Y-Yellow, G-Green, B-Blue or W-White Polymer 1 5 lbs. $24.80
Pullout Waste Recycling Center Individual Pack
SET PER WEIGHT PER SUGGESTED
PRODUCT #'s DESCRIPTION PRODUCT DIMENSIONS FINISH CARTON CARTON LIST PRICE
5349-9WM-C with International Recycling Colors
5349-9WM-W with White Containers
NOTES:
100# Weight Rating
**Container Colors - W=white, C=multi-colored (B=blue, G=green, Y=yellow)
5345 Door Mount Extenders SOLD SEPARATELY!
CONTAINS:
Complete with (3) polymer containers (25 Qts.) and (1) washable canvas bag (18 Qts.), heavy duty full-extension slides, frame and mounting screws. Fully Assembled
5349-9WM SERIES PREMIERE RECYCLE CENTER
Container Capacity: 25 Qt. Ea.
Canvas Bag Capacity: 18 Qt.
Minimum
Cabinet Opening
20
1
/8" 512 mm
1
1
/2" Counter top
Overhang
Canvas Bag
Plastic
Glass
Metal
Door mount extenders
sold separately.
You asked for it .... delivered!
These items feature soft-close! The same smooth sliding, heavy-duty slides you expect from
Rev-A-Shelf, with a cutting-edge soft-close design.
Go Green!
19⁄"
507 mm
20½"
521 mm
21⁄" 557 mm
