User Guide

Connecting your UC 1500
1. Take the UC 1500 Base Unit and Dialer out of the box.
2. Connect the Dialer to the Base Unit, making sure to connect the
cable in the dialer only port on the bottom of the UC 1500.
3. Using the provided Ethernet cable, connect the UC 1500 to an
Ethernet jack providing power over Ethernet (PoE) and the bottom
of the UC 1500. The UC is powered via Ethernet; alternatively, we
offer an optional PoE adapter if no PoE is provided in your system.
4. When booting up, the LEDs on the UC 1500 will change between
red, green, and orange lights. When the UC 1500 is ready to use,
the LEDs will display solid green lights and the device will emit a
chime.
5. Follow the instructions on the Extension Microphones guide to connect the additional microphones.
Connecting the UC 1500 to the VoIP Network:
There are multiple ways to configure the UC 1500 to your network:
1. Via Dialer:
a. Press the Menu Button on the Dialer
b. Navigate to and Select the Settings Option
c. Select VoIP Settings
d. Configure the items in this menu per your call manager configuration
e. For initial administrator password, use 7386.
f. Reboot the system. On successful configuration, the display will show the phone number
associated with the line.
Contents
• 1 Base Unit
• 1 Dialer Unit
• 1 USB Cable, 6.56ft (2.0m)
• 1 Ethernet Cable, 25ft(7.62m)
• 1 Extension Microphone Kit
with 2 extension mics and
cables
• Quick Start Guide
