Technical data

Manual – Gear Units and Gearmotors
189
10
Lubricants
Design and Operating Notes
Parallel shaft
helical (F) gear
units
F.., FA..B, FH..B, FV..B
FF..
FA.., FH.., FV.., FAF.., FAZ.., FHF.., FHZ.., FVF.., FVZ.., FT..
Gear unit
Fill quantity in liters
M1 M2 M3 M4 M5 M6
F..27 0.60 0.80 0.65 0.70 0.60 0.60
F..37 0.95 1.25 0.70 1.25 1.00 1.10
F..47 1.50 1.80 1.10 1.90 1.50 1.70
F..57 2.60 3.50 2.10 3.50 2.80 2.90
F..67 2.70 3.80 1.90 3.80 2.90 3.20
F..77 5.9 7.3 4.30 8.0 6.0 6.3
F..87 10.8 13.0 7.7 13.8 10.8 11.0
F..97 18.5 22.5 12.6 25.2 18.5 20.0
F..107 24.5 32.0 19.5 37.5 27.0 27.0
F..127 40.5 54.5 34.0 61.0 46.3 47.0
F..157 69.0 104.0 63.0 105.0 86.0 78.0
Gear unit
Fill quantity in liters
M1 M2 M3 M4 M5 M6
FF27 0.60 0.80 0.65 0.70 0.60 0.60
FF37 1.00 1.25 0.70 1.30 1.00 1.10
FF47 1.60 1.85 1.10 1.90 1.50 1.70
FF57 2.80 3.50 2.10 3.70 2.90 3.00
FF67 2.70 3.80 1.90 3.80 2.90 3.20
FF77 5.9 7.3 4.30 8.1 6.0 6.3
FF87 10.8 13.2 7.8 14.1 11.0 11.2
FF97 19.0 22.5 12.6 25.6 18.9 20.5
FF107 25.5 32.0 19.5 38.5 27.5 28.0
FF127 41.5 55.5 34.0 63.0 46.3 49.0
FF157 72.0 105.0 64.0 106.0 87.0 79.0
Gear unit
Fill quantity in liters
M1 M2 M3 M4 M5 M6
F..27 0.60 0.80 0.65 0.70 0.60 0.60
F..37 0.95 1.25 0.70 1.25 1.00 1.10
F..47 1.50 1.80 1.10 1.90 1.50 1.70
F..57 2.70 3.50 2.10 3.40 2.90 3.00
F..67 2.70 3.80 1.90 3.80 2.90 3.20
F..77 5.9 7.3 4.30 8.0 6.0 6.3
F..87 10.8 13.0 7.7 13.8 10.8 11.0
F..97 18.5 22.5 12.6 25.2 18.5 20.0
F..107 24.5 32.0 19.5 37.5 27.0 27.0
F..127 39.0 54.5 34.0 61.0 45.0 46.5
F..157 68.0 103.0 62.0 104.0 85.0 77.0
