12
TEMPERATURE CONTROL – STANDARD
STANDARD CONTROLLER FUNCTIONS
If one or more controllers are installed, at least one must be on for the water heater to operate. If all controllers
are off, the water heater will only deliver cold water.
on / off ( ) button – This button must be pressed once to turn on the controller.
A controller cannot be turned on if water is flowing from a hot tap.
To turn off a controller, press the on / off ( ) button once. The light will go out.
A controller can be turned off whilst water is flowing.
on / off operating light – The on / off operating light on the on / off ( ) button will glow when the controller is
turned on.
The light will go out when the controller is turned off.
priority light – This light will glow on a controller when that controller has priority.
The Bathroom controller(s), if they are turned on, have priority over the Kitchen
controller.
Priority means that controller has control of the water heater temperature setting.
The water temperature setting can only be adjusted by the controller that has priority.
in use light – This light will glow on all controllers, whether they are on or off, when hot water is
flowing, regardless of which controller has priority.
display panel – The current temperature setting is displayed on all controllers (whether hot water is
flowing or not), when any controller is on.
If all controllers are off, then the display remains blank.
The water volume can also be displayed on the Kitchen controller. The x 10L symbol
glows when the water volume is displayed.
up () button – The up () button increases the temperature and water volume settings.
Refer to “Temperature Adjustment – Standard Controller” on page 15 and “Water
Volume Function” on page 20.
down () button – The down () button decreases the temperature and water volume settings.
Refer to “Temperature Adjustment – Standard Controller” on page 15 and “Water
Volume Function” on page 20.
water volume ( ) button (Kitchen controller only) – This feature enables an alarm to sound when a set
volume of water has flowed through the water heater.
Refer to “Water Volume Function” on page 20.
water volume operating light – The water volume operating light on the water volume ( ) button will glow
when the water volume ( ) button is pressed and the water volume function is turned
on.
The light will go out when the water volume ( ) button is pressed and the
water volume function is turned off.
water volume symbol – The x 10L symbol below the display panel glows when the water volume function is
turned on and the water volume is displayed.
X 10L
88
°C
X 10L
88
°C
X 10L
88
°C
X 10L
88
°C
X 10L
88
°C
X 10L
88
°C
X 10L
88
°C
