TEMPERATURE CONTROL – DELUXE
DELUXE CONTROLLER FUNCTIONS
If one or more Deluxe controllers are installed, at least one must be on or the Bath Fill function activated for
the water heater to operate. If all Deluxe controllers and the Bath Fill function are off, the water heater will only
deliver cold water.
on / off ( ) button – The on / off ( ) button must be pressed once to turn on the Deluxe controller. A Deluxe
controller cannot be turned on if water is flowing from a hot tap.
To turn off a Deluxe controller, press the on / off ( ) button once. A Deluxe controller
can be turned off whilst water is flowing.
on / off operating light – The on / off operating light on the on / off ( ) button will glow when the Deluxe
controller is turned on.
The light will go out when the Deluxe controller is turned off.
PRIORITY light – The PRIORITY light will glow on a Deluxe controller when the controller has priority.
The Bathroom Deluxe controller(s), if they are turned on, have priority over the Kitchen
Deluxe controller.
PRIORITY means that particular Deluxe controller has control of the water heater
temperature setting. The water temperature setting can only be adjusted by a Deluxe
controller that has priority and is displaying the PRIORITY light.
operating light – The operating light will glow on all Deluxe controllers, whether they are on or off, when
hot water is flowing, regardless of which Deluxe controller has priority.
temperature display panel – The current temperature setting is displayed in °C on all Deluxe controllers
(whether hot water is flowing or not), when any Deluxe controller is on. If all Deluxe
controllers are off, the display remains blank.
up () button – The up () button increases the water temperature setting.
Refer to “Temperature Adjustment – Deluxe Controllers” on page 27.
down () button – The down () button decreases the water temperature setting.
Refer to “Temperature Adjustment – Deluxe Controllers” on page 27.
assistance call ( ) button – Pressing this button sounds an alert message on all Deluxe controllers, indicating
that assistance is required in the room from which the assistance call ( ) button was
activated.
speaker – The audio of the voice prompts and chimes is emitted from the speaker.
bath fill ( ) button – The bath fill ( ) button must be pressed once to turn on the Bath Fill function.
When the Bath Fill function is turned on, the last selected bath fill water volume in litres
will be displayed in the bath fill water volume display panel and the last selected bath fill
temperature in °C will be displayed in the temperature display panel.
The bath fill water volume and temperature can be adjusted by using the BATH FILL
VOLUME and BATH FILL TEMPERATURE buttons located behind the hinged panel on
the lower half of the Deluxe controller. Refer to “Bath-Fill Function” on page 32.
To turn off the Bath Fill function, press the bath fill ( ) button.
bath fill operating light – The bath fill operating light on the bath fill ( ) button will glow when the bath fill
( ) button is pressed and the Bath Fill function is turned on.
The light will flash when the Bath Fill function is complete but before the Bath Fill function
has been turned off.
The light will go out when the bath fill ( ) button is pressed and the Bath Fill function
is turned off.
