RICATECH RC800 MP4 PLAYER USER GUIDE RICATECH RC800 PORTABLE MP4 PLAYER RC800 Page 1 of 16
RICATECH RC800 MP4 PLAYER USER GUIDE NOTE: Please charge the player for at least 8 hours before using! -The player will not charge well on a shared USB connection like one on front of an ATX Housing or via an unpowered USB HUB. -Use the USB connection on the back of your computer casing, or an optional Ricatech® power adapter model RCCH03. Cautions Do not subject the device to severe impact or drop it from a high position. Do not use the player in extreme hot or cold, dusty or damp environment.
RICATECH RC800 MP4 PLAYER USER GUIDE 1 2 Key Features MP3&WMA Player AVI Video player JPEG photo viewer MicroSD Memory card reader Folder Navigation Voice Recorder Stereo FM radio FM Recording Removable Storage Device Computer Games Built-in, rechargeable lithium-ion battery Customizable settings System Requirements Hardware: IBM PC or Compatible PC, Notebook with USB interface Operating System: Windows98/SE (with DirectX 9.
RICATECH RC800 MP4 PLAYER USER GUIDE Double click the “My Computer”, icon. You will see a “removable disk” which represents the player. Now you can use the removable disk as a normal local disk drive, copying audio files from or to the removable disk. 4.2 Removing the player from the PC safely For Windows2000/XP: (1) Left click the (Remove hardware safely)icon at the right hand corner of the taskbar. (2) Click the pop-up mini-window with message of “Stop the USB Mass Storage Device – Drive (X)”.
RICATECH RC800 MP4 PLAYER USER GUIDE 5 Keys Description A. Earphone Jack B. LCD Display C. MENU: Hold for a while to enter the main menu. Briefly press to confirm selection confirm or enter the folder navigation mode. D. Previous: Play the previous track. / Move up. E. Next: Play the next track. / Move down. F. Play/Pause: Turn on or turn off the device. / Play or pause audios. G. VOL (volume): Adjust the volume / Return to the previous screen. H. Power Switch: Turn on or turn off the power I.
RICATECH RC800 MP4 PLAYER USER GUIDE 7 Basic operation Function Operation Play/Pause Press the PLAY/PAUSE button to play or pause. Adjust Volume (1) Shortly press the VOL button until you see a red volume icon blinking. (2) Press the PREVIOUS/NEXT button to decrease or increase volume. (3) Press the VOL button again to confirm. Previous Track Shortly press the PREVIOUS button. Next Track Shortly press the NEXT button. Fast Forward Press and hold the NEXT button.
RICATECH RC800 MP4 PLAYER USER GUIDE 9 Playing music 9.1 Enter the music mode Press and hold the MENU button to display the main menu. Use the PREVIOUS/NEXT button to select “Music” menu, and press the MENU button to confirm selection. Now you are in the MUSIC mode, refer music playing to the basic operations. 9.2 Folder navigation To navigate through folders: (1) In the MUSIC mode, shortly press the MENU button to enter folder navigation mode.
RICATECH RC800 MP4 PLAYER USER GUIDE 10 Playing video files (For advanced users) (1) Press and hold the MENU button to display the main menu. (2) Use the PREVIOUS/NEXT button to select the “Video” menu, and press the MENU button to enter the video player mode. (3) Press the PREVIOUS/NEXT button to search a video file that you want to play, and press the MENU button to play. For detail information about playing, see the “Basic Operation” section.
RICATECH RC800 MP4 PLAYER USER GUIDE (3) Press the PREVIOUS/NEXT button to select a .txt file, and press the MENU button to open the selected file. (4) Press the PREVIOUS/NEXT button to page up or page down, or press the PLAY/PAUSE button to page up or down automatically (by setting the time interval between 1 and 5 in Settings/Auto Slide show/Text). (5) During reading, you can use the bookmark to mark the page for resuming reading later. For information about bookmark, see “Using bookmark” section. 12.
RICATECH RC800 MP4 PLAYER USER GUIDE (1) In the folder navigation mode, select the file that you want to delete. (2) Press and hold the VOL button until a dialogue box shows up. (3) Use the PREVIOUS/NEXT button to select “YES” and press the MENU button to confirm. 16 FM Radio (optional) On the main menu, select “FM Tuner” and press the MENU button to turn on the FM radio. Search Station (1) Shortly press the MENU button to show the submenus.
RICATECH RC800 MP4 PLAYER USER GUIDE button to continue. (3) Press the PREVIOUS/NEXT button to select the station that you want to delete, and press the PLAY/PASUE button to continue. (4) Press the PREVIOUS/NEXT button to select “YES” or “NO”, and press the PLAY/PAUSE to confirm. Record FM program When you are listening to a station, you can press and hold the VOL button to record your favourite programs. For detail information about recording, see “Record” section.
RICATECH RC800 MP4 PLAYER USER GUIDE Preset EQ Normal, 3D, Rock, Pop, Classical, Bass, Jazz, User EQ User EQ (1) Press the VOL button to switch EQ (User-defined column. equalizer setting) (2) Press the PREVIOUS/NEXT button to adjust value. (3) Repeat pressing the VOL button until the cursor is on the YES button, and then press the MENU button to confirm. (4) Go to the EQ Select menu, and select User EQ to enable the equalizer setting.
RICATECH RC800 MP4 PLAYER USER GUIDE 19 Troubleshooting Problem Possible Cause Solution Battery is too low. Charge the battery. No sound when playing an The volume is too low. Adjust the volume. audio file. Bad audio file. Delete or skip the file. The LCD displays nothing when the device is started. The player cannot be connected to the PC. The displayed time is The PC has error when you plug and unplug the player.
RICATECH RC800 MP4 PLAYER USER GUIDE 20 Technical Specifications Item Specification Capacity 128MB or above Battery Type Rechargeable Lithium Battery Battery Life Approx. 5 Hours LCD Display 1.8-inch TFT screen Earphone Power 5mW+5Mw Video Format AVI (XviD) Audio Format MP3, WMA Photo Format JPEG Image Resolution 3520 X 2816 (Max.) Bit Rate MP3: 8-320kbps; WMA: 32-384kbps SNR ＞90dB USB Port USB2.
RICATECH RC800 MP4 PLAYER USER GUIDE ② Select “JPG JPEG JFIF Format” and then click “Options”. ③ Deselect the options circled in red and then press “OK” button to confirm.
RICATECH RC800 MP4 PLAYER USER GUIDE Warranty: Ricatech BV covers all products (Excl. Acessories) with a 2 year warranty applying to all faults caused by a factory-error. External physical damage will not be covered by our warranty Warranty: No Warranty : Out of warrranty repairs All hardware errors occurring within 2 years after purchase unless caused by points mentioned below. Faults caused by: *Dismountal by any other service center then ours.
