Setting items Description
Resolution: Select the output resolution setting.
Image Smoothing: Specify whether or not to perform image smoothing, or
specify the threshold resolution to apply smoothing.
Color Mode: Specify whether or not to print documents in color or black
and white.
Gradation: Specify the print image quality.
Color Setting: Select the compensation method to be used when converting
RGB data into CMYK.
• Off
Color settings are not modified.
• Fine
Select this setting to perform color matching and CMYK
conversion based on the color profile pattern selected
for "Color Profile:" Colors printed using this setting are
equivalent to a monitor gamma setting of 1.8.
• Super Fine
Select this setting to perform color matching and CMYK
conversion based on the color profile pattern selected
for "Color Profile:". This setting is useful for emphasizing
areas of light color. Colors printed using this setting are
equivalent to a monitor gamma setting of 2.2.
Color Profile: Select the color profile to be used when color matching RGB
to CMYK.
This function is available only if [Fine] or [Super Fine] is
selected in the "Color Setting:" list.
• Auto
Automatically configures the best color profile pattern
depending on the appearance of the document to print.
• Photographic
Enhances mid-tone colors similar to those seen in
photographs.
• Presentation
Convenient Print Functions
