JupiterC2_NRG_Copy_GB_01.
JupiterC2_GB_Copy_F_FM.book Page 1 Friday, January 20, 2006 7:37 PM Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference. For safe and correct use of this machine, please be sure to read the Safety Information in the General Settings Guide before you use it.
JupiterC2_GB_Copy_F_FM.book Page i Friday, January 20, 2006 7:37 PM Manuals for This Machine The following manuals describe the operational procedures of this machine. For particular functions, see the relevant parts of the manual. Note ❒ Manuals provided are specific to machine type. ❒ Adobe Acrobat Reader/Adobe Reader is necessary to view the manuals as a PDF file.
JupiterC2_GB_Copy_F_FM.book Page ii Friday, January 20, 2006 7:37 PM ❖ Scanner Reference (PDF file - CD-ROM1) Describes operations, functions, and troubleshooting for the machine's scanner function. ❖ Manuals for DeskTopBinder Lite DeskTopBinder Lite is a utility included on the CD-ROM labeled “Scanner Driver and Document Management Utility”. • DeskTopBinder Lite Setup Guide (PDF file - CD-ROM2) Describes installation of, and the operating environment for DeskTopBinder Lite in detail.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page vi Friday, January 20, 2006 7:37 PM What You Can Do with This Machine Functions differ depending on machine type and options. See p.4 “Functions Requiring Optional Configurations”.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page ix Friday, January 20, 2006 7:37 PM TABLE OF CONTENTS Manuals for This Machine ...................................................................................... i What You Can Do with This Machine ... iii What You Can Do with This Machine.................................................................. vi Notice ......................................................................................................................
JupiterC2_GB_Copy_F_FM.book Page x Friday, January 20, 2006 7:37 PM Staple ....................................................................................................................... 45 Punch ....................................................................................................................... 49 Duplex ...................................................................................................................... 53 1 Sided Combine........................................
JupiterC2_GB_Copy_F_FM.book Page xi Friday, January 20, 2006 7:37 PM 5. User Tools (Copier / Document Server Features) User Tools Menu (Copier / Document Server Features) ................................ 103 Accessing User Tools (Copier / Document Server Features)........................ 110 Changing Default Settings .....................................................................................110 Exiting User Tools ....................................................................................
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 1 Friday, January 20, 2006 7:37 PM Notice Do not copy or print any item for which reproduction is prohibited by law. Copying or printing the following items is generally prohibited by local law: bank notes, revenue stamps, bonds, stock certificates, bank drafts, checks, passports, driver's licenses. The preceding list is meant as a guide only and is not inclusive. We assume no responsibility for its completeness or accuracy.
JupiterC2_GB_Copy_F_FM.book Page 2 Friday, January 20, 2006 7:37 PM How to Read This Manual Symbols This manual uses the following symbols: R WARNING: This symbol indicates a potentially hazardous situation that might result in death or serious injury if you misuse the machine by not following the instructions under this symbol. Be sure to read the instructions, all of which are included in the Safety Information section in the General Settings Guide.
JupiterC2_GB_Copy_F_FM.book Page 3 Friday, January 20, 2006 7:37 PM Machine Types This machine comes in three models which vary by copy speed. To confirm which model you have, see the inside front cover of this manual.
JupiterC2_GB_Copy_F_FM.book Page 4 Friday, January 20, 2006 7:37 PM Functions Requiring Optional Configurations 2 tray finisher *1 ❍ ❍ ❍ Booklet finisher *1 ❍ ❍ ❍ *1 4 The paper tray unit is required in order to install the finisher. Punch ❍ Staple Mixed Size ❍ Stack SADF Auto Document Feeder ❍ (ADF) Shift Sort Batch Function Staple (Saddle Stitch) Certain functions require special machine configuration and extra options. See the table below.
JupiterC2_GB_Copy_F_FM.book Page 5 Friday, January 20, 2006 7:37 PM Control Panel This illustration shows the control panel of a machine with options fully installed. AAE001S 1. Screen Contrast knob 4. {Adjust/Program Colour}} key Adjusts display panel brightness. Use this key to adjust and register colours. See p.87 “Colour Adjustment/Program”, p.92 “User Colour”. 2. {User Tools/Counter}} key • User Tools Press to change the defaults and conditions to meet your requirements. See p.
JupiterC2_GB_Copy_F_FM.book Page 6 Friday, January 20, 2006 7:37 PM 10. {Energy Saver}} key 19. Colour Selection Key (Copy mode) Press to switch into and out of Energy Saver mode. See “Saving Energy”, General Settings Guide. Switch keys depending on the type of original, or the copying purpose: {Auto Colour Selection} }: {Full Colour} }: {Black & White} }: {Single Colour} }: {Two-colour} }: See p.28 “Colour Functions” 11.
JupiterC2_GB_Copy_F_FM.book Page 7 Friday, January 20, 2006 7:37 PM Display Panel The function items displayed serve as selector keys. You can select or specify an item by lightly pressing them. When you select or specify an item on the display panel, it is highlighted like this: . Keys appearing as cannot be used. Note ❒ The following illustration is an example of the panel display when the booklet finisher and 2 tray paper unit installed. ❖ Initial copy display AFZ022S 1.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 9 Friday, January 20, 2006 7:37 PM 1. Placing Originals Originals Note ❒ Highlighter pen colours are difficult to reproduce. Depending on the colour used, they may not come out on copies, or may come out as a different colour.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 11 Friday, January 20, 2006 7:37 PM Originals ❖ Exposure glass 1 CP01AEE ❖ ADF AAE044E Note ❒ When copying custom size originals, make sure you specify the size of the originals. If not, the image may not be copied properly. See p.17 “Placing custom size originals”. Sizes difficult to detect It is difficult for the machine to automatically detect the sizes of the following types of originals, so select the paper size manually.
JupiterC2_GB_Copy_F_FM.book Page 12 Friday, January 20, 2006 7:37 PM Placing Originals Missing Image Area Even if you correctly place originals in the ADF or on the exposure glass, margins of a few millimeters on all four sides of the original might not be copied. 1 GCGENK2E 1. 0.5 - 4.0 mm, 0"- 0.16" 2. 0.5 - 6.0 mm, 0"- 0.24" 12 3. 0.5 - 4.0 mm, 0"- 0.16" 4. 1.5 - 5.0 mm, 0.06"- 0.
JupiterC2_GB_Copy_F_FM.book Page 13 Friday, January 20, 2006 7:37 PM Placing Originals Placing Originals Note ❒ Place originals only when all correction fluid and ink has completely dried. Not taking this precaution could dirty the exposure glass, thus resulting in blemished copies. For example, to copy A3Kor 11" × 17"K originals with the Staple function selected: 1 Reference For original sizes you can set, see p.9 “Originals”.
JupiterC2_GB_Copy_F_FM.book Page 14 Friday, January 20, 2006 7:37 PM Placing Originals B Select the original orientation. 1 Standard orientation Placing Originals on the Exposure Glass A Make sure A Lift is selected. the exposure glass cover or the ADF. Important ❒ Do not lift the exposure glass cover or the ADF forcefully. O t h e r w is e , t h e A D F c o v e r might open or be damaged. 90° turn A Place the original in the landscape orientation, and then press .
JupiterC2_GB_Copy_F_FM.book Page 15 Friday, January 20, 2006 7:37 PM Placing Originals Placing Originals in the Auto Document Feeder Settings should be made accordingly in the following situations: A Set the document guide to the original size. B Place the aligned originals face up into the ADF. 1 ❖ When placing originals consisting of more than 80 pages: p.15 “Batch” ❖ When placing originals one by one: p.16 “SADF” ❖ When placing originals of the same width but different sizes: p.
JupiterC2_GB_Copy_F_FM.book Page 16 Friday, January 20, 2006 7:37 PM Placing Originals A Press [Special Original]. A Press [Special Original]. B Press [Batch], and then press [OK]. B Press [SADF], and then press [OK]. C Place one page of an original, and 1 Note ❒ If [SADF] is displayed, change the settings. See p.122 “Switch to Batch (SADF)”. C Place the first instalment of the originals, and then press the {Start} } key. D After the originals has been fed, place the next instalments.
JupiterC2_GB_Copy_F_FM.book Page 17 Friday, January 20, 2006 7:37 PM Placing Originals ❒ Copy speed and scanning speed may slow down. ❒ You can place originals of two different sizes at once. ❒ Sizes of originals that can be placed together using this function are as follows: Metric version A3L, B4 JIS L, A4KL, B5 JISKL Inch version 11" × 17"L, 81/2" × 14"L, 81/2" × 11"KL Placing custom size originals When placing custom size originals, specify the size of the originals.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 19 Friday, January 20, 2006 7:37 PM 2. Copying Basic Procedure Preparation When User Code Authentication is set, the screen for entering a user code will be displayed. Enter your user code using the number keys, and then press the { #} } key. For user codes, see "Authentication Information", General Settings Guide. When Basic Authentication, Windows Authentication, or LDAP Authentication is set, the authentication screen will be displayed.
JupiterC2_GB_Copy_F_FM.book Page 20 Friday, January 20, 2006 7:37 PM Copying - How to operate ❖ To stop the machine during a multicopy run Press the {Clear/Stop} } key. ❖ To return the machine to the initial condition after copying Press the {Clear Modes} } key. 2 ❖ When clearing entered values Press the {Clear/Stop} } key or [Clear] on the display. ❖ To check the settings Press the {Check Modes} } key. Interrupt Copy Use this function to interrupt a long copy job to make urgently needed copies.
JupiterC2_GB_Copy_F_FM.book Page 21 Friday, January 20, 2006 7:37 PM Basic Procedure Job Preset You can make settings for the next copy job while copying is in progress. If a long copy job is in progress and you do not want to wait for it to finish, you can use this function to make settings for the next copy job in advance. When the current copy job finishes, the next job begins automatically. 2 A Press [NextJob] when "Copying..." is displayed. B Make settings for the next copy job.
JupiterC2_GB_Copy_F_FM.book Page 22 Friday, January 20, 2006 7:37 PM Copying Copying from the Bypass Tray Use the bypass tray to copy onto special paper such as OHP transparencies, thick paper, thin paper, and copy paper that cannot be loaded in the paper trays. 2 Preparation When copying from the bypass tray, select [1 Sided] for copying in [Dup./Combine/Series] (for example [1 Sided] → [1 Sided].
JupiterC2_GB_Copy_F_FM.book Page 23 Friday, January 20, 2006 7:37 PM Copying from the Bypass Tray B Insert the paper with the side you want to copy facing up until you hear the beep, and align the paper guide to the paper size. When copying onto standard size paper A Press the {#} } key. The "Bypass Tray Paper" screen is displayed. B Press [Select Size]. 2 ZKVH130J 1: Extender Important ❒ If the guides are not flush against the copy paper, image skewing or misfeeds might occur.
JupiterC2_GB_Copy_F_FM.book Page 24 Friday, January 20, 2006 7:37 PM Copying ❒ To register the custom size entered, press [Program], and then press [Exit]. A Open the bypass tray, and then adjust the guides to the paper size. B Gently insert the OHP transparencies or thick paper face up until the beeper sounds. 2 E Press [OK]. D Place the originals, and then press the {Start} } key. Note ❒ When the Sort function is set, press the {#} } key after all originals have been scanned.
JupiterC2_GB_Copy_F_FM.book Page 25 Friday, January 20, 2006 7:37 PM Copying from the Bypass Tray When Copying on the Back Side of the Paper ❖ Top to bottom Using the bypass tray, you can make copies on the back of paper which has already been copied on the other side. 2 Note ❒ Do not use paper that has already been copied onto by other equipment. ❒ Copies made on the back side of the paper should be originals with very little image area, such as text originals.
JupiterC2_GB_Copy_F_FM.book Page 26 Friday, January 20, 2006 7:37 PM Copying F Place the originals, and then press When Copying onto Envelopes the {Start} } key. G When your copy job is finished, Note ❒ When placing an original on the exposure glass, place the original with the bottom line aligned to the left scale. 2 ❒ When placing originals in the ADF, place the originals with the bottom line inserted in the ADF.
JupiterC2_GB_Copy_F_FM.book Page 27 Friday, January 20, 2006 7:37 PM Making A3, 11" × 17" Full Bleed Copies Making A3, 11" × 17" Full Bleed Copies You can make A3, 11" × 17" full bleed copies with 12" × 18" paper. This is useful for making A3, 11" × 17" size copies with a coloured background (e.g. catalogues). 2 GCBLEE0E 1. A3, 11" × 17" size Original 2. In standard copy mode, margins 3. 12" × 18" Full Bleed Copy 4.
JupiterC2_GB_Copy_F_FM.book Page 28 Friday, January 20, 2006 7:37 PM Copying Colour Functions Selecting a Colour Mode Select a Colour mode that best suits your originals and copying requirements. 2 Reference For colour images, see p.iii “What You Can Do with This Machine ” The following basic functions are explained in this section. ❖ Auto Colour Selection Judges the colour of the original automatically, and copies either in full colour or black/white.
JupiterC2_GB_Copy_F_FM.book Page 29 Friday, January 20, 2006 7:37 PM Colour Functions Note ❒ When copied using the registered colour, the original will be copied lighter than the registered colour. C Press [Non-black Portion], and then select the colour to replace the black colour of the original. ❒ Press [Lighter] or [Darker], and you can adjust the density in 4 steps. When the {Two-colour} } key is selected A Select either [Two-colour] or [Red & Black]. 2 D Press [OK] twice.
JupiterC2_GB_Copy_F_FM.book Page 30 Friday, January 20, 2006 7:37 PM Copying E Select any one item from [Conversion 1] to [Conversion 4]. Erase Colour You can erase a certain colour in the image of the original. 2 F Select the colour to be converted. G Select the new colour to be converted. Note ❒ You can adjust the density of each colour in 4 levels. ❒ When you want to change the converted colour, press from [Conversion 1] to [Conversion 4] and make the selection again.
JupiterC2_GB_Copy_F_FM.book Page 31 Friday, January 20, 2006 7:37 PM Colour Functions Colour Background Copies by adding a colour in the whole page. Note ❒ Since the Colour Background function overprints the entire original, t h e c o l o ur o f t h e im a g e m ay change. 2 A Press [Edit / Colour Creation]. B Press [Colour Creation]. C Press [Colour Background]. D Select the background colour, then press [OK]. Note ❒ You can adjust the density of each colour in 4 levels.
JupiterC2_GB_Copy_F_FM.book Page 32 Friday, January 20, 2006 7:37 PM Copying Copier Functions 2 Adjusting Copy Image Density Manual image density There are three types of adjustment available: A Press [Auto Image Density] to cancel it. B Press [Lighter] or [Darker] to adjust ❖ Auto Image Density The machine automatically adjusts image density. image density. ❖ Manual image density You can adjust the general density of the original in nine increments.
JupiterC2_GB_Copy_F_FM.book Page 33 Friday, January 20, 2006 7:37 PM Copier Functions Selecting the Original Type Select one of the following six types to match originals: ❖ Text When originals contain only text (no pictures). ❖ Text / Photo When originals contain photographs or pictures alongside the text. ❖ Photo When you need to reproduce delicate tones of photographs and pictures. ❖ Map You can configure the machine to scan Map originals.
JupiterC2_GB_Copy_F_FM.book Page 34 Friday, January 20, 2006 7:37 PM Copying Selecting Copy Paper There are two ways to select copy paper: ❖ Auto Paper Select The machine selects a suitable size of copy paper automatically based on original size and reproduction ratio. 2 ❖ Manual Paper Select Choose the paper you want to copy onto from a paper tray, bypass tray, or Large Capacity Tray (LCT). Reference p.11 “Sizes difficult to detect” p.
JupiterC2_GB_Copy_F_FM.book Page 35 Friday, January 20, 2006 7:37 PM Copier Functions Auto Paper Select A Make sure [Auto Paper Select] is selected. 2 Note ❒ Trays with a key mark are not automatically selected. See “Paper Type” in “Tray Paper Settings”, General Settings Guide. Manual Paper Select A Select the paper tray, bypass tray or LCT. The selected paper tray is highlighted. Reference p.22 “Copying from the Bypass Tray” If the paper type keys are not displayed A Press [Auto Paper Select].
JupiterC2_GB_Copy_F_FM.book Page 36 Friday, January 20, 2006 7:37 PM Copying - Rotated copy If the orientation of the original (L or K) is different to that of the paper you are copying onto, this function rotates the original image by 90°, fitting it onto the copy paper. This function works when [Auto Paper Select] or [Auto Reduce / Enlarge] is selected. See p.34 “Auto Paper Select”, p.38 “Auto Reduce / Enlarge”. 2 GCROTA0E Note ❒ The default setting for Auto Tray Switching is [With Image Rotation].
JupiterC2_GB_Copy_F_FM.book Page 37 Friday, January 20, 2006 7:37 PM Copier Functions A Press [Reduce / Enlarge]. Preset Reduce/Enlarge You can select a preset ratio for copying. 2 ❖ Base Point The base point of Reduce/Enlarge differs depending on how the original was scanned. When the original is placed on the exposure glass, the upper left corner is the base point. When placed in the ADF, the bottom left corner is the base point.
JupiterC2_GB_Copy_F_FM.book Page 38 Friday, January 20, 2006 7:37 PM Copying A Press [Create Margin] on the initial display. B Enter the ratio. To select the ratio using [n n] and [o o] A Select a preset ratio close to the ratio using [Reduce] or [Enlarge]. B Adjust the ratio further, using [n n] or [o o]. 2 B If you do not want to combine it with the Reduce/Enlarge function, place originals, and then press the {Start} } key. Zoom You can change the reproduction ratio in increments of 1%.
JupiterC2_GB_Copy_F_FM.book Page 39 Friday, January 20, 2006 7:37 PM Copier Functions Note ❒ You cannot use the bypass tray with this function. ❒ When using Auto Reduce / Enlarge, see the following table for original sizes and orientations you can use: A Press [Auto Reduce / Enlarge].
JupiterC2_GB_Copy_F_FM.book Page 40 Friday, January 20, 2006 7:37 PM Copying C Make sure [Size Magnificatn] is highlighted. D Enter the length of the original using the number keys, and then press [#]. Note ❒ You can enter sizes within the following ranges: 2 Note ❒ You can also select a preset ratio close to the ratio using [Reduce] or [Enlarge], and then adjust it further, using [n n] or [o o]. A Press [Reduce / Enlarge]. Metric 1–999 mm version (increments of 1 mm) Inch 0.1"–99.
JupiterC2_GB_Copy_F_FM.book Page 41 Friday, January 20, 2006 7:37 PM Copier Functions ❒ If you have incorrectly entered the ratio, readjust it using [n n] or [o o]. D Press [Vertical]. E Adjust the ratio using [n n] or [o o]. F Press [OK]. D Press [OK]. E Place the originals, and then press the {Start} } key. Note ❒ You can enter sizes within the following ranges: Metric version Vertical: 1–999 mm (increments of 1 mm) Horizontal: 1–999 mm (increments of 1 mm) Inch version 2 0.1"–99.
JupiterC2_GB_Copy_F_FM.book Page 42 Friday, January 20, 2006 7:37 PM Copying Sort The machine can scan originals into memory and automatically sort copies. ❖ Shift Sort • When a finisher is installed: Each time the copies of one set or a job are delivered, the next copy is shifted to separate each set or job. Reference Related default settings: 2 p.123 “Select Stack Function” p.122 “Memory Full Auto Scan Restart” p.122 “Rotate Sort: Auto Paper Continue” p.
JupiterC2_GB_Copy_F_FM.book Page 43 Friday, January 20, 2006 7:37 PM Copier Functions ❖ When the booklet finisher is installed Sample copy You can use this function to check copy settings before making a long copy run. Note ❒ This function can be used only when the Sort function is turned on. Note ❒ When the optional finisher is installed, use the User Tools to display [Rotate Sort]. See p.123 “Select Stack Function”.
JupiterC2_GB_Copy_F_FM.book Page 44 Friday, January 20, 2006 7:37 PM Copying 2 Changing the number of sets Stack You can change the number of copy sets during copying. Copies can be assembled with each page shifted. Note ❒ This function can only be used when the Sort function is turned on. ❖ When a finisher is installed This function groups together copies of each page in a multi-page original. Every other page stack is shifted for ease of separation.
JupiterC2_GB_Copy_F_FM.book Page 45 Friday, January 20, 2006 7:37 PM Copier Functions Staple Individual copy sets can be stapled. 2 Note ❒ You cannot use the bypass tray with this function. Reference p.123 “Select Stapling Position” Stapling position and original setting Place all the originals in an orientation in which they can be read. They will be automatically rotated for copying.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 48 Friday, January 20, 2006 7:37 PM Copying Original location Saddle Stitch Exposure glass 2 *1 *2 ADF Stapling position *1 L This table shows the stapling positions, not the orientation of delivery. Not available for A3, B4 JIS or 11" × 17", 81/2" × 14" size paper. A Select one of the stapling positions. ❖ 2 tray finisher ❖ Booklet finisher Note ❒ When you select the stapling position, the Sort function is automatically selected. Reference p.
JupiterC2_GB_Copy_F_FM.book Page 49 Friday, January 20, 2006 7:37 PM Copier Functions Note ❒ When placing originals on the exposure glass, start with the first page to be copied. When placing originals in the ADF, set the first page on top. ❒ When placing originals on the exposure glass or in the ADF using the Batch function, press the {#} } key after all the originals have been scanned. Punch 2 You can make punch holes in copies.
JupiterC2_GB_Copy_F_FM.book Page 50 Friday, January 20, 2006 7:37 PM Copying Note ❒ 3 holes is only available with the 2 tray finisher. ❒ You cannot use the bypass tray with this function.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 52 Friday, January 20, 2006 7:37 PM Copying Original location Exposure glass 2 holes ADF Punch hole positions *1 K L 90º Turn 2 4 holes K L *1 This table shows the punch hole positions, not the orientation of delivery. A Select one of the punch hole positions. B Enter the number of copy sets with the number keys. C Place the originals, and then press the {Start}} key.
JupiterC2_GB_Copy_F_FM.book Page 53 Friday, January 20, 2006 7:37 PM Copier Functions Duplex There are three types of duplex copies: ❖ 1 Sided→ →2 Sided Copies 2 one-sided pages onto a two-sided page. Original orientation and completed copies Copy images differ according to the orientation in which you place originals (vertical K or horizontal L ). 2 ❖ 2 Sided→ →2 Sided Copies 1 two-sided page onto a two-sided page.
JupiterC2_GB_Copy_F_FM.book Page 54 Friday, January 20, 2006 7:37 PM Copying A Press [Dup./Combine/Series]. ❒ When placing originals on the exposure glass or in the ADF using the Batch function, press the { #} } key after all the originals have been scanned. Originals and copy orientation 2 You can select the orientation. • Top to Top Note ❒ You can also select "1 Sided to 2 Sided" or "2 Sided to 2 Sided" directly, by pressing the Copy Function Key. If you do this, proceed to step D.
JupiterC2_GB_Copy_F_FM.book Page 55 Friday, January 20, 2006 7:37 PM Copier Functions 1 Sided Combine Combine several pages onto one side of a sheet. ❖ Orientation of the original and combine image position • Open to leftR originals ❖ 1 Sided 2 Pages → Combine 1 Side Copies 2 one-sided originals onto one side of a sheet. 2 GCSHUY1E • Open to top S originals GCSHUY2E GCSHVY7E ❖ 1 Sided 4 Pages → Combine 1 Side Copies 4 one-sided originals onto one side of a sheet.
JupiterC2_GB_Copy_F_FM.book Page 56 Friday, January 20, 2006 7:37 PM Copying Reference Related default settings: p.116 “Erase Original Shadow in Combine” p.117 “Copy Order in Combine” p.118 “Separation Line in Combine” 2 A Press [Dup./Combine/Series]. Note ❒ You can select "1 Sided 2 Pages → Combine 1 Side" or "1 Sided 4 Pages → Combine 1 Side" by using Copy Function key. In this case, proceed to step F. F Place the originals, and then press the {Start} } key.
JupiterC2_GB_Copy_F_FM.book Page 57 Friday, January 20, 2006 7:37 PM Copier Functions ❖ 1 Sided 16 Pages → Combine 2 Side Copies 16 one-sided originals onto a sheet, eight pages per side. ❖ 2 Sided 16 Pages → Combine 2 Side Copies 8 two-sided originals onto a sheet, eight pages per side. 2 GCSHVY6E GCSHVY5E Note ❒ You cannot use the bypass tray with this function. 1. Front 2. Back ❖ 2 Sided 4 Pages → Combine 2 Side Copies 2 two-sided originals onto a sheet, two pages per side.
JupiterC2_GB_Copy_F_FM.book Page 58 Friday, January 20, 2006 7:37 PM Copying A Press [Dup./Combine/Series]. Series Copies This function copies the front and back of a two-sided original separately, or two facing pages of a bound original, onto two sheets. 2 B Press [1 Sided] or [2 Sided] for Original, and then press [Combine 2 Side] for Copy. Reference p.54 “Originals and copy orientation” C Select the number of originals to combine, and then press [OK]. D Select the paper size. E Press [OK].
JupiterC2_GB_Copy_F_FM.book Page 59 Friday, January 20, 2006 7:37 PM Copier Functions ❖ Front&Back→ →2 Sided Copies both sides of a two-page spread original onto both sides of a sheet. A Press [Dup./Combine/Series]. 2 Note ❒ See the following table for original and copy paper sizes when using a 100% ratio.
JupiterC2_GB_Copy_F_FM.book Page 60 Friday, January 20, 2006 7:37 PM Copying ❖ Open to right Copying Book Originals Copies two or more originals in page order. ❖ 1 Sided → Booklet Makes copies in page order for a folded booklet. 2 ❖ Open to left GCAH020E ❖ 1 Sided→ →Magazine Copies two or more originals into magazine page order copies (when folded and stacked).
JupiterC2_GB_Copy_F_FM.book Page 61 Friday, January 20, 2006 7:37 PM Copier Functions ❖ 2 Sided→ →Magazine Copies two or more two-sided originals into magazine page order copies (when folded and stacked). ❖ Open to left How to fold and unfold copies to make a magazine ❖ Open to left 2 GCBOOK5E GCAH030E ❖ Open to right ❖ Open to right GCBOOK6E GCAH040E How to fold copies to make a booklet Note ❒ You cannot use the bypass tray with this function.
JupiterC2_GB_Copy_F_FM.book Page 62 Friday, January 20, 2006 7:37 PM Copying D Press [Book]. →Booklet], [2 Sided→ →E Select [1 Sided→ Booklet][1 Sided→ →Magazine], or [2 Sided→ →Magazine], and then press [OK]. F Press [OK]. G Select the paper. H Place the originals, and then press 2 the {Start} } key. Note ❒ When placing originals on the exposure glass or in the ADF using the Batch function, press the { #} } key after all the originals have been scanned. See p.
JupiterC2_GB_Copy_F_FM.book Page 63 Friday, January 20, 2006 7:37 PM Copier Functions C Press [Edit Image]. D Press [Image Repeat]. E Make sure that [Whole Area] is selected, then press [OK]. F Press [OK] twice. G Place the original, and then press the {Start} } key. C Press [Edit / Colour Creation]. D Press [Edit Image]. E Press [Image Repeat]. F Press [Specified Area]. G Enter the length of [X1] with the 2 number keys, then press [#]. H Enter the length of [Y1] with the number keys, then press [#].
JupiterC2_GB_Copy_F_FM.book Page 64 Friday, January 20, 2006 7:37 PM Copying ❖ Metric version 2 Original size and orientation Copy paper size and orientation A5L A4K B6 JISL B5 JISK A4K A3L A5K A4L B5 JISK B4 JISL B6 JISK B5 JISL E Select the paper. F Place the originals, and then press the {Start} } key. Centring You can make copies with the image moved to the centre.
JupiterC2_GB_Copy_F_FM.book Page 65 Friday, January 20, 2006 7:37 PM Copier Functions A Select the paper. B Press [Edit / Colour Creation]. ❒ If [Two-colour] (normal) is selected, the white part of the original becomes black and the black part becomes white, and the coloured part is copied with the specified colour. ❒ If [Red & Black] is selected, the white part of the original becomes black, the black part and the red part becomes white, and the blue part becomes red in colour. C Press [Edit Image].
JupiterC2_GB_Copy_F_FM.book Page 66 Friday, January 20, 2006 7:37 PM Copying B Press [Edit Image]. C Press [Mirror Image]. D Press [OK] twice. E Place the originals, then press the ❖ Centre/Border Erases both the original's centre and edge margins from the copy. {Start} } key. 2 Erase You can erase the centre and/or all four sides of the original image. This function has three modes: ❖ Border Erases the original's edge margin from the copy. GCCENT3E Reference The erase width is set to 10 mm (0.
JupiterC2_GB_Copy_F_FM.book Page 67 Friday, January 20, 2006 7:37 PM Copier Functions Border Erase Selecting [Diff. Width] A Press [Edit / Colour Creation]. A Press [Diff. Width]. B Press the key for the border you want to change, and then set the erase border width using [n n] and [o o]. B Press [Erase / Margin Adj.]. C Press [Erase]. D Set the erase border width. Selecting [Same Width] A Press [Same Width]. B Set the erase border width using [n n] and [o o]. 2 C Press [OK]. E Press [OK] twice.
JupiterC2_GB_Copy_F_FM.book Page 68 Friday, January 20, 2006 7:37 PM Copying Centre/border erase Selecting [Diff. Width] A Press [Edit / Colour Creation]. A Press [Diff. Width]. B Press the key for the part you want to change, and then set the erase margin width using [n n] and [o o]. 2 B Press [Erase / Margin Adj.]. C Press [Erase]. D Press [Centre / Border]. E Set the centre and border C Press [OK]. to be erased. Selecting [Same Width] A Press [Same Width].
JupiterC2_GB_Copy_F_FM.book Page 69 Friday, January 20, 2006 7:37 PM Copier Functions Note ❒ You can change the width of the binding margin as follows: G Place the originals, and then press the {Start} } key. Metric version 0–30 mm (increments of 1 mm) Background Numbering Inch version 0"–1.2" (increments of 0.1") Use this function to have numbers printed on the background of copies. 2 A Press [Edit / Colour Creation]. GCSTMP2E B Press [Erase / Margin Adj.]. C Press [Margin Adjustment].
JupiterC2_GB_Copy_F_FM.book Page 70 Friday, January 20, 2006 7:37 PM Copying E Press [OK] 3 times. F Place the originals, then press the Stamp position and original orientation {Start} } key. Changing the stamp colour A Press [Stamp]. B Select the stamp colour, then press 2 [OK]. Preset Stamp Frequently used messages can be stored in memory and stamped on copies.
JupiterC2_GB_Copy_F_FM.book Page 71 Friday, January 20, 2006 7:37 PM Copier Functions B Press [Stamp]. C Press [Preset Stamp]. D Select the message. E Press [All Pages] or [1st Page Only] to User Stamp Prints a registered stamp onto copies. select the print page. Note ❒ You can change the colour, position, size, and density of the stamp. See p.71 “Changing the stamp colour”. See p.71 “To change stamp position, size, and density”. F After you have specified all necessary settings, press [OK].
JupiterC2_GB_Copy_F_FM.book Page 72 Friday, January 20, 2006 7:37 PM Copying Reference Related default settings: p.120 “Stamp Position 1 - 4” p.120 “Stamp Format 1 - 4” p.120 “Stamp Colour: 1 - 4” A Press [Edit / Colour Creation]. 2 Changing the stamp colour A Press [Stamp Colour]. B Select the stamp colour, then press [OK]. To change the stamp position A Press [Change]. B Select the position, and then press [OK]. B Press [Stamp]. C Press [User Stamp]. D Select the stamp number.
JupiterC2_GB_Copy_F_FM.book Page 73 Friday, January 20, 2006 7:37 PM Copier Functions C Press [Copier / Document Server Features]. L Place the original for user stamp on the exposure glass, and then press [Start Scanning]. The original is scanned, and the stamp is registered. Note ❒ Originals cannot be scanned from the ADF when programming the user stamp. D Press [Stamp]. E Press [User Stamp]. F Press [Program / Delete Stamp].
JupiterC2_GB_Copy_F_FM.book Page 74 Friday, January 20, 2006 7:37 PM Copying D Press [Stamp]. E Press [User Stamp]. F Press [Program / Delete Stamp]. G Press [Delete], and then press the Stamp position and original orientation stamp number you want to delete. 2 H Select [Delete], and then press [Exit]. I Press [Exit]. The Copier / Document Server Features main menu is displayed. J Press [Exit]. Exits settings and gets ready to copy. Date Stamp You can use this function to print dates onto copies.
JupiterC2_GB_Copy_F_FM.book Page 75 Friday, January 20, 2006 7:37 PM Copier Functions A Press [Edit / Colour Creation]. To change the date format A Press [Change Format]. 2 B Press [Stamp]. C Press [Date Stamp]. D Press [All Pages] or [1st Page Only] to B Select the date format, and then press [OK]. select the print page. To change the stamp position A Press [Change]. B Select the date stamp position, and then press [OK]. Note ❒ You can change the colour, format and position of the date stamp.
JupiterC2_GB_Copy_F_FM.book Page 76 Friday, January 20, 2006 7:37 PM Copying There are six types of Page Numbering (“n” is the total number of pages in original): • P1, P2,…Pn • 1/n, 2/n,...n/n • -1-, -2-,...-n• P.1, P.2,...P.n • 1, 2…n • 1-1, 1-2,..1-n 2 p.121 “Page Numbering in Combine” p.122 “Stamp Position” p.122 “Superimpose” p.122 “Stamp Colour” A Press [Edit / Colour Creation]. Stamp position and orientation of originals B Press [Stamp]. C Press [Page Numbering]. D Select the format.
JupiterC2_GB_Copy_F_FM.book Page 77 Friday, January 20, 2006 7:37 PM Copier Functions Changing the stamp colour A Press [Stamp Colour]. B Select the stamp colour, then press B Press [First Printing Page], then en- ter the original page number from which to start printing using the number keys, and then press the {#} } key. [OK]. 2 To change the stamp position A Press [Change]. B Select the position, and then press [OK].
JupiterC2_GB_Copy_F_FM.book Page 78 Friday, January 20, 2006 7:37 PM Copying D Press [Last Number], enter the number of the page to stop numbering using the number keys, and then press the {#} } key. ❒ To change the number entered, press [Clear] or the {Clear/Stop} } k ey , an d t he n e n t er a ne w number. C Press [Numbering from / to], then en- ter the number of page from which to start numbering using the number keys, and then press the {#} } key.
JupiterC2_GB_Copy_F_FM.book Page 79 Friday, January 20, 2006 7:37 PM Copier Functions If you selected (1-1, 1-2,…) A Press [Change] on the right hand side. B Press [First Printing Page], and then enter the original page number from which to start printing using number keys, and then press the {#} } key. Note ❒ To change the number entered, press [Clear] or the {Clear/Stop} } k ey , an d th e n e n t er a n e w number. C Press [First Chapter No.
JupiterC2_GB_Copy_F_FM.book Page 80 Friday, January 20, 2006 7:37 PM Copying ❖ Front/Back covers The first and last page of original is copied onto a specified cover sheet paper. • Copy Designate You can use this function to copy certain pages of your original onto slip sheets. 2 GCCOVE0J • Blank Reference p.116 “Front Cover Copy in Combine” A Press [Cover / Slip Sheet]. Preparation Before using this function, set the special paper tray for slip sheets.
JupiterC2_GB_Copy_F_FM.book Page 81 Friday, January 20, 2006 7:37 PM Copier Functions D Enter the page number of the original's location you want to copy onto a slip sheet with the number keys, and then press the {#} } key. E To specify another page, repeat steps C to D. Note ❒ You can specify up to 20 pages. ❒ This function can be used only when you select the Duplex (1 Sided→2 Sided) or Combine function. A Press [Cover / Slip Sheet]. 2 Note ❒ To select chapters 11 to 20, press [T T11~20].
JupiterC2_GB_Copy_F_FM.book Page 82 Friday, January 20, 2006 7:37 PM Copying Slip Sheets Every time the originals' page changes, a slip sheet is inserted. This function can be used to automatically insert a slip sheet between OHP transparencies, or as a stacking function. You can also copy onto slip sheets. 2 Note ❒ Press the {#} } key and select [OHP Sheet] in Special paper. See p.24 “When copying onto OHP Transparencies or Thick Paper”.
JupiterC2_GB_Copy_F_FM.book Page 83 Friday, January 20, 2006 7:37 PM Storing Data in the Document Server Storing Data in the Document Server The Document Server enables you to store documents in memory and print them as you want. Important ❒ Machine failure can result in data loss. Important data stored on the hard disk should be backed up. The manufacturer shall not be responsible for any damage that might result from loss of data.
JupiterC2_GB_Copy_F_FM.book Page 84 Friday, January 20, 2006 7:37 PM Copying ❒ To check that the document has been stored, press the { Document Server} } key to display the document selection screen. ❒ When the machine is printing a document stored using the copier function, wait until printing has finished before you store another copy document. ❒ To print stored documents, see “Printing Stored Documents”, General Settings Guide.
JupiterC2_GB_Copy_F_FM.book Page 85 Friday, January 20, 2006 7:37 PM Programs Programs You can store frequently used copy job settings in machine memory and recall them for future use. Note ❒ You can store up to 10 programs. ❒ You can select the standard mode or Program No.10 as the default mode to be set when modes are cleared or reset, or immediately after the operation switch is turned on. See p.112 “Change Initial Mode”. ❒ Paper settings are stored based on paper size.
JupiterC2_GB_Copy_F_FM.book Page 86 Friday, January 20, 2006 7:37 PM Copying F Press [OK]. When the settings are successfully stored, the program name is displayed on the right side of the registered program number. The display returns to the initial copy display for a while. 2 Changing a stored program A Check the program settings. D Press [Yes]. The program is deleted, and the display returns to the initial copy display. Recalling a Program A Press the {Program}} key. B Press [Recall].
JupiterC2_GB_Copy_F_FM.book Page 87 Friday, January 20, 2006 7:37 PM 3. Colour Adjustment/Program Colour Adjustment This function lets you alter up to three single colours by mixing them with adjacent colours in the colour circle. Reference For types and examples of image adjustment functions, see p.iii “What You Can Do with This Machine ”. Note ❒ You can adjust up to 3 colours from yellow, red, magenta, blue, cyan, or green at the same time.
JupiterC2_GB_Copy_F_FM.book Page 88 Friday, January 20, 2006 7:37 PM Colour Adjustment/Program Colour Balance You can adjust the overall colour tone when the overall copy is reddish or bluish. Reference For types and examples of the image adjustment functions, see p.iii “What You Can Do with This Machine ”. 3 A Press the {Adjust/Program Colour} } key. ZFNS014E B Make sure that [Colour Balance] is selected.
JupiterC2_GB_Copy_F_FM.book Page 89 Friday, January 20, 2006 7:37 PM Colour Balance Changing the registered settings A Press the {Adjust/Program Colour}} key. B Make sure that [Colour Balance] is selected, and then press [Program Colour Balance]. C Select the program number (1–3) D Press [OK]. E Place the originals, and then press the {Start} } key.
JupiterC2_GB_Copy_F_FM.book Page 90 Friday, January 20, 2006 7:37 PM Colour Adjustment/Program Image Adjustment Reference For types and examples of the image adjustment functions, see p.iii “What You Can Do with This Machine ”. You can make the following types of image adjustments. 3 ❖ Sharp / Soft Adjusts the outline of an image. ❖ Contrast Adjusts the shades of an image. ❖ Background Density Adjusts the background density of an image. ❖ Adjust U.C.R.
JupiterC2_GB_Copy_F_FM.book Page 91 Friday, January 20, 2006 7:37 PM Image Adjustment Adjusting the background density A Adjust by pressing [Lighter] or [Darker]. Note ❒ Adjust to a lighter density when copying dark textured originals, such as newspaper or recycled paper. ❒ Adjust to a darker density when darkening the colour of markers or highlighters. However, highlighter pen colours are difficult to reproduce.
JupiterC2_GB_Copy_F_FM.book Page 92 Friday, January 20, 2006 7:37 PM Colour Adjustment/Program User Colour You can register colours created by adjusting the density of yellow, magenta, cyan, and black. You can also name the colours that you register, and print out registered colours. Reference For types and examples of the image adjustment functions, see p.iii “What You Can Do with This Machine ”.
JupiterC2_GB_Copy_F_FM.book Page 93 Friday, January 20, 2006 7:37 PM User Colour Note ❒ Press [Custom Setting] to directly specify the density of each colour with the number keys. See p.93 “Mixing Colours Manually with the Number Keys” Selecting from user colours A Press [User Colour]. B Select from the registered colours. E Specify the colour density. ❒ If you enter the wrong densit y , p r e s s [ Cl e a r] o r t h e {Clear/Stop} } key, and then reenter the correct density.
JupiterC2_GB_Copy_F_FM.book Page 94 Friday, January 20, 2006 7:37 PM Colour Adjustment/Program F Enter the density in percentages (%) with the number keys, and then press [#]. When renaming a colour A Press [Change Name]. B Enter the name of the colour (up to 16 characters can be used), and then press [OK]. 3 Reference “Entering Text” General Settings Guide. G Check the names of each colour, and then press [OK]. Note ❒ Repeat steps E to G if you want to specify the density of multiple colours.
JupiterC2_GB_Copy_F_FM.book Page 95 Friday, January 20, 2006 7:37 PM 4. Troubleshooting If Your Machine Does Not Operate As You Want When a Message Is Displayed The following chart contains explanations of common messages. If other messages are displayed, then follow the instructions as displayed. Note ❒ For messages not listed here, see “Troubleshooting”, General Settings Guide. Message Causes Solutions Cannot detect original size. An irregular original is placed. See p.11 “Sizes difficult to detect”.
JupiterC2_GB_Copy_F_FM.book Page 96 Friday, January 20, 2006 7:37 PM Troubleshooting Message Causes Solutions Cannot staple paper of this size. The Staple function cannot be used with the paper size selected. Select a paper size that can be used with the Staple function. See p.131 “Staple”. Duplex is not available with this paper size. A paper size not available when using the Duplex function has been selected. Select a proper paper size. See p.134 “Duplex”. Maximum number of sets is *.
JupiterC2_GB_Copy_F_FM.book Page 97 Friday, January 20, 2006 7:37 PM If You Cannot Make Clear Copies If You Cannot Make Clear Copies Problem Causes Solutions Copies appear dirty. The image density is too dark. Adjust the image density. See p.32 “Adjusting Copy Image Density”. Auto Image Density is not selected. Select Auto Image Density. See p.32 “Adjusting Copy Image Density”. The reverse side of an orig- The image density is too inal image is copied. dark.
JupiterC2_GB_Copy_F_FM.book Page 98 Friday, January 20, 2006 7:37 PM Troubleshooting If You Cannot Make Copies As You Want This section explains causes of, and remedies for, unexpected copy results. ❖ Basic Problem Causes Solutions Copies are not stapled. There are jammed staples in the stapler. Remove jammed staples. See “Removing Jammed Staples”General Settings Guide. Note ❒ After removing jammed staples, staples might not eject the first few times you try to use the stapler.
JupiterC2_GB_Copy_F_FM.book Page 99 Friday, January 20, 2006 7:37 PM If You Cannot Make Copies As You Want ❖ Edit Problem Causes When using the Double Copies function, parts of the original image are not copied. The original and copy pa- Select A3L for A4 K originals and per combination is not cor- A4 for A5 originals. See p.63 “Dourect. ble Copies”. When using the Border, You set a wide erased marCentre, or Centre/Border gin. function, parts of the original image are not copied.
JupiterC2_GB_Copy_F_FM.book Page 100 Friday, January 20, 2006 7:37 PM Troubleshooting ❖ Combine Problem Causes Solutions You cannot fold copies into a book using the Magazine or Booklet function. Combine Original Magazine Format is not set correctly. Change the setting. When using the Combine function, parts of the image are not copied. You specified a reproduction ratio that does not match the sizes of originals and copy paper.
JupiterC2_GB_Copy_F_FM.book Page 101 Friday, January 20, 2006 7:37 PM If You Cannot Make Copies As You Want When Memory Is Full Note ❒ If you set [Memory Full Auto Scan Restart] in User Tools (see p.122 “Memory Full Auto Scan Restart” ) to [Yes], even if memory becomes full, the memory overflow message will not be displayed. The machine will make copies of scanned originals first, then automatically scan and copy remaining originals. When this happens, the resulting sorted pages will not be sequential.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 103 Friday, January 20, 2006 7:37 PM 5. User Tools (Copier / Document Server Features) User Tools Menu (Copier / Document Server Features) User Tools Item Names Default Settings 1 General Features P.1/5 See p.111 “General Features P. /5”.
JupiterC2_GB_Copy_F_FM.book Page 104 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) User Tools Item Names Default Settings General Features P.4/5 See p.113 “General Features P.4/5”. Document Server Storage Key:F1~F5 • F1: 2 Sided Original Top to Top • F2: 1 Sided→1 Sided Combine • F3: 1 Sided→1 Sided Combine: 4 originals • F4: 1 Sided→1 Sided Combine: 8 originals • F5: Create Margin General Features P.5/5 See p.113 “General Features P.5/5”.
JupiterC2_GB_Copy_F_FM.book Page 105 Friday, January 20, 2006 7:37 PM User Tools Menu (Copier / Document Server Features) User Tools Item Names Default Settings Reproduction Ratio P.2/2 See p.114 “Reproduction Ratio P.2/2”.
JupiterC2_GB_Copy_F_FM.book Page 106 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) User Tools Item Names Default Settings Edit P.2/2 See p.116 “Edit P.2/3”. Front Cover Copy in Combine Combine Copy Order in Combine From Left to Right Copy on Designating Paper Yes Copy on Designating Page in Combine Combine Orientation: Booklet, Magazine Open to Left 3 3 Edit P. /3 See p.117 “Edit P. /3”.
JupiterC2_GB_Copy_F_FM.book Page 107 Friday, January 20, 2006 7:37 PM User Tools Menu (Copier / Document Server Features) User Tools Item Names User Stamp Default Settings Program / Delete Stamp Stamp Position: 1~4 Metric version • Position: Top Right • Top Margin: 24mm • Right Margin: 24mm Inch version • Position: Top Right • Top Margin: 1.0" • Right Margin: 1.
JupiterC2_GB_Copy_F_FM.book Page 108 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) User Tools Item Names Page Numbering Default Settings Stamp Format P1, P2... Font Font 1 Size Auto Duplex Back Page Stamping Position Opposite Position Page Numbering in Combine Per Original Stamp on Designated Slip Sheet Stamp Position: No Metric version • Position P1, 1/5, P.1, 1: Top Right -1-, 1-1: Bottom Centre • Top/Bottom Margin P1, 1/5, P.
JupiterC2_GB_Copy_F_FM.book Page 109 Friday, January 20, 2006 7:37 PM User Tools Menu (Copier / Document Server Features) User Tools Item Names Default Settings Adjust Colour Image See p.123 “Adjust Colour Image”. Background Density of ADS(Full Colour / Two-colour) Centre of the 5 level adjustment Colour Sensitivity Centre of the 5 level adjustment A.C.S. Sensitivity Centre of the 5 level adjustment A.C.S. Priority Full Colour Administrator Tools See p.124 “Administrator Tools”.
JupiterC2_GB_Copy_F_FM.book Page 110 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) Accessing User Tools (Copier / Document Server Features) This section is for key operators in charge of this machine. With User Tools can change the machine's default settings. Note ❒ Be sure to exit User Tools and return to the initial copy display after all settings are finished. This section describes system settings you can set for the copier function.
JupiterC2_GB_Copy_F_FM.book Page 111 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools Settings You Can Change with User Tools General Features P.1/5 ❒ If you select [Hide], the display is as below. ❖ Auto Paper Select Priority Auto Paper Select is the default setting. You can cancel this setting. See p.34 “Selecting Copy Paper”. Note ❒ Default: On ❖ Paper Display You can choose to have the available paper trays and sizes shown on the initial display.
JupiterC2_GB_Copy_F_FM.book Page 112 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) Note ❒ Default: With Image Rotation ❒ [With Image Rotation] Use to copy w he n usin g th e Au to T ray Switching function. ❒ [Without Image Rotation] Only copies with Auto Tray Switching if you load paper of the same size and in the same orientation in two or more trays. If the paper is not the same size or in the same orientation, copying is interrupted and the message “Load paper.
JupiterC2_GB_Copy_F_FM.book Page 113 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools General Features P.3/5 ❖ Copy Function Key: F1-F5 You can assign frequently used functions to function keys F1 to F5.
JupiterC2_GB_Copy_F_FM.book Page 114 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) ❖ Auto Image Density Priority You can set whether Auto Image Density is “On” or “Off” when the machine is turned on, reset, or modes are cleared. Note ❒ Default: Full Colour/Two-colour: Off, B&W/Single Colour: On ❒ When using the Auto Colour Select function, the settings of Full Colour/Two-colour will be effective. Reproduction Ratio P.
JupiterC2_GB_Copy_F_FM.book Page 115 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools Note ❒ Default: • Metric version: • Reduce 1: 25% • Reduce 2: 50% • Reduce 3: 65% • Reduce 4: 71% • Reduce 5: 75% • Reduce 6: 82% • Inch version: • Reduce 1: 25% • Reduce 2: 50% • Reduce 3: 65% • Reduce 4: 73% • Reduce 5: 78% • Reduce 6: 85% ❒ When selecting [User Redc.Ratio], enter a ratio using the number keys (in the range of 25 to 99%).
JupiterC2_GB_Copy_F_FM.book Page 116 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) ❖ Front Margin: Top/Bottom You can specify top and bottom margins on the front side of copies using the Margin Adjustment function. Note ❒ Default: • Metric version: T/B 0 mm • Inch version: T/B 0.0" ❖ Back Margin: Top/Bottom You can specify top and bottom margins on the back side of copies using the Margin Adjustment function.
JupiterC2_GB_Copy_F_FM.book Page 117 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools Note ❒ Default: Combine Edit P.3/3 ❖ Copy Order in Combine You can set the copy order when using the Combine function to Left to Right or Top to Bottom. ❖ Image Repeat Separation Line You can select a separation line and colour using the Image Repeat function from: None, Solid, Broken A, Broken B, or Crop Marks.
JupiterC2_GB_Copy_F_FM.book Page 118 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) ❒ An image of approximately 1.5mm will not be displayed as the width of the separation line, when specifying solid or broken lines. ❖ Double Copies Separation Line You can select a separation line using the Double Copies function from: None, Solid, Broken A, Broken B, or Crop Marks.
JupiterC2_GB_Copy_F_FM.book Page 119 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools ❒ Line colour (Full Colour): Yellow, Red, Cyan, Magenta, Green, Blue, Black ❒ Separation lines cannot be specified when using [None].
JupiterC2_GB_Copy_F_FM.book Page 120 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) Note ❒ Default: Normal ❒ Normal: The stamp is printed on the image. You cannot check which parts will overlap. ❒ Lighter: The image can be seen through the stamp. ❒ Lightest: The image appears ev en c le are r t ha n in t he Lighter setting. • Page to Stamp You can have the stamp printed on the first page or all pages.
JupiterC2_GB_Copy_F_FM.book Page 121 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools ❖ Font You can select the Date Stamp font. Note ❒ Default: Font 1 ❒ This setting is linked to the Page Numbering function. ❖ Stamp Position You can set the position where the stamp is printed. Press the arrow keys to adjust the position. Note ❒ Default: • Metric version: • Position: Top Left • Top Margin: 8 mm • Left Margin: 32 mm • Inch version: • Position: Top Left • Top Margin: 0.
JupiterC2_GB_Copy_F_FM.book Page 122 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) ❖ Stamp on Designated Slip Sheet You can print the page number on slip sheets when you use the Designate function set to "Copy" and Page Numbering function together. ❖ Stamp Position P1, P2... Stamp Position: 1/5, 2/5... Stamp Position: –1–, –2–... Stamp Position: P.1, P.2. Stamp Position: 1, 2... Stamp Position: 1–1, 1–2... You can set the position where the stamp is printed.
JupiterC2_GB_Copy_F_FM.book Page 123 Friday, January 20, 2006 7:37 PM Settings You Can Change with User Tools Note ❒ If you select [No] : • When memory becomes full, the machine stops operation, allowing you to remove the copies on the output tray. ❒ If you select [Yes] : • You can leave the machine unattended to make copies, but sorted pages will not be sequential. ❒ Default: No ❖ Select Stack Function Specify whether Stack or Rotate Sort has priority on the initial display.
JupiterC2_GB_Copy_F_FM.book Page 124 Friday, January 20, 2006 7:37 PM User Tools (Copier / Document Server Features) Note ❒ Default: Centre of the 5 level adjustment ❖ A.C.S. Priority This setting determines the copy priority between “Black & White” and “Full Colour” when “Auto Colour Select” is selected. Note ❒ Default: Full Colour Administrator Tools ❖ Menu Protect You can prevent unauthenticated users from changing the user tools settings. For details, consult the administrator.
JupiterC2_GB_Copy_F_FM.book Page 125 Friday, January 20, 2006 7:37 PM 6. Specifications Combination Chart The combination chart below shows which functions can be used together. The following tables explains the symbols used in the chart. means that these functions can be used together. $ means that these functions cannot be used together. The second function selected will be the function you are working in. × means that these functions cannot be used together.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 127 Friday, January 20, 2006 7:37 PM Supplementary Specifications Supplementary Specifications ❖ Mixed Size mode • Since small originals may not be correctly aligned with the original guide, the copy image may be slanted. • Copying speed and scanning speed will be reduced. • You can place originals of two different sizes at a time.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 130 Friday, January 20, 2006 7:37 PM Specifications Paper size and orientation 2 tray finisher Paper capacity and weight Finisher shift tray 1 A4KL, B5 JISKL, A5K, 81/2" × 11"KL 500 sheets (80 g/m2) (20 lb.) A3L, B4 JISL, 11" × 17"L, 81/2" × 14"L 250 sheets (80 g/m2) (20 lb.) Finisher shift tray 2 (No staple) A4K, 81/2" × 11"K 2000 sheets (80 g/m2) (20 lb.) A3L, B4 JISL, A4L, B5 JISKL, 11" × 17"L, 81/2" × 14"L, 81/2" × 11"L 750 sheets (80 g/m2) (20 lb.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 132 Friday, January 20, 2006 7:37 PM Specifications Note ❒ When stapling B4L, A3L, 81/2" × 14"L, 11" × 17"L, pull out the extender of the finisher tray. ❒ When the number of copies exceeds tray capacity, copying stops. If this happens, remove the copies from the shift tray, and then resume copying. • The tray capacity for the stapled sheets is as follows: (paper weight: 80 g/m2, 20 lb.
JupiterC2_GB_Copy_F_FM.book Page 133 Friday, January 20, 2006 7:37 PM Supplementary Specifications • When using [Top Slant], [Left 2] or [Top 2] with Combine, Double copies or Auto Reduce / Enlarge function, “Blank part will appear. Check orientation.”message may appear depending on the orientation of originals and paper you placed. In this case, change the paper orientation.
JupiterC2_GB_Copy_F_FM.book Page 134 Friday, January 20, 2006 7:37 PM Specifications Booklet finisher Punch kit type 2 holes type 4 holes type 2 holes 4 holes L A3, A4, B4 JIS, B5 JIS, 11" × 17", 81/2" × 14", 81/2" × 11" K A4, B5 JIS, 81/2" × 11" L A3 K A4 • The punch hole positions change according to the orientation of the paper selected.
JupiterC2_GB_Copy_F_FM.book Page 135 Friday, January 20, 2006 7:37 PM Supplementary Specifications • If the number of originals placed is less than the number specified for combining, the last page segment will be left blank as shown. ❖ Series Copies • The machine sets the reproduction ratio automatically to meet the paper size and copies the originals together onto the paper. • The reproduction ratios you can specify are 25–400%.
JupiterC2_GB_Copy_F_FM.book Page 136 Friday, January 20, 2006 7:37 PM Specifications ❖ Erase The width of the erased margin varies depending on the reproduction ratio.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 138 Friday, January 20, 2006 7:37 PM Specifications If you combine this function with the Duplex (Top to Top) function and select [P1, P2] or [1/n, 2/n], page numbers on the back are printed as follows: GCSTMPBE 1. Front 2. Back ❖ Front Cover, Front/Back Cover • If Blank mode is selected, the cover will not be counted as a copy. • Front and back covers are two-sided copied depending on the settings made in Display Time in Cover Sheet Tray of User Tools (System Settings).
JupiterC2_GB_Copy_F_FM.book Page 139 Friday, January 20, 2006 7:37 PM INDEX 1 sided → 2 sided, 53 2 sided → 1 sided, 53 2 sided → 2 sided, 53 90° turn, 14 A Accessing user tools copier/document server features, 110 A.C.S. priority, 124 sensitivity, 123 Adjust Colour Image, 123 Adjusting background density, 91 colours based on selected colour, 92 contrast, 90 copy image density, 32 sharpness/softness, 90 text/photo sensitivity, 91 U.C.R.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 141 Friday, January 20, 2006 7:37 PM original type priority, 111 paper display, 111 tone − original remains, 112 two-colour mode priority, 113 Generation copy, 33 Messages, 95 Missing image area, 12 Mixed size, 16 N Number keys, 6 I Image adjustment, 90 background density, 90, 91 contrast, 90 sharpness/softness, 90 text/photo sensitivity, 90, 91 U.C.R.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.
JupiterC2_GB_Copy_F_FM.book Page 1 Friday, January 20, 2006 7:37 PM Declaration of Conformity “The Product complies with the requirements of the EMC Directive 89/336/EEC and its amending directives and the Low Voltage Directive 73/23/EEC and its amending directives.” In accordance with IEC 60417, this machine uses the following symbols for the main power switch: a means POWER ON. b means POWER OFF. c means STAND BY. Trademark Acrobat® is a registered trademark of Adobe Systems Incorporated.
