RIGOL Chapter 6 Operations and Measurements
6-38 MSO5000-E User Guide
parameters:
--Press Top to select "Histogram" or "Max-Min".
--Press Base to select "Histogram" or "Max-Min".
Remove the Measurement Result
This oscilloscope allows you to remove the measurement results of the parameters.
Press Measure Remove to enter the "Remove" sub-menu.
Press Remove to remove the last added measurement item. Note that pressing
this key one time can only remove one measurement item. When you remove a
measurement item, the measurement result of the last added item at the
bottom of the screen will be removed. You can rotate the multifunction knob
to switch the measurement item, then press down the knob or press Remove
to remove the item. You can also enable the touch screen to tap the desired
measurement item, and then press Remove to remove the item.
Press Remove All to remove all the displayed measurement items.
Press Indicator to enable or disable the indicator.
Besides, you can also press Measure Add Remove to enter the "Remove"
sub-menu.
Statistical Function
Performs statistics and displays the measurement results (Cur, Avg, Max, Min, Dev,
and Cnt) of at most 10 items, as shown in the figure below.
Tip
Modifying the threshold will affect the measurement results of
the time, delay and phase parameters.
If you select "Manual" under Amp Method, the measurement
results of other parameters may be affected.
"Histogram" and "Max-Min" are the internal measurement
algorithm for the oscilloscope. The "Histogram" method here is
different from the Histogram function of the oscilloscope.
Tip
If the "Remove" sub-menu
is not displayed in the current menu, when you select
a certain measurement item, the system will automatically enter the "Remove"
sub-menu.
