RIGOL Chapter 12 Reference Waveform
12-4 MSO5000-E User Guide
To Reset the Reference Waveform
Press More Reset, and the reference waveform is restored to the position where
the source channel waveform is located when the SaveToRef operation was
executed.
Color Setting
MSO5000-E series oscilloscope provides five colors (gray, green, blue, red, and
orange) to mark the reference waveforms of different channels in order to distinguish
the reference waveforms of different reference waveform channels.
Press Color, and then rotate the multifunction knob to select the color of the
reference waveform of the channel. You can also press Color continuously or enable
the touch screen to select it. The GND icon and the label at the left side of the
waveform of the currently selected channel will be filled with the specified color. For
example,
and .
Label Setting
Press More Label to enter the label setting menu. You can use the built-in label in
the library or manually input a label. Three input methods are available for you to
input a label name, including Chinese, English, and Traditional Chinese.
Press Display continuously to enable or disable the display of the reference
waveform label. If it is enabled, the label will be displayed at the left side of the
waveform. If the current channel is REFn (n=1,2, …10), then the default label of
the reference waveform is REFn (n=1, 2, …10).
Press Library and rotate the multifunction knob to select the preset label,
and then press down the knob to select it. You can also press Library
continuously or enable the touch screen to select it. The available preset labels
include Default, ACK, ADDR, BIT, CLK, and etc.
Press Label, and the label editing interface is automatically displayed. You can
input the label manually. For the label editing methods, refer to descriptions in
"
Channel Label".
