RIGOL Chapter 19 System Utility Function Setting
19-12 MSO5000-E User Guide
Set the port
Press Port to set the protocol port in the pop-up numeric keypad. Its range
is from 0 to 65535.
Set the user name
Press UserName to set the user name of the server. For detailed setting
methods for the user name, refer to descriptions in "
To Create a Folder".
Set the password
Press PassWord to set the password of the server. For detailed setting
methods for the password, refer to descriptions in "
To Create a Folder".
Email test
Press Test to test whether the e-mail server is properly set.
Restore default settings
Press Default to restore the settings of receiver and mail settings to
defaults.
2. Set the Receiver
Press Receiver to display the receiver input interface, and you can edit the
email address of the receiver. For detailed input methods of the receiver email
address, refer to descriptions in "
To Create a Folder".
3. Upload Attachment
Press Attachment, then rotate the multifunction knob to select the
attachment type to be uploaded, and then press down the knob
to select it.
You can also press Attachment continuously to select or enable the touch
screen to tap the attachment. The available attachments include "Screen",
"Setup", and "Other". If you select "Other", you also need to press File Select
to select the file to be uploaded.
4. Send the Mail
Press Send Mail to send the edited email to the receiver.
Key Locker
You can set whether to lock the front-panel keys.
Press Utility More Key Locker to select "Locked" or "Unlocked".
Locked: indicates that all keys of the oscilloscope (except the Key Locker key)
are locked.
Unlocked: unlocks the front-panel keys.
