Video Trigger
The video signal can include image information and timing information, which adopts
different standards and formats. MSO5000-E series can trigger on the standard video
signal field or line of NTSC (National Television Standards Committee), PAL (Phase
Alternating Line), or SECAM (Sequential Couleur A Memoire).
Trigger Type:
Press Type, and then rotate the multifunction knob to select "Video". Press
down the knob to select the trigger type. Then, the current trigger setting
information is displayed at the upper-right corner of the screen, as shown in the
figure below. You can also press Type continuously or enable the touch screen to tap
the desired trigger type and select it.
Source Selection:
Press Source to switch the trigger source and select CH1-CH2. For details, refer to
descriptions in "
Trigger Source". The current trigger source is displayed at the
upper-right corner of the screen.
Note: Only when we select the channel (that has been input with signals) as the
trigger source, can we obtain a stable trigger.
Video Polarity:
Press Polarity continuously to select the desired video polarity. The polarities
available are positive polarity (
) and negative polarity ( ).
Video Standard:
Press Standard and rotate the multifunction knob to select the desired video
standard. You can also press Standard continuously to select the video standard or
enable the touch screen to tap the desired video standard and select it.
Video
Standard
Frame Frequency
(Frame)
Scan Type
TV Scan Line
NTSC
30
Interlaced Scan
525
PAL/SECAM
25
Interlaced Scan
625
480p/60Hz
60
Progressive Scan
525
576p/50Hz
50
Progressive Scan
625
720p/60Hz
60
Progressive Scan
750
720p/50Hz
50
Progressive Scan
750
720p/30Hz
30
Progressive Scan
750
720p/25Hz
25
Progressive Scan
750
720p/24Hz
24
Progressive Scan
750
1080p/60Hz
60
Progressive Scan
1125
1080p/50Hz
50
Progressive Scan
1125
