Data Sheet

2 Kleingehäuse KX/Technik im Detail
Kleingehäuse
Inhaltsverzeichnis
Klemmenkästen KX, ohne Flansch
Klemmenkästen KX, mit Flansch
E-Box KX
Bus-Gehäuse KX
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1500.000 150 150 120 4 – 5
1501.000 300 150 120 4 – 5
1502.000 200 200 120 4 – 5
1503.000 300 200 120 4 – 5
1504.000 400 200 120 4 – 5
1505.000 500 200 120 4 – 5
1506.000 600 200 120 4 – 5
1507.000 300 300 120 4 – 5
1508.000 400 300 120 4 – 5
1509.000 500 300 120 4 – 5
1510.000 600 300 120 4 – 5
1511.000 400 400 120 4 – 5
1512.000 600 400 120 4 – 5
1513.000 800 400 120 4 – 5
1514.000 150 150 80 4 – 5
1515.000 300 150 80 4 – 5
1516.000 200 200 80 4 – 5
1517.000 300 200 80 4 – 5
1518.000 400 200 80 4 – 5
1527.000 800 200 120 4 – 5
1528.000 200 150 80 4 – 5
1529.000 200 150 120 4 – 5
1589.000 400 150 120 4 – 5
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1530.000 300 150 120 4 – 5
1531.000 300 200 120 4 – 5
1532.000 400 200 120 4 – 5
1533.000 500 200 120 4 – 5
1535.000 300 300 120 4 – 5
1536.000 400 300 120 4 – 5
1537.000 500 300 120 4 – 5
1538.000 600 300 120 4 – 5
1539.000 400 400 120 4 – 5
1540.000 600 400 120 4 – 5
1541.000 800 400 120 4 – 5
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1545.000 150 300 80 6 – 7
1546.000 200 200 80 6 – 7
1547.000 200 400 80 6 – 7
1548.000 150 300 120 6 – 7
1549.000 200 200 120 6 – 7
1550.000 200 400 120 6 – 7
1551.000 150 150 80 6 – 7
1552.000 200 300 80 6 – 7
1553.000 150 150 120 6 – 7
1554.000 200 300 120 6 – 7
1555.000 300 300 120 6 – 7
1556.000 300 400 120 6 – 7
1557.000 200 500 120 6 – 7
1574.000 200 300 155 6 – 7
1575.000 300 300 155 6 – 7
1576.000 380 300 155 6 – 7
1577.000 300 400 155 6 – 7
1578.000 300 600 155 6 – 7
1579.000 300 800 155 6 – 7
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1610.000 400 200 155 8
1611.000 400 300 155 8
1612.000 600 300 155 8
1613.000 800 300 155 8
Kleingehäuse KX, Stahlblech
Klemmenkästen KX, ohne Flansch E-Box KX
Bus-Gehäuse KX
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1560.000 150 150 80 9
1561.000 300 150 80 9
1562.000 200 200 80 9
1563.000 300 200 80 9
1564.000 150 150 120 9
1565.000 200 200 120 9
1566.000 300 200 120 9
1567.000 300 300 120 9
1568.000 400 200 120 9
1569.000 400 300 120 9
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1301.000 200 300 155 10
1584.000 200 300 120 10
1587.000 200 300 155 10
1588.000 380 300 155 10
Best.-Nr. KX Breite mm Höhe mm Tiefe mm Seite
1583.000 200 300 80 11
1585.000 400 200 120 11
1586.000 600 200 120 11
Kleingehäuse KX, Edelstahl
