, OWNER S MANUAL CHECK Table of Contents 1. Safety Precautions and Warnings………………………………………......……………1 2. General Information…………………………………………………...........................................…1 2.1 On-Board Diagnostics (OBD)II………………………………………………................……1 2.2 Diagnostic Trouble Codes (DTCs)………………………………………………......……2 2.3 Location of the Data Link Connector (DLC)……………………………….....……3 2.4 OBD II Readiness Monitors………………………………………………......................……3 2.
CHECK , OWNER S MANUAL 6.8 Products Setup…………………………………………………................................................…35 6.9 Tool Information……………………………………………..............................................………42 6.10 Battery Replacement………………………………………………...............................……42 6.11 Vehicle Coverage………………………………………………….........................................…43 6.12 Product Trouble shooting……………………………………………….......................……43 7. Review Data………………………………………………….....................................
, OWNER S MANUAL CHECK 11.6 O2 Monitor Test………………………………………………..........................................……117 11.7 On-Board Monitor Test……………………………………...........................………………119 11.8 Component Test……………………………………………….........................................……121 11.9 Viewing Vehicle Information…………………………………................…………………123 11.10 Modules Present…………………………………………….....................................………124 12. Print Data…………………………………………………....................................................
CHECK , OWNER S MANUAL 1. Safety Precautions and Warnings To prevent personal injury or damage to vehicles and/or the scan tool, read this instruction manual first and observe the following safety precautions at a minimum whenever working on a vehicle: 1. Always perform automotive testing in a safe environment. 2. Wear safety eye protection that meets ANSI standards. 3. Keep clothing, hair, hands, tools, test equi pment, etc. away from all moving or hot engine parts. 4.
, OWNER S MANUAL CHECK The OBD II system is designed to monitor emission control systems and key engine components by performing either continuous or periodic tests of specific components and vehicle conditions. When a problem is detected, the OBD II system turns on a warning lamp (MIL) on the vehicle instrument panel to alert the driver typically by the phrase of "Check Engine" or "Service Engine Soon".
, OWNER S MANUAL CHECK 2.3 Location of the Data Link Connector (DLC) The DLC (Data Link Connector or Diagnostic Link Connector) is the standardized 16-cavity connector where diagnostic scan tools interface with the vehicle's on-board computer. The DLC is usually located 12 inches from the center of the instrument panel (dash), under or around the driver s side for most vehicles. If Data Link Connector is not located under dashboard, a label should be there telling location.
, OWNER S MANUAL CHECK Non-Continuous Monitors -- Unlike the continuous monitors, many emissions and engine system components require the vehicle to be operated under specific conditions before the monitor is ready. These monitors are termed non-continuous monitors and are listed below: 1).EGR System 2).O2 Sensors 3).Catalyst 4).Evaporative System 5).O2 Sensor Heater 6).Secondary air 7).Heated Catalyst 8).A/C system 2.
CHECK , OWNER S MANUAL 2.6 OBD II Definitions Powertrain Control Module (PCM) -- OBD II terminology for the onboard computer that controls engine and drive train. Malfunction Indicator Light (MIL) -- Malfunction Indicator Lig ht (Service Engine Soon, Check Engine) is a term used for the lig ht on the instrument panel. It is to alert the driver and/or the repair technician that there is a problem with one or more of vehicle's systems and may cause emissions to exceed federal standards.
, OWNER S MANUAL CHECK 2.7 Diagnostic Interface Vehicles must be equi pped with OBD Interface. Many manufacturers are using this interface approximately from year model 1995 on.The nterface is a 16-pin connection, which is located inside the cabin and should be reachable from driver seat. Pin ---- assignment of OBD Diagnostic outlet. PIN 7 and 15 ---- data transmission according to DIN ISO 9141-2. PIN 2 and 10 ---- data transmission according to SAE J1850.
CHECK , OWNER S MANUAL 1. LCD DISPLAY -- Indicates test results. Backlit,128 x 64 pixel display with contrast adjustment. 2. ENTER BUTTON -- Confirms a selection (or action) from a menu. Starts recording live data under manual trigger mode. 3. ESC BUTTON -- Cancels a selection (or action) from a menu or returns to the menu. It is also used to setup system, exit DTC Lookup screen,or stop data recording when pressed. 4.
, OWNER S MANUAL CHECK 3.2 Specifications 1) Display: Backlit,128 x 64 pixel display with contrast adjustment 2) Operating Temperature: 0 to 60°C (32 to 140 F°) 3) Storage Temperature: -20 to 70°C (-4 to 158 F°) 4) External Power: 8.0 to 18.0 V power provided via vehicle battery 5) Internal Power: 9V cell battery 6) Dimensions: Length Width Heig ht 209 mm (7.00”) 107 mm (3.74”) 37 mm (1.38”) 7) NW: 0.76kg (0.84lb), GW: 0.98 kg(1.21lb) 3.
CHECK , OWNER S MANUAL 4) "$"” -- Identifies the control module number from which data isretrieved. 3.5 Keyboard No solvents such as alcohol are allowed to clean the keypad or display. Use a mild nonabrasive detergent and a soft cotton cloth. Do not soak the keypad as the keypad is not waterproof. 3.6 Power Internal Battery Power The scan tool has a 9V cell battery that provides power for off-car reviewing and analysis. Press the power key to turn on the scan tool.
, OWNER S MANUAL CHECK Main Menu =======================-=2/5 Diagnostics DTC Lookup Review Data System Setup Tool Information The number “x/x” to the rig ht indicates total number of items under this menu and sequence of hig hlig hted item. 2) From DTC Lookup menu, use LEFT/RIGHT button to move to the desired character, use UP/DOWN button to change selected digit/ character and press ENTER button to confirm.
, OWNER S MANUAL CHECK 3.8 Product Setup The scan tool allows you to make the following adjustments and settings: 1) Language: Selects the desired language. 2) Contrast adjustment: Adjusts the contrast of the LCD display. 3) Unit of measure: Sets the unit of measure to English or Metric. 4) Auto Power-Off: Sets automatic power-off limits. 5) Beep Set: Turns on/off beep. 6) Tool self-test: Checks if the LCD display and keyboard are working normally.
, OWNER S MANUAL CHECK Language Setup English is the default language. 1) From System Setup menu, use UP/DOWN scroll button to select Language,and press ENTER button. System Setup =====================-=-=:1/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2) Use UP/DOWN scroll button to select the desired language and press ENTER button to save your selection and return to previous menu.
, OWNER S MANUAL CHECK Contrast =========================== (30%) Use to change 3) Press ENTER button to save your settings and return to previous menu. Unit of Measurement Metric is the default measurement unit. 1) From System Setup menu,use UP/DOWN scroll button to select Unit of Measure and press ENTER button.
, OWNER S MANUAL CHECK 3) Press ENTER button to save your selection and return to previous menu. Auto Power-off The minimum automatic power-off time is 1 minute, and the maximum is 20 minutes. The Auto Power-Off function can be available only when the scanner is powered by cell battery. 1) From System Setup menu,use UP/DOWN scroll button to select Auto Power-Off and press ENTER button.
, OWNER S MANUAL CHECK 2) From Beep Set menu, use UP/DOWN scroll button to select Beep ON or Beep OFF to turn on/off the beep. Beep Set ========================2/2 Beep ON Beep OFF 3) Press ENTER button to save your selection and return to previous menu. Tool Self-test The Tool Self-test function checks if the display and keyboard are working properly. A. Display test The Display Test function checks if the LCD display is working normally.
, OWNER S MANUAL CHECK 3) Press ENTER button again to start test. Look for missing spots in the solid black characters. 4) When completed,press ESC button to return. B.Keyboard Test The Keyboard Test function verifies if the keys are functioning properly. 1) Use UP/DOWN scroll button to select Keyboard Test from the Tool Self-test menu,and then press ENTER button. Tool Self-test ========================2/2 Display Test Keyboard Test 2) Press any key to start test.
, OWNER S MANUAL CHECK 1) From Main Menu, use UP/DOWN scroll button to select Tool Information and press ENTER button. Main Menu ========================5/5 Diagnostics DTC Lookup Review Data System Setup Tool Information 2) View tool information on screen. Tool Information =========================== Serial No : MS083462 Burn Date : 11/12/07 S/W Ver : V1.00 H/W Ver : V1.01 LIB Ver : V1.00 3.10 Battery Replacement The scan tool requires a 9V cell battery to operate when disconnected from vehicle power.
, OWNER S MANUAL CHECK A small number of 1994 and 1995 model year gasoline vehicles are OBD II compliant. To verify if a 1994 or 1995 vehicle is OBD II compliant, check the Vehicle Emissions Control Information (VECI) Label which is located under the hood or by the radiator of most vehicles.If the vehicle is OBD II compliant,the label will designate OBDII Certified”. Additionally, Government regulations mandate that all OBDII compliant vehicles must have a “common” sixteen-pin Data Link Connector (DLC).
CHECK , OWNER S MANUAL the following to reset the tool: Press and hold POWER button for at least 2 seconds to reset the scan tool. Turn the ignition off and wait for about 10 seconds. Turn the ignition back to on and continue the testing. Scan tool doesn’t power up If the scan tool won’t power up or operates incorrectly in any other way, you need to do the following to check up: Check if the scan tool’s OBD II connector is securely connected to the vehicle’s DLC; Check if the DLC pins are bent or broken.
, OWNER S MANUAL CHECK Review Data ========================1/5 Stored Codes Pending Codes Freeze Frame I/M Readiness Vehicle Info. If there is no data stored for selected item,a “Not Supported” or “Stored No Data!” message shows on the screen. 3) Review selected data on screen $09 1/6 P0118 Generic =========================== Engine Coolant Temperature Sensor 1 Circuit Hig h 5.
, OWNER S MANUAL CHECK Main Menu =========================== Diagnostics DTC Lookup Review Data System Setup 6 Press ENTER button to confirm. A sequence of messages displaying the OBD2 protocols will be observed on the display until the vehicle protocol is detected. If the scan tool fails to communicate with the vehicle’s ECU (Engine Control Unit), a “LINKING ERROR!” message shows up on the display.
, OWNER S MANUAL CHECK 8 If you wish to erase the data, press ENTER button; if you do not want to erase the data, press ESC or use LEFT/RIGHT button to select NO and press ENTER to continue. 9 View a summary of system status (MIL status,DTC counts, Monitor status) on screen. Wait a few seconds or press any key for Diagnostic Menu to come up.
, OWNER S MANUAL CHECK monitor codes”. They indicate problems that the control module has detected during the current or last driving cycle but are not considered serious yet. Pending Codes will not turn on the malfunction indicator lamp (MIL). If the fault does not occur within a certain number of warm-up cycles,the code clears from memory. 1) Use UP/DOWN scroll button to select Read Codes from Diagnostic Menu and press ENTER button.
, OWNER S MANUAL CHECK The control module number, sequence of the DTCs, total number of codes detected and type of codes (Generic or Manufacturer specific) will be observed on the upper rig ht hand corner of the display. 4) If more than one DTC is found, use UP/DOWN scroll button, as necessary,until all the codes have been shown up.
, OWNER S MANUAL CHECK Diagnostic Menu ========================2/6 Read Codes Erase Codes View Freeze Frame I/M Readiness Vehicle Info. Unit of Measure 2) A warning message comes up asking for your confirmation. Erase Codes =========================== Erase trouble codes! Are you sure? YES NO If you do not want to proceed with erasing codes, press ESC button or use LEFT/RIGHT scroll button to select NO to exit. A message of Command Cancelled!” show ups.
, OWNER S MANUAL CHECK Erase Codes =========================== Erase Failure. Turn Key on with Engine Off! Press any key to con 4) Press any button to return to Diagnostic Menu. 5.3 Viewing Freeze Frame Data 1) To view freeze frame data, use UP/DOWN scroll button to select View Freeze Frame from Diagnostic Menu and press ENTER button. Diagnostic Menu ========================3/6 Read Codes Erase Codes View Freeze Frame I/M Readiness Vehicle Info.
CHECK , OWNER S MANUAL If there is no freeze frame data available, an advisory message No freeze frame data stored!” shows on the display. 4) If you want to view full name of a PID, use UP/DOWN scroll button to select the PID. FUELSYS1 =========================== Fuel System 1 Status Press any key to con. 5) Wait a few seconds or press any button to return to previous screen. 5.
, OWNER S MANUAL CHECK completed its diagnostic testing. " N/A”" -- The monitor is not supported on that vehicle. 1) Use UP/DOWN scroll button to select I/M Readiness from Diagnostic Menu and press ENTER button. Diagnostic Menu ========================4/6 Read Codes Erase Codes View Freeze Frame I/M Readiness Vehicle Info. Unit of Measure 2) Wait a few seconds while the scan tool validates the PID MAP.
CHECK , OWNER S MANUAL Oxygen Sens Mon -- O2 Sensors Monitor Catalyst Mon -- Catalyst Monitor EVAP System Mon -- Evaporative System Monitor Oxygen Sens htr --O2 Sensor Heater Monitor Sec Air System -- Secondary Air Monitor Htd Catalyst -- Heated Catalyst Monitor A/C Refrig Mon -- A/C system Monitor Since DTCs Cleared =========================== MIL Status OFF Misfire Monitor OK Fuel System Mon OK Comp.
, OWNER S MANUAL CHECK Diagnostic Menu ========================5/6 Read Codes Erase Codes View Freeze Frame I/M Readiness Vehicle Info. Unit of Measure 2) Observe on-screen instruction Vehicle Info. =========================== Turn Key on with engine off Press any Key to con. 3) Wait a few seconds while the scan reads vehicle information Vehicle Info. =========================== Reading Info.
, OWNER S MANUAL CHECK Calibration ID =========================== Cal ID1: LMC720……… 6) Press ESC button to return to the previous menus. 6.Using the scan tool (Model RDT61) 6.
, OWNER S MANUAL CHECK 1. LCD DISPLAY -- Indicates test results. Backlit, 128 x 64 pixel display with contrast adjustment. 2. ENTER BUTTON -- Confirms a selection (or action) from a menu. Starts recording live data under manual trigger mode. 3. ESC BUTTON -- Cancels a selection/action from a menu or returns to the menu. It is also used to setup system, exit DTC Lookup screen, or stop data recording when pressed. 4.
CHECK , OWNER S MANUAL 4). External Power: 8.0 to 18.0 V power provided via vehicle battery 5). Internal Power: 9V cell battery 6). Dimensions: Length Width Heig ht 209 mm (7.00”) 107 mm (3.74”) 37 mm (1.38”) 7). NW: 0.76kg (0.84lb), GW: 0.98 kg(1.21lb 6.3 Accessories Included 1). User's Manual -- Instructions on tool operations. 2). CD -- Includes user’s manual, DTC lookup software,and etc. 3). OBD2 cable -- Provides power to tool and communicates between tool and vehicle. 4).
, OWNER S MANUAL CHECK 6.6 Power Internal Battery Power The scan tool can be inserted a 9V cell battery that provides power for off-car reviewing and analysis. Press the power key to turn on the scan tool. When the icon appears,replace the battery as instructed in Battery Replacement on paragraph 3.10. If the scan tool is stored for a long period of time, remove batteries to prevent battery leakage from damaging battery compartment.
, OWNER S MANUAL CHECK 2). From DTC Lookup menu,use LEFT/RIGHT button to move to the desired character,use UP/DOWN button to change selected digit/ character and press ENTER button to confirm. DTC Lookup ======================= P0001 [ ] – Left [ ] - Rig ht [ ][ ]- Change Digit [ENTER]- Confirm [ESC]- Exit 3). View the DTC definition on screen. When DTC definition covers more than one screen,use LEFT/RIHT button to view additional information on previous/next screens.
, OWNER S MANUAL CHECK 6). Tool self-test: Checks if the LCD display and keyboard are working normally. Settings of the unit will remain until change to the existing settings is made. To enter the setup menu mode From the keyboard: Press ESC button to enter System Setup menu. Follow the instructions to make adjustments and settings as described in the following setup options.
, OWNER S MANUAL CHECK System Setup ================= -=1/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2). Use UP/DOWN scroll button to select the desired language and press ENTER button to save your selection and return to previous menu. Language ====================1/5 English Français Deutsoh Dutch Espanol Contrast Adjustment 1). From System Setup menu,use UP/DOWN scroll button to select Contrast, and press ENTER button.
, OWNER S MANUAL CHECK Contrast ======================= (30%) Use to change 3). Press ENTER button to save your settings and return to previous menu. Unit of Measurement Metric is the default measurement unit. 1). From System Setup menu,use UP/DOWN scroll button to select Unit of Measure and press ENTER button. System Setup ========================-:3/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2).
, OWNER S MANUAL CHECK Auto Power-off The minimum automatic power-off time is 1 minute,and the maximum is 20 minutes. The Auto Power-Off function can be available only when the scanner is powered by cell battery. 1). From System Setup menu,use UP/DOWN scroll button to select Auto Power-Off and press ENTER button. System Setup ========================-:4/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2).
, OWNER S MANUAL CHECK System Setup ========================-:5/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2). From Beep Set menu,use UP/DOWN scroll button to select Beep ON or Beep OFF to turn on/off the beep. Beep Set ==========================2/2 Beep ON Beep OFF 3). Press ENTER button to save your selection and return to previous menu. Tool Self-test The Tool Self-test function checks if the display and keyboard are working properly. A.
, OWNER S MANUAL CHECK 2). Select Display Test from Tool Self-test menu and press ENTER button. Tool Self-test ==========================1/2 Display Test Keyboard Test 3). Press ENTER button again to start test. Look for missing spots in the solid black characters. 4). When completed,press ESC button to return. B. Keyboard Test The Keyboard Test function verifies if the keys are functioning properly. 1).
, OWNER S MANUAL CHECK If you press and hold the power switch,the key name does not show on the screen,but resets the scanner when powered by vehicle battery,or turns off the scanner when powered by cell battery. If it does not restart the scanner or power off the scanner, the key is not working properly. 3). Double press ESC to return to previous menu. 6.
CHECK , OWNER S MANUAL The scan tool requires a 9V cell battery to operate when disconnected from vehicle power. 1). Locate the battery cover on the back of the scan tool. 2). Remove the battery cover screw and slide the battery cover off. 3). Remove discharged batteries and install a new 9V cell battery. 4) Reinstall battery cover by sliding battery cover on and installing screw. 6.
, OWNER S MANUAL CHECK Check if the scan tool’s OBD II connector is securely connected to the vehicle's DLC; Verify that the vehicle is OBD2 compliant; Turn the ignition off and wait for about 10 seconds. Turn the ignition back to on and continue the testing. Verify the control module is not defective. Operating Error If the scan tool freezes, then an exception occurs or the vehicle's ECU (Engine Control Unit) is too slow to respond to requests.
, OWNER S MANUAL CHECK Main Menu ============================= Diagnostics DTC Lookup Review Data Tool Information 2). Use UP/DOWN scroll button to select the desired item from Review Data menu,and press ENTER button. Review Data ==========================1/9 Stored Codes Pending Codes Live Data Freeze Frame I/M Readiness O2 Monitor Test If no data from previously tested vehicle is recorded, only Module Present data containing module ID and protocol type can be reviewed.
, OWNER S MANUAL CHECK If there is no data stored for selected item, a "Not Supported or Stored No Data!" message shows on the screen. 8. OBD II Diagnostics When more than one vehicle control module is detected by the scan tool, you will be prompted to select the module where the data may be retrieved. The most often to be selected are the Powertrain Control Module [PCM] and Transmission Control Module [TCM]. CAUTION: Don't connect or disconnect any test equi pment with ignition on or engine running. 1.
, OWNER S MANUAL CHECK If the "LINKING ERROR" message does not go away, then there mig ht be problems for the scan tool to communicate with the vehicle. Contact your local distributor or the manufacturer's customer service department for assistance. 7. You will be prompted to erase previously stored data. Review previously stored data thoroug hly before erasing.
, OWNER S MANUAL CHECK Control Module ==========================1/2 Engine Module $A4 Use UP/DOWN scroll button to select a module and press ENTER button. 8.1 Reading Codes Reading Codes can be done with the key on engine off (KOEO) or with the key on engine running (KOER). Stored Codes are also known as hard codes”or permanent codes”. These codes cause the control module to illuminate the malfunction indicator lamp (MIL) when emission-related fault occurs.
, OWNER S MANUAL CHECK Trouble Codes ============================Stored Codes Pending Codes If there are no Diagnostic Trouble Codes present, the display indicates "No (pending) codes are stored in the module!" Wait a few seconds or press any key to return to Diagnostic Menu. 3). View DTCs and their definitions on screen.
, OWNER S MANUAL CHECK Vehicle Manufacturer =======================-=-1/11 Alfa Romeo Audi/VW BMW Buick Cadillac Chevrolet If the manufacturer for your vehicle is not listed,use UP/DOWN scroll button to select Other and press ENTER button. 8.2 Erasing Codes CAUTION: Erasing the Diagnostic Trouble Codes may allow the scan tool to delete not only the codes from the vehicle’s on-board computer,but also Freeze Frame data and manufacturer specific enhanced data.
, OWNER S MANUAL CHECK Erase Codes ============================= Erase trouble codes! Are you sure? YES NO If you do not want to proceed with erasing codes, press ESC button or use LEFT/RIGHT scroll button to select NO to exit. A message of "Command Cancelled!" show ups. Wait a few seconds or press any key to return to Diagnostic Menu. 3). Press ENTER button to confirm. If the codes are cleared successfully, an "Erase Done!" confirmation message shows on the display.
, OWNER S MANUAL CHECK 4). Press any button to return to Diagnostic Menu. 8.3 Live Data Viewing Data The View Data function allows viewing of live or real time PID data of vehicle’s computer module(s). 1). To view live data,use UP/DOWN scroll button to select Live Data from Diagnostic Menu and press ENTER button. Diagnostic Menu =========================3/11 Read Codes Erase Codes Live Data View Freeze Frame I/M Readiness O2 Monitor Test 2).
, OWNER S MANUAL CHECK Viewing Complete Data Set. 4). To view complete set of data,use UP/DOWN scroll button to select Complete Data Set from View Data menu and press ENTER button. View Data =========================1/3 Complete Data Set Custom Data Set Unit of Measure 5). View live PIDs on the screen. Use UP/DOWN scroll button for more PIDs if an or arrow appears on the screen. Live Data ===========================DTC_CNT 6 FUELSYS1 OL FUELSYS2 N/A LOAD_PCT (%) 0.0 G ETC( C ) -40 SHRTFT1 (%) 0.
, OWNER S MANUAL CHECK 8). Observe on-screen instructions. Custom Data Set ============================= [ ] -Select/Deselect [ ] -Deselect all [ENTER]- Confirm [ESC] - Cancel 9). Use RIGHT button to deselect/select data parameters,and use UP/ DOWN scroll button to move up and down. Selected parameters are marked with solid squares.
, OWNER S MANUAL CHECK If you decide to deselect these items,press ENTER; if you decide not to,press ESC or use UP/DOWN scroll button to select NO to continue PID selections. 10). Press ENTER button to view selected PIDs on screen. Live Data ============================= DTC_CNT FUELSYS2 ETC( C ) 4 6 N/A -40 11). Use ESC button to return to View Data menu and/or return to Live Data menu.
, OWNER S MANUAL CHECK Recording Complete Data Set 2). To record complete set of live data,use UP/DOWN scroll button to select Complete Data Set from Record Data menu and press ENTER button. Record Data… =========================1/3 Complete Data Set Custom Data Set Unit of Measure 3). Use UP/DOWN scroll button to select a trigger mode and press ENTER button.
, OWNER S MANUAL CHECK DTC Trigger… ============================= Waiting for DTC to trigger recording… Press [ESC] to exit 4). Use UP/DOWN scroll button to select a memory location and press ENTER button. Select Memory… ==========================1/3 Location #1 Location #2 Location #3 * The asterisk (*) icon on the screen indicates that there is a previous recording in the memory location.
, OWNER S MANUAL CHECK Manual Trigger… ============================= Ready to record! Press [ENTER] to start recording… Press [ESC] to exit If DTC Trigger is selected,following screen shows: DTC Trigger… ============================= Waiting for DTC to trigger recording… Press [ESC] to exit 6). Wait for DTC to trigger recording or press ENTER to startrecording. Drive till a DTC is detected when DTC Trigger is selected. If no DTCs are detected,press ESC to exit recording.
, OWNER S MANUAL CHECK Record Data… ============================= Record Done! Playback data? YES NO If you wish to playback recorded data,press ENTER button; if you do not wish to playback,press ESC button,or use LEFT/RIGHT button to select NO and press ENTER button to return to Record Data menu. Record Data =========================-=Complete Data Set Custom Data Set Unit of Measure Recording Custom Data Set 8).
, OWNER S MANUAL CHECK Custom Data Set ============================= [ ] -Select/deselect [ ] -Deselect all [ENTER] -Confirm [ESC] - Cancel 10). Use RIGHT button select/deselect data parameters. Selected parameters are marked with solid squares. Press ENTER button to confirm. Custom Data Set ============================= DTC_CNT #01 FUELSYS1 FUELSYS2 #02 LOAD_PCT(%) #03 ETC( C ) SHRTFT1(%) You are allowed to pick up a maximum of 18 PIDs.
, OWNER S MANUAL CHECK Custom Data Set =========================_=_5 DTC_CNT #01 FUELSYS1 FUELSYS2 #02 LOAD_PCT(%) #03 ETC( F ) SHRTFT1(%) 11). Use UP/DOWN scroll button to select a trigger mode and press ENTER button. Pick Trigger Mode =========================1/2 Manual Trigger DTC Trigger If data from previously tested vehicle is not erased,data from current test will be stored in temporary cache.
, OWNER S MANUAL CHECK 12). Use UP/DOWN scroll button to select a memory location and press ENTER button. Select Memory ==========================1/3 Location #1 * Location #2 Location #3 The asterisk (*) icon on the screen indicates that there is a previous recording in the memory location. If you select a location marked with an asterisk (*) icon,a message prompting to overwrite old recording is displayed.
, OWNER S MANUAL CHECK If DTC Trigger is selected,following screen shows: DTC Trigger ============================= Waiting for DTC to trigger recording… Press [ESC] to exit 14). Wait for DTC to trigger recording or press ENTER to start recording. Recording… 5/60 ………… ==========================_=6 DTC_CNT 6 FUELSYS1 OL FUELSYS2 N/A LOAD_PCT(%) 0.0 ETC( C) -40 SHRTFT1(%) 0.0 15).
, OWNER S MANUAL CHECK Record Data =========================-=-Complete Data Set Custom Data Set Unit of Measure Playing Back Data The Playback Data function allows viewing of previously stored PID data. 1). To playback recorded data, use UP/DOWN scroll button to select Playback Data from Live Data menu and press ENTER button. Live Data =========================3/3 View Data Record Data Playback Data You are also allowed to playback recorded data immediately after recording. 2).
CHECK , OWNER S MANUAL If there is no recording in selected location,a message "Not Supported or Stored No Data" displays on the screen. For data stored in temporary cache,you do not have to select memory location. 3). Use UP/DOWN button to view recorded PIDs of each frame. Playback …. -5/16 ………… ===========================-6 DTC_CNT 6 FUELSYS1 OL FUELSYS2 N/A LOAD_PCT(%) 0.0 ETC( C) -40 SHRTFT1(%) 0.
, OWNER S MANUAL CHECK Diagnostic Menu =========================4/11 Read Codes Erase Codes Live Data View Freeze Frame I/M Readiness O2 Monitor Test 2). Wait a few seconds while the scan tool validates the PID MAP. View Freeze Frame ============================ Reading PID.01 - Please Wait - 3). If retrieved information covers more than one screen,then a down arrow will appear. Use DOWN scroll button,as necessary,until all the data have been shown up.
, OWNER S MANUAL CHECK 5). Wait a few seconds or press any button to return to previous screen. 8.5 Retrieving I/M Readiness Status I/M Readiness function is used to check the operations of the Emission System on OBD2 compliant vehicles. It is an excellent function to use prior to having a vehicle inspected for compliance to a state emissions program. Some latest vehicle models may support two types of I/M Readiness tests: A.
, OWNER S MANUAL CHECK /M Readiness ============================ Reading PID… - Please Wait - 3). If the vehicle supports both types of tests,then both types will be shown on the screen for selection. I/M Readiness ============================ Since DTCs Cleared This Drive Cycle 4). Use UP/DOWN scroll button,as necessary,to view the status of the MIL lig ht ("ON" or "OFF") and the following monitors: Misfire monitor -- Misfire monitor Fuel System Mon -- Fuel System Monitor Comp.
, OWNER S MANUAL CHECK 5). If the vehicle supports readiness test of "This Drive Cycle",a screen of the following displays: This Drive Cycle ============================= MIL Status OFF Misfire Monitor OK Fuel System Mon N/A Comp. Component OK Catalyst Mon INC Htd Catalyst N/A 6). Press ESC button to return to Diagnostic Menu. 8.
, OWNER S MANUAL CHECK 2). Wait a few seconds while the scan tool validates the PID MAP. O2 Monitor Test ============================ Reading PID… - Please Wait - 3). Use UP/DOWN scroll button to select O2 sensor from O2 Monitor Test menu and press ENTER button. O2 Monitor Test ======================-=:=2/2 O2 Bank1 Sensor1 O2 Bank1 Sensor2 If the vehicle does not support the mode,an advisory message will be displayed on the screen.
, OWNER S MANUAL CHECK 5). Use UP/DOWN scroll button to view more screens of data if an icon displays. 6) Press ESC button to return to the previous menus. or 8.7 On-Board Monitor Test The On-Board Monitor Test is useful after servicing or after erasing a vehicle's control module memory. The On-Board Monitor Test for non-CANequi pped vehicles retrieves and displays test results for emission-related powertrain components and systems that are not continuously monitored.
, OWNER S MANUAL CHECK On-Board Mon. Test ============================ Test $01 Data Test $05 Data Test $09 Data If the vehicle under test does not support the mode,an advisory message will be displayed on the screen. On-Board Mon. Test ============================= The selected mode is not supported Press any key to con. For CAN-equi pped vehicles,test selections can be as below: On-Board Mon. ============================= O2 Mon. B1S1 O2 Mon. B1S2 Catalyst Mon. B1 EGR Mon. Bank1 4).
, OWNER S MANUAL CHECK For CAN-equi pped vehicles,test results displayed can be as below: O2 Mon. B1S1 ============================= Rich-Lean Threshd (MV) MEAS: MIN: MAX: STS: 0.450 0.312 0.630 OK 6). Press ESC button to return to the previous menus. 8.8 Component Test The Component Test function allows initiating a leak test for the vehicle's EVAP system. The scan tool itself does not perform the leak test,but commands the vehicle's on-board computer to start the test.
, OWNER S MANUAL CHECK 3). From Component Test menu,use UP/DOWN scroll button to select the test to be initiated. Component Test ========================-=1/1 Evap Leak Test 4). If the test has been initiated by the vehicle,a confirmation message will be displayed on the screen. Working ============================ Command Sent! Press any key to con. Some vehicles do not allow scan tools to control vehicle systems or components.
, OWNER S MANUAL CHECK Diagnostic Menu ========================-=9/11 On-Board Mon. Test Component Test Vehicle Info. Modules Present Unit of Measure 2). An advisory message comes up to remind you. Wait a few seconds or press any key to continue. Vehicle Info. ============================= Turn key on with engine off ! Press any key to con. 3). Wait a few seconds while the scan tool reads vehicle information. Vehicle Info.
, OWNER S MANUAL CHECK 5). View retrieved vehicle information on screen. Calibration ID ============================= Cal ID1: 30668343 Cal ID2: 08644359 6). Press ESC button to return previous menu 8.10 Modules Present The Modules Present function allows viewing of the module IDs and communication protocols for OBD2 modules in the vehicle. 1). Use UP/DOWN scroll button to select Modules Present from Diagnostic Menu and press ENTER button. Diagnostic Menu =======================-=10/11 On-Board Mon.
, OWNER S MANUAL CHECK 9. Using the scan tool (Model RDT69) 9.1 Tool Description 9 1 4 2 8 6 ENTER ESC 5 7 3 1.LCD DISPLAY -- Indicates test results. Backlit,128 x 64 pixel display with contrast adjustment. 2.ENTER BUTTON -- Confirms a selection (or action) from a menu. Starts recording live data under manual trigger mode. 3.ESC BUTTON -- Cancels a selection (or action) from a menu or returns to the menu.
, OWNER S MANUAL CHECK 4.LEFT SCROLL BUTTON -- When look up DTC definitions, moves to previous character and views additional information on previous screens if DTC definition covers more than one screen; deselect all marked PID data when viewing or recording customized live data list; views previous frames of recorded data when playing back live data. It is also used to update DTC library when pressed. 5.
CHECK , OWNER S MANUAL 5) Internal Power: 9V cell battery 6) Dimensions: Length Width Heig ht 209 mm (7.00”) 107 mm (3.74”) 37 mm (1.38”) 7) NW: 0.76kg (0.84lb), GW: 0.98 kg(1.21lb) 9.3 Accessories Included 1) User’s Manual -- Instructions on tool operations 2) CD -- Includes user’s manual,DTC lookup software,and etc. 3) OBD2 cable -- Provides power to tool and communicates between tool and vehicle 4) USB/Serial cable -- Used to upgrade the scan tool, and to print retrieved data.
, OWNER S MANUAL CHECK 9.5 Keyboard No solvents such as alcohol are allowed to clean the keypad or display. Use a mild nonabrasive detergent and a soft cotton cloth. Do not soak the keypad as the keypad is not waterproof. 9.6 Power Internal Battery Power The scan tool has a 9V cell battery that provides power for off-car reviewing and analysis. Press the power key to turn on the scan tool.
, OWNER S MANUAL CHECK 9.7 DTC Lookup The DTC Lookup function is used to search for definitions of DTCs stored in built-in DTC library. 1) From Main Menu, use UP/DOWN scroll button to select DTC Lookup and press ENTER button. Main Menu 2/6 ==================== Diagnostics DTC Lookup Review Data Print Data System Setup Tool Information The number “x/x” to the rig ht indicates total number of items under this menu and sequence of hig hlig hted item.
, OWNER S MANUAL CHECK 3) View the DTC definition on screen. When DTC definition covers more than one screen, use LEFT/RIGHT button to view additional information on previous/next screens. For manufacturer specific codes, you need to select a vehicle make on an additional screen to look for DTC definitions.
, OWNER S MANUAL CHECK System Setup ================= Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 1/6 From the Main Menu: Use the UP/DOWN scroll button to select System Setup,and press ENTER button. Follow the instructions to make adjustments and settings as described in the following setup options. System Setup ====================5/6 Diagnostics DTC Lookup Review Data Print Data System Setup Tool Information Language Setup English is the default language.
, OWNER S MANUAL CHECK 2) Use UP/DOWN scroll button to select the desired language and press ENTER button to save your selection and return to previous menu. Language ====================1/5 English Français Deutsoh Dutch Espanol Contrast Adjustment 1) From System Setup menu, use UP/DOWN scroll button to select Contrast,and press ENTER button.
, OWNER S MANUAL CHECK Unit of Measurement Metric is the default measurement unit. 1) From System Setup menu, use UP/DOWN scroll button to select Unit of Measure and press ENTER button. System Setup ====================3/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2) From Unit of Measure menu, use UP/DOWN scroll button to select the desired unit of measurement.
, OWNER S MANUAL CHECK System Setup ====================4/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2) From Auto Power-off menu,use UP/DOWN scroll button to increase or decrease time. Auto Power-off ======================= 01 Minute [ ] – Increase time [ ] – Decrease time [ENTER] - Confirm 3) Press ENTER button to save your setting and return to previous menu. Beep Set The default setting is Beep On.
, OWNER S MANUAL CHECK 2) From Beep Set menu,use UP/DOWN scroll button to select Beep ON or Beep OFF to turn on/off the beep. Beep Set ====================2/2 Beep ON Beep OFF 3) Press ENTER button to save your selection and return to previous menu. Tool Self-test The Tool Self-test function checks if the display and keyboard are working properly. A. Display test The Display Test function checks if the LCD display is working normally.
, OWNER S MANUAL CHECK Tool Self-test ====================1/2 Display Test Keyboard Test 3) Press ENTER button again to start test. Look for missing spots in the solid black characters. 4) When completed,press ESC button to return. B. Keyboard Test The Keyboard Test function verifies if the keys are functioning properly. 1) Use UP/DOWN scroll button to select Keyboard Test from the button.
, OWNER S MANUAL CHECK If you press and hold the power switch,the key name does not show on the screen, but resets the scanner when powered by vehicle battery, or turns off the scanner when powered by cell battery. If it does not restart the scanner or power off the scanner, the key is not working properly. 3) Double press ESC to return to previous menu. 9.
, OWNER S MANUAL CHECK 2) Remove the battery cover screw and slide the battery cover off. 3) Remove discharged batteries and install a new 9V cell battery. 4) Reinstall battery cover by sliding battery cover on and installing screw. 9.11 Vehicle Coverage This model T69 OBDII/EOBD Scanner is specially designed to work with all OBD II compliant vehicles,including those equi pped with next-generation protocol -- Control Area Network (CAN).
CHECK , OWNER S MANUAL Verify that the ignition is ON; Check if the scan tool’s OBD II connector is securely connected to the vehicle’s DLC; Verify that the vehicle is OBD2 compliant; Turn the ignition off and wait for about 10 seconds. Turn the ignition back to on and continue the testing. Verify the control module is not defective Operating Error If the scan tool freezes, then an exception occurs or the vehicle’s ECU (Engine Control Unit) is too slow to respond to requests.
, OWNER S MANUAL CHECK 1) Use UP/DOWN scroll button to select Review Data from Main Menu,and press ENTER button Main Menu ====================3/6 Diagnostics DTC Lookup Review Data Print Data System Setup Tool Information 2) Use UP/DOWN scroll button to select the desired item from Review Data menu,and press ENTER button.
, OWNER S MANUAL CHECK $09 1/6 Generic P0118 ======================= Engine Coolant Temperature Sensor 1 Circuit Hig h If there is no data stored for selected item, a “Not Supported or Stored No Data!” message shows on the screen. 11. OBD II Diagnostics When more than one vehicle control module is detected by the scan tool, you will be prompted to select the module where the data may be retrieved.
, OWNER S MANUAL CHECK 6 Press ENTER button to confirm. A sequence of messages displaying the OBD2 protocols will be observed on the display until the vehicle protocol is detected. If the scan tool fails to communicate with the vehicle’s ECU (Engine Control Unit), a “LINKING ERROR!” message shows up on the display.
, OWNER S MANUAL CHECK Diagnostic Menu to come up. System Status ======================= MIL Status Codes Found Monitors N/A Monitors OK Monitors INC ON 6 3 3 5 If more than one module is detected,you will be prompted to select a module before testing. Control Module ====================1/2 Engine Module $A4 Use UP/DOWN scroll button to select a module and press ENTER button. 11.1 Reading Codes Reading Codes can be done with the key on engine off (KOEO) or with the key on engine running (KOER).
, OWNER S MANUAL CHECK 1) Use UP/DOWN scroll button to select Read Codes from Diagnostic Menu and press ENTER button. Diagnostic Menu ====================1/11 Read Codes Erase Codes Live Data View Freeze Frame I/M Readiness O2 Monitor Test 2) Use UP/DOWN scroll button to select Stored Codes or Pending Codes from the Trouble Codes menu and press ENTER button.
, OWNER S MANUAL CHECK 4) If more than one DTC is found, use UP/DOWN scroll button, as necessary,until all the codes have been shown up. If retrieved DTCs contain any manufacturer specific or enhanced codes, a “Manufacturer specific codes are found! Press any key to select vehicle make!” message comes up prompting you to select vehicle manufacturer to view DTC definitions. Use UP/DOWN scroll button to select manufacturer and then press ENTER button to confirm.
, OWNER S MANUAL CHECK Diagnostic Menu ====================2/11 Read Codes Erase Codes Live Data View Freeze Frame I/M Readiness O2 Monitor Test 2)A warning message comes up asking for your confirmation. Erase Codes ======================= Erase trouble codes! Are you sure? YES NO If you do not want to proceed with erasing codes,press ESC button or use LEFT/RIGHT scroll button to select NO to exit. A message of "Command Cancelled!"” show ups.
, OWNER S MANUAL CHECK Erase Codes ======================= Erase Failure. Turn Key on with Engine Off! Press any key to con. 4) Press any button to return to Diagnostic Menu. 11.3 Live Data Viewing Data The View Data function allows viewing of live or real time PID data of vehicle’s computer module(s). 1) To view live data, use UP/DOWN scroll button to select Live Data from Diagnostic Menu and press ENTER button.
, OWNER S MANUAL CHECK LiveData ====================1/3 View Data Record Data Playback Data Viewing Complete Data Set 4) To view complete set of data, use UP/DOWN scroll button to select Complete Data Set from View Data menu and press ENTER button. View Data ====================1/3 Complete Data Set Custom Data Set Unit of Measure 5) View live PIDs on the screen. Use UP/DOWN scroll button for more PIDs if an or arrow appears on the screen.
, OWNER S MANUAL CHECK RPM (/min) 975 1725 925 6) Press ESC button to return to previous menu. Viewing Custom Data Set 7) To view customized PID data, use UP/DOWN scroll button to select Custom Data Set from View Data menu and press ENTER button. View Data ======================= Complete Data Set Custom Data Set Unit of Measure 8) Observe on-screen instructions.
, OWNER S MANUAL CHECK Custom Data Set ===================-==6 DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) #01 #02 #03 The number “x” to the upper rig ht corner of the screen indicates sequence of hig hlig hted item; and “#x” are the order that the parameters are selected and will be displayed. You are allowed to pick up a maximum of 18 PIDs. If the selected PIDs exceed 18, a “The selected data list is full!” message displays on the screen.
, OWNER S MANUAL CHECK 11) Use ESC button to return to View Data menu and/or return to Live Data menu. Recording Data The Record Data function allows recording vehicle modules’ Parameter Identification (PID) data to help diagnose intermittent vehicle problems. A recording includes 5 frames of live data before trigger event and several frames after trigger event. There are two trigger modes used to record data: A. Manual Trigger - allows user to press ENTER button to start recording. B.
, OWNER S MANUAL CHECK Record Data ====================1/3 Complete Data Set Custom Data Set Unit of Measure 3) Use UP/DOWN scroll button to select a trigger mode and press ENTER button. Pick Trigger Mode ====================1/2 Manual Trigger DTC Trigger If data from previously tested vehicle is not erased, data from current test will be stored in a temporary cache.
, OWNER S MANUAL CHECK 4) Use UP/DOWN scroll button to select a memory location and press ENTER button. Select Memory ====================1/3 Location #1 Location #2 Location #3 * The asterisk (*) icon on the screen indicates that there is a previous recording in the memory location. If you select a location marked with an asterisk (*) icon, a message prompting to overwrite old recording displays.
, OWNER S MANUAL CHECK If DTC Trigger is selected,following screen shows: DTC Trigger ======================= Waiting for DTC to trigger recording… Press [ESC] to exit 6) Wait for DTC to trigger recording or press ENTER to start recording. Drive till a DTC is detected when DTC Trigger is selected. If no DTCs are detected,press ESC to exit recording. Recording..... 5/60 ===================-=-= DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) 6 6 OL N/A 0.0 -40 0.0 The number "“x/x...
, OWNER S MANUAL CHECK If you wish to playback recorded data,press ENTER button; if you do not wish to playback, press ESC button, or use LEFT/ RIGHT button to select NO and press ENTER button to return to Record Data menu. Record Data ===================-=-= Complete Data Set Custom Data Set Unit of Measure Recording Custom Data Set 8) To record customized data, use UP/DOWN scroll button to select Custom Data Set from Record Data menu and press ENTER button.
, OWNER S MANUAL CHECK 10) Use RIGHT button select/deselect data parameters. Selected parameters are marked with solid squares. Press ENTER button to confirm. Custom Data Set ======================= DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) #01 #02 #03 You are allowed to pick up a maximum of 18 PIDs. If the selected PIDs exceed 18,a “"The selected data list is full!"” message displays on the screen. If you wish to deselect all marked items,press LEFT button.
, OWNER S MANUAL CHECK Pick Trigger Mode ====================1/2 Manual Trigger DTC Trigger If data from previously tested vehicle is not erased, data from current test will be stored in temporary cache.
, OWNER S MANUAL CHECK The asterisk (*) icon on the screen indicates that there is a previous recording in the memory location. If you select a location marked with an asterisk (*) icon, a message prompting to overwrite old recording is displayed.
, OWNER S MANUAL CHECK 14) Wait for DTC to trigger recording or press ENTER to start recording. Recording… 5/60… ===================-==6 DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) 6 OL N/A 0.0 -40 0.0 15) The scan tool keep recording PID data until user presses ESC button, the selected memory location is full, or it completes recording. A message prompting to playback data shows on the screen.
, OWNER S MANUAL CHECK 1) To playback recorded data, use UP/DOWN scroll button to select Playback Data from Live Data menu and press ENTER button. Live Data ====================3/3 View Data Record Data Playback Data You are also allowed to playback recorded data immediately after recording. 2) Use UP/DOWN button to select the memory location marked with an asterisk (*) icon.
, OWNER S MANUAL CHECK The number “"x/x"” to the upper rig ht corner of the screen indicates total number of recorded frames and sequence of frame being displayed. Negative frames indicate data recorded prior to trigger event; and positive frames indicate data recorded after trigger event. 4) Use LEFT/RIGHT button to view PIDs of next or previous frames. Playback … 6/16… ===================-=-4 DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) 6 OL N/A 0.0 -40 0.0 11.
, OWNER S MANUAL CHECK 3) If retrieved information covers more than one screen, then a down arrow will appear. Use DOWN scroll button, as necessary, until all the data have been shown up. View Freeze Frame… =====================2 DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) 1630 OL N/A 0.0 -40 0.0 If there is no freeze frame data available,an advisory message" No freeze frame data stored!”" shows on the display.
, OWNER S MANUAL CHECK tests: A. Since DTCs Cleared - indicates status of the monitors since the DTCs are erased. B. This Drive Cycle - indicates status of monitors since the beginning of the current drive cycle. An I/M Readiness Status result of "“NO”" does not necessarily indicate that the vehicle being tested will fail the state I/M inspection. For some states, one or more such monitors may be allowed to be "“Not Ready"” to pass the emissions inspection.
, OWNER S MANUAL CHECK 3) If the vehicle supports both types of tests,then both types will be shown on the screen for selection. I/M Readiness… ====================1/2 Since DTCs Cleared This Drive Cycle 4) Use UP/DOWN scroll button, as necessary, to view the status of the MIL lig ht (“"ON"” or "“OFF ") and the following monitors: Misfire monitor -- Misfire monitor Fuel System Mon -- Fuel System Monitor Comp.
, OWNER S MANUAL CHECK 5) If the vehicle supports readiness test of “This Drive Cycle”,a screen of the following displays: This Drive Cycle… ======================= MIL Status OFF Misfire Monitor Fuel System Mon Comp. Component Catalyst Mon Htd Catalyst OK OK OK INC N/A 6) Press ESC button to return to Diagnostic Menu. 11.
, OWNER S MANUAL CHECK 2) Wait a few seconds while the scan tool validates the PID MAP. O2 Monitor Test… ======================= Reading PID… - Please Wait - 3) Use UP/DOWN scroll button to select O2 sensor from O2 Monitor Test menu and press ENTER button. O2 Monitor Test… ====================2/2 O2 Bank1 Sensor1 O2 Bank1 Sensor2 If the vehicle does not support the mode, an advisory message will be displayed on the screen.
, OWNER S MANUAL CHECK 5) Use UP/DOWN scroll button to view more screens of data if an or icon displays. 6) Press ESC button to return to the previous menus. 11.7 On-Board Monitor Test The On-Board Monitor Test is useful after servicing or after erasing a vehicle’s control module memory. The On-Board Monitor Test for nonCAN-equi pped vehicles retrieves and displays test results for emissionrelated powertrain components and systems that are not continuously monitored.
, OWNER S MANUAL CHECK 3) From On-Board Mon. Test menu, use UP/DOWN scroll button to select a test to view and press ENTER button. On-Board Mon. Test … ==================-=1/3 Test $01 Data Test $05 Data Test $09 Data If the vehicle under test does not support the mode, an advisory message will be displayed on the screen. On-Board Mon. Test … ======================= The selected mode is not supported Press any key to con.
, OWNER S MANUAL CHECK Test $01… ======================= ID: MOD : MEAS: MAX : MIN : STS : 00 $11 0 0 -------OK For CAN-equi pped vehicles,test results displayed can be as below: 6) Press ESC button to return to the previous menus. 11.8 Component Test The Component Test function allows initiating a leak test for the vehicle's EVAP system. The scan tool itself does not perform the leak test, but commands the vehicle's on-board computer to start the test.
, OWNER S MANUAL CHECK Component Test … ======================= Reading PID… - Please Wait - 3) From Component Test menu, use UP/DOWN scroll button to select the test to be initiated. Component Test … ==================-=1/1 Evap Leak Test 4) If the test has been initiated by the vehicle,a confirmation message will be displayed on the screen. Working … ==================-=1/1 Command Sent! Press any key to con. Some vehicles do not allow scan tools to control vehicle systems or components.
, OWNER S MANUAL CHECK 5) Wait a few seconds or press any key to return to Diagnostic Menu. 11.9 Viewing Vehicle Information The Vehicle Info. function enables retrieval of Vehicle Identification No.(VIN),Calibration ID(s),Calibration Verification Nos. (CVNs) and In-use Performance Tracking on 2000 and newer vehicles that support Mode 9. 1) Use UP/DOWN scroll button to select Vehicle Info. from the Diagnostic Menu and press ENTER button. Diagnostic Menu… ===================-9/11 On-Board Mon.
, OWNER S MANUAL CHECK Vehicle Info. … ======================= Reading info… - Please Wait - If the vehicle does not support this mode,a message shows on the display warning that the mode is not supported. 4) From Vehicle Info. menu, use UP/DOWN scroll button to select an available item to view and press ENTER button. con. Vehicle Info. … ==================-=2/3 Vehicle ID Number Calibration ID Cal. Verif. Number 5) View retrieved vehicle information on screen. con.
, OWNER S MANUAL CHECK 1) Use UP/DOWN scroll button to select Modules Present from Diagnostic Menu and press ENTER button. con. Vehicle Info. … =================-=10/11 On-Board Mon. Test Component Test Vehicle Info. Modules Present Unit of Measure 2) View modules present with their IDs and communication protocols. con. Modules Present … ======================= ID Protocol _________________________ $11 ISO 9141-2 12.
, OWNER S MANUAL CHECK con. Main Menu ====================4/6 Diagnostics DTC Lookup Review Data Print Data System Setup Tool Information 6) Use UP/DOWN scroll button to select the desired item to print from Print Data menu. con. Print Data ====================1/9 Stored Codes Pending Codes Live Data Freeze Frame I/M Readiness O2 Sensor Test To print all retrieved data,UP/DOWN scroll button to select Print All Data from Print Data menu. con. Print Data ==================-=9/9 On-Board Mon.
, OWNER S MANUAL CHECK 13.Using the scan tool (Model RDT79) 13.1 Tool Description 9 1 4 2 8 6 ENTER ESC 5 7 3 1.LCD DISPLAY -- Indicates test results. Backlit,128 x 64 pixel display with contrast adjustment.
, OWNER S MANUAL CHECK 2.ENTER BUTTON -- Confirms a selection (or action) from a menu. Starts recording live data under manual trigger mode. 3.ESC BUTTON -- Cancels a selection (or action) from a menu or returns to the menu. It is also used to setup system, exit DTC Lookup screen,or stop data recording when pressed. 4.
CHECK , OWNER S MANUAL 13.3 Accessories Included 1). User’s Manual -- Instructions on tool operations 2). CD -- Includes user’s manual,DTC lookup software,and etc. 3). OBD2 cable -- Provides power to tool and communicates between tool and vehicle 4). USB cable -- Used to upgrade the scan tool, and to print retrieved data. 5). Carry case -- A nylon case to store the scan tool when not in use. 6). Cell battery (not provided) --Supplies power to the Scan tool when disconnected from vehicle DLC.
, OWNER S MANUAL CHECK A plastic DLC cover may be found for some vehicles and you need to remove it before plugging the OBD2 cable. 3). Plug OBD II cable to the vehicle's DLC. 13.7 DTC Lookup The DTC Lookup function is used to search for definitions of DTCs stored in built-in DTC library. 1). From Main Menu, use UP/DOWN scroll button to select DTC Lookup and press ENTER button.
, OWNER S MANUAL CHECK 4). To view next or previous DTC in the built-in DTC library,use UP/DOWN button. 5). To enter another DTC,press ESC button to return to previous screen. 6). To exit to Main Menu,press ESC button. 13.8 Product Setup The scan tool allows you to make the following adjustments and settings: 1). Language: Selects the desired language. 2). Contrast adjustment: Adjusts the contrast of the LCD display. 3). Unit of measure: Sets the unit of measure to English or Metric. 4).
, OWNER S MANUAL CHECK Language Setup English is the default language. 1). From System Setup menu, use UP/DOWN scroll button to select Language,and press ENTER button. System Setup ====================1/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2). Use UP/DOWN scroll button to select the desired language and press ENTER button to save your selection and return to previous menu.
, OWNER S MANUAL CHECK 3). Press ENTER button to save your settings and return to previous menu. Unit of Measurement Metric is the default measurement unit. 1). From System Setup menu, use UP/DOWN scroll button to select Unit of Measure and press ENTER button. System Setup ====================3/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2). From Unit of Measure menu, use UP/DOWN scroll button to select the desired unit of measurement.
, OWNER S MANUAL CHECK 2). From Auto Power-off menu,use UP/DOWN scroll button to increase or decrease time. Auto Power-off ======================= 01 Minute [ ] – Increase time [ ] – Decrease time [ENTER] - Confirm 3). Press ENTER button to save your setting and return to previous menu. Beep Set The default setting is Beep On. 1). From System Setup menu, use UP/DOWN scroll button to select Beep Set and press ENTER button.
, OWNER S MANUAL CHECK Tool Self-test The Tool Self-test function checks if the display and keyboard are working properly. A. Display test The Display Test function checks if the LCD display is working normally. 1). From System Setup menu, use UP/DOWN scroll button to select Tool Self-test,and press ENTER button. System Setup ====================6/6 Language Contrast Unit of Measure Auto Power-off Beep Set Tool Self-test 2). Select Display Test from Tool Self-test menu and press ENTER button.
, OWNER S MANUAL CHECK 2). Press any key to start test. When you press a key, the key name should be observed on the display. If the key name does not show up, then the key is not functioning properly. Keyboard Test ======================= Press any key to start test key: Double [ESC] to return If you press and hold the power switch,the key name does not show on the screen, but resets the scanner when powered by vehicle battery, or turns off the scanner when powered by cell battery.
CHECK , OWNER S MANUAL 13.10 Battery Replacement The scan tool requires a 9V cell battery to operate when disconnected from vehicle power. 1). Locate the battery cover on the back of the scan tool. 2). Remove the battery cover screw and slide the battery cover off. 3). Remove discharged batteries and install a new 9V cell battery. 4). Reinstall battery cover by sliding battery cover on and installing screw. 13.
, OWNER S MANUAL CHECK Press and hold POWER button for at least 2 seconds to reset the scan tool. Turn the ignition off and wait for about 10 seconds. Turn the ignition back to on and continue the testing. Scan tool doesn’t power up If the scan tool won’t power up or operates incorrectly in any other way, you need to do the following to check up: Check if the scan tool's OBD II connector is securely connected to the vehicle's DLC; Check if the DLC pins are bent or broken. Clean the DLC pins if necessary.
, OWNER S MANUAL CHECK $09 1/6 Generic P0118 ======================= Engine Coolant Temperature Sensor 1 Circuit Hig h If there is no data stored for selected item, a "Not Supported or Stored No Data!” message shows on the screen. If no data from previously tested vehicle is recorded, only Module Present data containing module ID and protocol type can be reviewed. Review Data ====================1/1 Modules Present 15.
, OWNER S MANUAL CHECK 6. Press ENTER button to confirm. A sequence of messages displaying the OBD2 protocols will be observed on the display until the vehicle protocol is detected. If the scan tool fails to communicate with the vehicle's ECU(Engine Control Unit), a "LINKING ERROR!" message shows up on the display.
, OWNER S MANUAL CHECK Control Module ====================1/2 Engine A/T Use UP/DOWN scroll button to select a module and press ENTER button. 15.1 Reading Codes Reading Codes can be done with the key on engine off (KOEO) or with the key on engine running (KOER). Stored Codes are also known as "hard codes"”or "permanent codes". These codes cause the control module to illuminate the malfunction indicator lamp (MIL) when emission-related fault occurs.
, OWNER S MANUAL CHECK Trouble Codes ====================1/3 Stored Codes Pending Codes Permanent Codes If there are no Diagnostic Trouble Codes present, the display indicates "No (pending) codes are stored in the module!" Wait a few seconds or press any key to return to Diagnostic Menu. Press Permanent Codes, the auto scanner will show all trouble code history, which happened into the vehicle ECU, even if these are erased already! 3). View DTCs and their definitions on screen.
, OWNER S MANUAL CHECK If the manufacturer for your vehicle is not listed,use UP/DOWN scroll button to select Other and press ENTER button. 15.2 Erasing Codes CAUTION: Erasing the Diagnostic Trouble Codes may allow the scan tool to delete not only the codes from the vehicle's on-board computer, but also Freeze Frame data and manufacturer specific enhanced data. Further,the I/M Readiness Monitor Status for all vehicle monitors is reset to Not Ready or Not Complete status.
, OWNER S MANUAL CHECK Erase Codes ======================= Erase Done! Press any key to con. If the codes are not cleared, then an Erase Failure. Turn Key on with Engine off! message appears. Erase Codes ======================= Erase Failure. Turn Key on with Engine Off! Press any key to con. 4). Press any button to return to Diagnostic Menu. 15.3 Live Data Viewing Data The View Data function allows viewing of live or real time PID data of vehicle’s computer module(s).
, OWNER S MANUAL CHECK 2).Wait a few seconds while the scan tool validates the PID MAP. Live Data ======================= Reading PID.01 - Please Wait - 3). Use UP/DOWN scroll button to select View Data from Live Data menu and press ENTER button. LiveData ====================1/3 View Data Record Data Playback Data Viewing Complete Data Set 4). To view complete set of data, use UP/DOWN scroll button to select Complete Data Set from View Data menu and press ENTER button.
, OWNER S MANUAL CHECK The number "x" to the rig ht of the screen indicates sequence of hig hlig hted item. If the "G" icon appears when a PID is hig hlig hted, it indicates graphic information is available. Press ENTER to view graph. RPM (/min) 975 1725 925 6). Press ESC button to return to previous menu. Viewing Custom Data Set 7). To view customized PID data, use UP/DOWN scroll button to select Custom Data Set from View Data menu and press ENTER button.
, OWNER S MANUAL CHECK Custom Data Set ===================-==6 DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) #01 #02 #03 The number "x" to the upper rig ht corner of the screen indicates sequence of hig hlig hted item; and "#x" are the order that the parameters are selected and will be displayed. You are allowed to pick up a maximum of 18 PIDs. If the selected PIDs exceed 18, a The selected data list is full!”message displays on the screen.
, OWNER S MANUAL CHECK Recording Data The Record Data function allows recording vehicle modules Parameter Identification (PID) data to help diagnose intermittent vehicle problems. A recording includes 5 frames of live data before trigger event and several frames after trigger event. There are two trigger modes used to record data: A. Manual Trigger - allows user to press ENTER button to start recording. B.
, OWNER S MANUAL CHECK If data from previously tested vehicle is not erased, data from current test will be stored in a temporary cache. Following screen shows when Manual Trigger is selected: Manual Trigger ======================= Ready to record! Press [ENTER] to start recording… Press [ESC] to exit Or following screen shows when DTC Trigger is selected: DTC Trigger ======================= Waiting for DTC to trigger recording… Press [ESC] to exit 4).
, OWNER S MANUAL CHECK If you wish to proceed with overwriting the old recording, press ENTER button; if you do not wish to overwrite it, use LEFT/RIGHT button to select NO or press ESC button to pick another memory location. 5). Observe on-screen instructions.
, OWNER S MANUAL CHECK 7). The scan tool keeps recording PID data until user presses ESC button, selected memory location is full,or it completes recording. A message prompting to playback data shows on the screen. Record Data ======================= Record Done! Playback data? YES NO If you wish to playback recorded data,press ENTER button; if you do not wish to playback, press ESC button, or use LEFT/RIGHT button to select NO and press ENTER button to return to Record Data menu.
, OWNER S MANUAL CHECK 10). Use RIGHT button select/deselect data parameters. Selected parameters are marked with solid squares. Press ENTER button to confirm. Custom Data Set ======================= DTC_CNT FUELSYS1 FUELSYS2 LOAD_PCT(%) ETC( C ) SHRTFT1(%) #01 #02 #03 You are allowed to pick up a maximum of 18 PIDs. If the selected PIDs exceed 18, a "The selected data list is full!" message displays on the screen. If you wish to deselect all marked items,press LEFT button.
, OWNER S MANUAL CHECK Pick Trigger Mode ====================1/2 Manual Trigger DTC Trigger If data from previously tested vehicle is not erased, data from current test will be stored in temporary cache.
, OWNER S MANUAL CHECK Select Memory ======================= A previous recording exists! Do you want to overwrite it? YES NO If you do not wish to proceed with overwriting old recording,press ENTER button; if you do not wish to overwrite it, press ESC button, or use LEFT/ RIGHT button to select NO and press ENTER to pick another memory location. 13) Observe on-screen instructions.
, OWNER S MANUAL CHECK 15).The scan tool keep recording PID data until user presses ESC button, the selected memory location is full, or it completes recording. A message prompting to playback data shows on the screen. Record Data… ======================= Record Done! Playback data? YES NO If you wish to playback recorded data,press ENTER button; if you do not wish to playback, press ECS button, or use LEFT/RIGHT button to select NO and press ENTER button to return to Record Data menu.
, OWNER S MANUAL CHECK 2). Use UP/DOWN button to select the memory location marked with an asterisk (*) icon. Select Memory ====================3/3 Location #1 Location #2 Location #3 * * If there is no recording in selected location, a message "Not Supported or Stored No Data" displays on the screen. For data stored in temporary cache, you do not have to select memory location. 3). Use UP/DOWN button to view recorded PIDs of each frame.
, OWNER S MANUAL CHECK 15.4 Viewing Freeze Frame Data 1). To view freeze frame data, use UP/DOWN scroll button to select View Freeze Frame from Diagnostic Menu and press ENTER button. Diagnostic Menu… ===================4/11 Read Codes Erase Codes Live Data View Freeze Frame I/M Readiness O2 Monitor Test 2). Wait a few seconds while the scan tool validates the PID MAP. View Freeze Frame… ======================= Reading PID.01 - Please Wait - 3).
, OWNER S MANUAL CHECK 15.5 Retrieving I/M Readiness Status I/M Readiness function is used to check the operations of the Emission System on OBD2 compliant vehicles. It is an excellent function to use prior to having a vehicle inspected for compliance to a state emissions program. Some latest vehicle models may support two types of I/M Readiness tests: A. Since DTCs Cleared - indicates status of the monitors since the DTCs are erased. B.
, OWNER S MANUAL CHECK Current Readiness: Views the status of 11 sensors/moinots at present I/M readiness 1). Choose Current Readiness and press Enter button. 2). Wait a few seconds while the scan tool validates the PID MAP. Current Readiness… ======================= Reading PID… - Please Wait - 3). If the vehicle supports both types of tests,then both types will be shown on the screen for selection. Currrent Readiness… ====================1/2 Since DTCs Cleared This Drive Cycle 4).
, OWNER S MANUAL CHECK 5). If the vehicle supports readiness test of “This Drive Cycle. a screen of the following displays: This Drive Cycle… ======================= MIL Status OFF Misfire Monitor Fuel System Mon Comp. Component Catalyst Mon Htd Catalyst OK OK OK INC N/A 6).Press ESC button to return to Diagnostic Menu. Stored Readiness: Views the status of 11 sensors/monitors stored in the Freeze Frame Data.
, OWNER S MANUAL CHECK FUELSYS1… ===================== Fuel System 1 Status Press any key to con. 6).Press ESC button to return to Diagnostic Menu. 15.6 O2 Monitor Test OBD2 regulations set by SAE require that relevant vehicles monitor and test the oxygen (O2) sensors to identify problems related to fuel efficiency and vehicle emissions. These tests are not on-demand tests and they are done automatically when engine operating conditions are within specified limits.
, OWNER S MANUAL CHECK 3). Use UP/DOWN scroll button to select O2 sensor from O2 Monitor Test menu and press ENTER button. O2 Monitor Test… ====================2/2 O2 Bank1 Sensor1 O2 Bank1 Sensor2 If the vehicle does not support the mode, an advisory message will be displayed on the screen. O2 Monitor Test… ======================= The selected mode is not supported Press any key to con. 4). View test results of selected O2 sensor.
, OWNER S MANUAL CHECK powertrain components and systems that are not continuously monitored. The On-Board Monitor Test for CAN-equi pped vehicles retrieves and displays test results for emission-related powertrain components and systems that are and are not continuously monitored.Test and components IDs are determined by the vehicle manufacturer. 1). Use UP/DOWN scroll button to select On-Board Mon. Test from Diagnostic Menu and press ENTER button. Diagnostic Menu… ====================7/11 On-Board Mon.
, OWNER S MANUAL CHECK On-Board Mon. Test … ======================= The selected mode is not supported Press any key to con. For CAN-equi pped vehicles,test selections can be as below: On-Board Mon … ======================= O2 Mon. B1S1 O2 Mon. B1S2 Catalyst Mon. B1 EGR Mon. Bank1 4). Use UP/DOWN scroll button to select the desired monitor from OnBoard Mon. Test menu and press ENTER button. 5). View test data on screen.
, OWNER S MANUAL CHECK 1). Use UP/DOWN scroll button to select Component Test from Diagnostic Menu and press ENTER button. Diagnostic Menu… ==================-=8/11 On-Board Mon. Test Component Test Vehicle Info. Modules Present Unit of Measure 2). Wait a few seconds while the scan tool validates the PID MAP. Component Test … ======================= Reading PID… - Please Wait - 3). From Component Test menu, use UP/DOWN scroll button to select the test to be initiated.
, OWNER S MANUAL CHECK Some vehicles do not allow scan tools to control vehicle systems or components. If the vehicle under test does not support the EVAP Leak Test,an advisory message is displayed on the screen. Component Test… ======================= The selected mode is not supported Press any key to con. 5). Wait a few seconds or press any key to return to Diagnostic Menu. 15.9 Viewing Vehicle Information The Vehicle Info. function enables retrieval of Vehicle Identification No.
, OWNER S MANUAL CHECK Vehicle Info. … ======================= Reading info… - Please Wait - If the vehicle does not support this mode,a message shows on the display warning that the mode is not supported. 4). From Vehicle Info. menu, use UP/DOWN scroll button to select an available item to view and press ENTER button. con. Vehicle Info. … ==================-=2/5 Vehicle ID Number Calibration ID Cal. Verif. Number In-use Perform Track ECU Name 5). View retrieved vehicle information on screen.
, OWNER S MANUAL CHECK con. ECU Name… ======================= ECU1: ECM1-ECU-BASF45464FEFEFEF ECU2: ECM2-ECU-BAVD45464FEFEF34E 6). Press ESC button to return previous menu 15.10 Modules Present The Modules Present function allows viewing of the module IDs and communication protocols for OBD2 modules in the vehicle. 1). Use UP/DOWN scroll button to select Modules Present from Diagnostic Menu and press ENTER button. con. Vehicle Info. … =================-=10/11 On-Board Mon.
, OWNER S MANUAL CHECK 1). Place included CD into CD-Drive.or download applications from our distributions. 2). Follow onscreen instructions on your computer to install applications. 3). Launch printing application software from the CD. 4). Connect the scanner to computer with the USB cable supplied. 5). Use UPLDOWN scrou button to select Print Data from MainMenu and press Enter button. con. Main Menu ====================4/6 Diagnostics DTC Lookup Review Data Print Data System Setup Tool Information 6).
, OWNER S MANUAL CHECK 17. Appendix 17.
, OWNER S MANUAL CHECK PID Abbreviation Full Name IAT(°F) IAT(°C) MAF(g/s) MAF(lb/min) TP (%) AIR_STAT O2SLOC O2B1S1(V) SHRTFTB1S1 (%) O2B1S2(V) SHRTFTB1S2 (%) O2B1S3(V) SHRTFTB1S3 (%) O2B1S4(V) Intake Air Temperature Intake Air Temperature Mass Air Flow Sensor Mass Air Flow Sensor Absolute Throttle Position Commanded Secondary Air Status Location of O2 Sensors O2 Sensor Output Voltage(B1S1) Short Term Fuel Trim(B1S1) O2 Sensor Output Voltage(B1S2) Short Term Fuel Trim(B1S2
, OWNER S MANUAL 172 CHECK PID Abbreviation Full Name SHRTFTB2S1 (%) O2B2S2(V) SHRTFTB2S2 (%) O2B3S1(V) SHRTFTB3S1 (%) O2B3S2(V) SHRTFTB3S2 (%) O2B4S1(V) SHRTFTB4S1 (%) O2B4S2(V) SHRTFTB4S2 (%) OBDSUP O2SLOC RUNTM(sec) MIL_DIST(km) MIL_DIST(mile) FRP(kPa) FRP(PSI) FRP(kPa) FRP(PSI) EQ_RATB1S1 O2B1S1(V) EQ_RATB1S2 O2B1S2(V) EQ_RATB1S3 O2B1S3(V) EQ_RATB1S4 O2B1S4(V) Short Term Fuel Trim(B2S1) O2 Sensor Output Voltage(B2S2) Short Term Fuel Trim(B2S2)
, OWNER S MANUAL CHECK PID Abbreviation Full Name EQ_RATB2S1 O2B2S1(V) EQ_RATB2S2 O2B2S2(V) EQ_RATB2S3 O2B2S3(V) EQ_RATB2S4 O2B2S4(V) EQ_RATB1S1 O2B1S1(V) EQ_RATB1S2 O2B1S2(V) EQ_RATB2S1 O2B2S1(V) EQ_RATB2S2 O2B2S2(V) EQ_RATB3S1 O2B3S1(V) EQ_RATB3S2 O2B3S2(V) EQ_RATB4S1 O2B4S1(V) EQ_RATB4S2 O2B4S2(V) EGR_PTC (%) EGR_ERR (%) EVAP_PCT (%) FLI (%) Equivalence Ratio(wide range O2S)(B2S1) O2 Sensor Voltage(wide range O2S)(B2S1) Equivalence Ratio(wide
, OWNER S MANUAL 174 CHECK PID Abbreviation Full Name WARM_UPS CLR_DIST(km) CLR_DIST(mile) EVAP_VP(Pa) EVAP_VP(inH2O) BARO(kPa) BARO(inHg) EQ_RAT11 O2S11(mA) EQ_RAT12 O2S12(mA) EQ_RAT13 O2S13(mA) EQ_RAT14 O2S14(mA) EQ_RAT21 O2S21(mA) EQ_RAT22 O2S22(mA) EQ_RAT23 O2S23(mA) EQ_RAT24 O2S24(mA) Number of Warm-ups Since DTC Cleared Distance Since DTC Cleared Distance Since DTC Cleared Evap System Vapor Pressure Evap System Vapor Pressure Barometric Pressure Bar
, OWNER S MANUAL CHECK PID Abbreviation Full Name O2S21(mA) EQ_RAT22 O2S22(mA) EQ_RAT31 O2S31(mA) EQ_RAT32 O2S32(mA) EQ_RAT41 O2S41(mA) EQ_RAT42 O2S42(mA) CATEMP11(°F) CATEMP11(°C) CATEMP21(°F) CATEMP21(°C) CATEMP12(°F) CATEMP12(°C) CATEMP22(°F) CATEMP22(°C) VPWR(V) LOAD_ABS (%) EQ_RAT TP_R (%) AAT(°F) AAT(°C) TP_B (%) TP_C (%) O2 Sensor Current(wide range O2S)(B2S1) Equivalence Ratio(wide range O2S)(B2S2) O2 Sensor Current(wide range O2S)(B2S2)
, OWNER S MANUAL 176 CHECK PID Abbreviation Full Name APP_D (%) APP_E (%) APP_F (%) TAC_PCT (%) MIL_TIME CLR_TIME Accelerator Pedal Position D Accelerator Pedal Position E Accelerator Pedal Position F Commanded Throttle Actuator Control Minute run by Engine While MIL activated Time since Diagnostic Trouble Code Clear OBD2 Car Scanner
CHECK , OWNER S MANUAL 17.
, OWNER S MANUAL Abbreviatio Full Name O2SCOMP1 O2 Sensor Monitor Completion Counts Bank 1 O2SCOND1 O2 Sensor Monitor Conditions Encountered Counts Bank 1 O2SCOMP2 O2SCOND2 178 O2 Sensor Monitor Completion Counts Bank 2 O2 Sensor Monitor Conditions Encountered Counts Bank 2 CHECK Definitions O2 Sensor Monitor Completion Counts Bank 1 displays number of time that all conditions necessary to detect an oxygen sensor bank 1 malfunction have been encountered (numerator).
CHECK Abbreviatio Full Name , OWNER S MANUAL Definitions AIR Monitor Conditions Encountered Counts (Secondary Air) AIR Monitor Conditions Encountered Counts (Secondary Air) displays number of times that the vehicle has been operated in the specified AIR system monitoring conditions (denominator). EVAPCOMP EVAP Monitor Completion Condition Counts EVAP Monitor Completion Condition Counts displays number of time that all conditions necessary to detect a 0.
, OWNER S MANUAL CHECK 18. Warranty and Service 18.1 Limited One Year Warranty We warrants to its customers that this product will be free from all defects in materials and workmanshi p for a period of one (1) year from the date of the original purchase, subject to the following terms and conditions: 1). The sole responsibility of us under the warranty is limited to either the repair or, at the option of us, replacement of the scan tool at no charge with proof of purchase.
www.roadico.
