Live Data
===================-2/3
11) Use
ESC
button to return to
View Data
menu and/or return to
Live
Data
menu.
Recording Data
The Record Data function allows recording vehicle modules’ Parameter
Identification (PID) data to help diagnose intermittent vehicle problems. A
recording includes 5 frames of live data before trigger event and several
frames after trigger event.
There are two trigger modes used to record data:
A.
Manual Trigger
- allows user to press
ENTER
button to start
recording.
B.
DTC Trigger
- automatically records PID data when a fault that
causes a DTC to set is detected by vehicle.
CAUTION: Do not try to drive and operate the scan tool at the same time!
Always have another person operate the scan tool while driving.
1) To record live data, use
UP/DOWN
scroll button to select
Record
Data
from
Live Data
menu and press
ENTER
button.
Recording Complete Data Set
2) To record complete set of live data, use
UP/DOWN
scroll button to
select Complete Data Set from Record Data menu and press
ENTER
button.
View Data
Record Data
Playback Data
