4). External Power: 8.0 to 18.0 V power provided via vehicle battery
5). Internal Power: 9V cell battery
6). Dimensions:
Length Width Heig ht
209 mm (7.00”) 107 mm (3.74”) 37 mm (1.38”)
7). NW: 0.76kg (0.84lb), GW: 0.98 kg(1.21lb
6.3 Accessories Included
1). User's Manual -- Instructions on tool operations.
2). CD -- Includes user’s manual, DTC lookup software, and etc.
3). OBD2 cable -- Provides power to tool and communicates between
tool and vehicle.
4). USB/Serial cable -- Used to upgrade the scan tool.
5). Carry case -- A nylon case to store the scan tool when not in use.
6)Cell battery (not provided) - Supplies power to the Scan tool when
disconnected from vehicle DLC. Or you can use the USB cable to connect
to the PC to supply power.
6.4 Navigation Characters
Characters used to help navigate the scan tool are:
1). " " -- Indicates current selection.
2). " "--
A"DOWN" Arrow
indicates additional information is available on
next screens.
3). " "--
An "UP" Arrow
indicates additional information is available on
previous screens.
4). "$" -- Identifies the control module number from which data is retrieved.
5). "G" -- Indicates graphic viewing is available.
6.5 Keyboard
No solvents such as alcohol are allowed to clean the keypad or display.
Use a mild nonabrasive detergent and a soft cotton cloth. Do not soak the
keypad as the keypad is not waterproof.
