User Manual

OWNER S MANUAL
,
OBD2 Car Scanner
48
CHECK
Control Module
==========================1/2
Engine
Module $A4
Diagnostic Menu
==========================1/11
Use
UP/DOWN
scroll button to select a module and press
ENTER
button.
8.1 Reading Codes
Reading Codes can be done with the key on engine off (KOEO) or with
the key on engine running (KOER).
Stored Codes are also known as hard codes”or permanent codes”.
These codes cause the control module to illuminate the malfunction
indicator lamp (MIL) when emission-related fault occurs.
Pending Codes are also referred to as“maturing codes or continuous
monitor codes. They indicate problems that the control module has
detected during the current or last driving cycle but are not considered
serious yet. Pending Codes will not turn on the malfunction indicator lamp
(MIL). If the fault does not occur within a certain number of warm-up
cycles, the code clears from memory.
1). Use
UP/DOWN
scroll button to select
Read Codes
from
Diagnostic Menu
and press
ENTER
button.
2). Use
UP/DOWN
scroll button to select
Stored Codes
or
Pending
Codes
from the
Trouble Codes
menu and press
ENTER
button.
Read Codes
Erase Codes
Live Data
View Freeze Frame
I/M Readiness
O2 Monitor Test
