Specifications

USA/Cananda: 1.800.877.2376
www.robern.com
Electric Option Models are ETL certified to:
UL 962
CSA Standard C22.2 No. 68
Features
Construction
Options
Dimensions
Codes/Standards Applicable
•
Model Number Key
Hinge Side
L = Left
R = Right
Cabinet
C
M Series
M
Ganging Cabinet-to-Cabinet Arrangement
Ganging Cabinet-to-Lights Arrangement
Installation Options
MC2430D6 Cabinet - Specification Sheet
Page 1 of 2
229-1016_rA_081915
Depth
D6
• Modular Cabinet - build arrays with lighting and cabinets to suit
• Quiet close Safeseal® Gasket
• Mirrored interior with 3 adjustable glass shelves
• Includes magnetic tool holder, razor/phone holder and 3 tier tray
• Includes installation hardware for recess mounting
• Can be recessed, semi-recessed (kit required) or surface mounted (kit required)
• Left or Right hand hinged
• Plain or Beveled front mirror
• Flat or Arched top mirror
• Decorative or Digital Wood Glass
• E2 Electric includes USB, 120VAC outlet and Lighted Interior
• E4 Electric includes USB, 120VAC outlet and Lighted Interior, Door
Defogger and Nightlight
• Other widths / heights / depths available
Door Style
FP = Flat, Plain
FB = Flat, Beveled
AP = Arched, Plain
AB = Arched, Beveled
## = Decorative Glass Option
Height
30"
Width
24"
Options
Blank = Non Electric
E2 = Electric and Interior Light
E4 = Electric, Interior Light, Defogger and Night Light
TV = TViD
Satin anodized aluminum body and door frame
3 mirror design – rear of cabinet and both sides of door
Blum 170° self-closing hinges
Safeseal® Gasket with sealed corners on cabinet body
Adjustable shelving at 2" (5.1 cm) increments
Clip-on accessories & magnet area provided with cabinet
USB charging port
Electric Option Cabinet:
Standard knock out for ½" (1.3 cm) cable connector
Wired internally - Front access serviceability
Sensor controlled LED Lit Shelf
•
•
•
•
•
•
•
•
(E4 Option Shown)
Height: 30" (76.2 cm)
Width: 23-1/4" (59.1 cm)
Depth: 6-5/8" (16.8 cm) Surface, 7/8" (2.3 cm) Project from wall when
recessed, and 3” (7.6 cm) Project from wall when Semi-Recessed
Recessed Mount - Rough Opening - 29-1/4" H x 22-1/2" W x 6" D
(74.3 cm H x 57.2 cm W x 15.2 cm D)
Semi-Recessed Mount - Rough Opening - 29-1/4" H x 22-1/2" W x 4" D
(74.3 cm H x 57.2 cm W x 10.2 cm D) Reference Surface Mount Kit when ordering
MSMK30D6SRP – Plain Mirror Kit
MSMK30D6SR## – Decorative Kit
Surface Mount - Reference Surface Mount Kit when ordering
MSMK30D6P – Plain Mirror Kit
MSMK30D6## – Decorative Kit
Gangs to M Series Cabinet - Reference M Ganging Kit when
ordering - MGKIT
Gangs to M Series Lighting - Reference Ganging kit for the particular
light option when ordering
