(2)

Conversion Compatibility

and Product I.D. Label

25-Pin Connector for cable 1492-CONACAB005_

1492-CM1771-LA004 Conversion Module

I. Description (Cont’d)

Conversion Compatibility

and Product I.D. Label

37-Pin Connector for cable

1492-CONACAB005

T_

Cable

1492-CONACAB

005T_

Conversion

Compatibility and

Product I.D. Label

25-Pin Connector

for cable

1492-C005005XT

PN-114290

DIR 10000060101 (Version 01)

Publication 1492-IN048B-EN-E
