Chapter 1
Overview
1–3
Compatible
Adapters
Catalog
Number
Device
Extended
Node
Capability
Comments
1785-LT/x PLC-5/15 Yes In adapter mode
1785-LT2 PLC-5/25 Yes In adapter mode
1785-LT3 PLC-5/12 Yes In adapter mode
1785-L30x PLC-5/30 Yes In adapter mode
1785-L40x PLC-5/40 Yes In adapter mode
1785-L60x PLC-5/60 Yes In adapter mode
1771-ASC Remote I/O Adapter Module No
1771-ASB Remote I/O Adapter Module
Series B and
C only
Series A, B, and C
1771-AM1
1-Slot I/O Chassis with Integral
Power Supply and Adapter
Yes
1771-AM2
2-Slot I/O Chassis with Integral
Power Supply and Adapter
Yes
1784-F30D
Plant Floor Terminal Remote I/O
Expansion Module
Yes
1771-RIO Remote I/O Interface Module No
1771-JAB Single Point I/O Adapter Module Yes
1771-DCM Direct Communication Module No
1778-ASB Remote I/O Adapter Module Yes
1747-ASB Remote I/O Adapter Module Yes
2706-xxxx
DL40 Datalinert
Yes
Must be catalog number
2706-ExxxxxB1.
2705-xxx
RediPANELt
Yes
2711-xx PanelView Terminal Yes
1336-RIO
Remote I/O Adapter for 1336 AC
Industrial Drives
Yes
1395-NA
Remote I/O Adapter for 1395 DC
Industrial Drives
Yes
1747-ASB
SLC 500 Remote I/O Adapter
Module
Yes
