Chapter 4
Module Configuration
4–4
Use this table to set SW1 – switches 1 through 6.
Logical Rack Number (Octal) Switch Number (SW1)
1747-
SN
PLC-
2
PLC-
3
PLC-
5/15
PLC-
5/25
PLC-
5/40
PLC-
5/60
PLC-
5/250
1 2 3 4 5 6
0 1 0 – – – – 0 ON ON ON ON ON ON
1 2 1 1 1 1 1 1 ON ON ON ON ON OFF
2 3 2 2 2 2 2 2 ON ON ON ON OFF ON
3 4 3 3 3 3 3 3 ON ON ON ON OFF OFF
5 4 4 4 4 4 ON ON ON OFF ON ON
6 5 5 5 5 5 ON ON ON OFF ON OFF
7 6 6 6 6 6 ON ON ON OFF OFF ON
7 7 7 7 7 ON ON ON OFF OFF OFF
10 10 10 10 ON ON OFF ON ON ON
11 11 11 11 ON ON OFF ON ON OFF
12 12 12 12 ON ON OFF ON OFF ON
13 13 13 13 ON ON OFF ON OFF OFF
14 14 14 14 ON ON OFF OFF ON ON
15 15 15 15 ON ON OFF OFF ON OFF
16 16 16 16 ON ON OFF OFF OFF ON
17 17 17 17 ON ON OFF OFF OFF OFF
20 20 20 ON OFF ON ON ON ON
21 21 21 ON OFF ON ON ON OFF
22 22 22 ON OFF ON ON OFF ON
23 23 23 ON OFF ON ON OFF OFF
24 24 24 ON OFF ON OFF ON ON
25 25 25 ON OFF ON OFF ON OFF
26 26 26 ON OFF ON OFF OFF ON
27 27 27 ON OFF ON OFF OFF OFF
30 30 ON OFF OFF ON ON ON
31 31 ON OFF OFF ON ON OFF
32 32 ON OFF OFF ON OFF ON
33 33 ON OFF OFF ON OFF OFF
34 34 ON OFF OFF OFF ON ON
35 35 ON OFF OFF OFF ON OFF
36 36 ON OFF OFF OFF OFF ON
37 37 ON OFF OFF OFF OFF OFF
40 OFF ON ON ON ON ON
41 OFF ON ON ON ON OFF
42 OFF ON ON ON OFF ON
43 OFF ON ON ON OFF OFF
44 OFF ON ON OFF ON ON
Continued on next page.
