Chapter 8
Application Examples
8–5
DIP Switch Settings
Switch 1 Switch 2
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
ON X X X X X X X X X X X
OFF X X X
= Not used
System Configuration
Amount Device Catalog Number
1 Power Supply 1746-P2
1 SLC 5/01 Processor 1747-L511
1 7-Slot Rack 1746-A7
2 Analog Input, 4 point 1746-NI4
2 Analog Output, 4 point 1746-NO4I
1 DCM 1747-DCM
Image Table Configuration
Output Image
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
O:1.0 Status Word to PLC-5 from SLC
O:1.1 Counter ACC word denotes module being read
O:1.2 Word 0 of analog module being read
O:1.3 Word 1 of analog module being read
DCM
O:1.4
Word 2 of analog module being read
O:1.5 Word 3 of analog module being read
O:1.6 Counter ACC word denotes module being read
O:1.7 Not used
O:4.0 NO4I word 0
O
O:4.1 NO4I word 1
N
O
4I
O:4.2
NO4I word 2
O:4.3 NO4I word 3
O:5.0 NO4I word 0
O
O:5.1 NO4I word 1
N
O
4I
O:5.2
NO4I word 2
O:5.3 NO4I word 3
