Chapter 8
Application Examples
8–8
RUNG
2.4
EQU
EQUAL
Source A C5:0.ACC
0
Source B 4
MOV
MOVE
Source C5:0.ACC
0
Dest 0:1.1
0
COP
COPY FILE
Source #I:4.0
Dest #0:1.2
Length 4
MOV
MOVE
Source C5:0.ACC
0
Dest 0:1.6
0
Module Number Monitored = 4
RUNG
2.5
EQU
EQUAL
Source A C5:0.ACC
0
Source B 5
MOV
MOVE
Source C5:0.ACC
0
Dest 0:1.1
0
COP
COPY FILE
Source #I:5.0
Dest #0:1.2
Length 4
MOV
MOVE
Source C5:0.ACC
0
Dest 0:1.6
0
<END>
Module Number Monitored = 5
