SLC 500 Data Files and Logical Addressing B-9
Publication 1747-6.1
Data File 7- Integer
These are 1-word elements, addressable at the element and bit level.
The Data Table Access Module cannot access Integer words to the bit
level.
Assign integer addresses as follows:
Format Explanation
Nf:e
N Integer
f File number.
Number 7 is the default file. A file
number between 10-255 can be used if
additional storage is required.
: Element delimiter
e
Element
number
Ranges from 0 to 255. These are 1-word
elements. 16 bits per element.
/ Bit delimiter
b Bit number
Bit location within the element. Ranges
from 0 to 15.
Examples: N7:2
N7:2/8
N10:36
Element 2, integer file 7.
Bit 8 in element 2, integer file 7.
Element 36, integer file 10 (file designated as an integer file
by the user)
15 14 13121110987654
0
0
1
2
253
254
255
Element321
Integer File
