Appendix
D
Mounting Template
We have provided the following full-size template for your
convenience in mounting the Data Table Access Module.
Using the Template
Before you use this template, read the installation recommendations
on page 2-1.
104.8 mm
(4.125 in.)
95.76 mm
(3.77 in.)
3.86 mm dia.
(0.152 in.)
4 holes
Scrape paint
to ensure
good ground.
114.3 mm
(4.5 in.)
128.5 mm
(5.06 in.)
Scrape paint
to ensure
good ground.
