3-2 Module Setup Procedure
Publication 1747-6.1
Factory Default
Settings
The module is shipped from the factory with the following default
settings:
Key Explanation
: Data File Addressing Element Delimiter
. Data File Addressing Word Delimiter
/ Data File Addressing Bit Delimiter
PRE Timer/Counter Preset Word
ACC Timer/Counter Accumulator Word
LEN Control Register File Length Word
POS Control Register Pointer Position Word
+/- Positive/Negative Signed Integer
NEXT Increment to Next Logical Address
PREV Decrement to Previous Logical Address
INC Increment Data Value or Control Bit
DEC Decrement Data Value or Control Bit
F( ) Function Key
ESC Escape Key
SHIFT Shift to Upper Case
ENTER Enter Desired Parameter
Feature Default Setting
Language English
DTAM Node Address 0
Baud Rate 19200
Auto Attach Off
LCD Backlighting On
Monitor Override Off
