3-4 Module Setup Procedure

Publication 1747-6.1

Selecting the

Language

You can configure the module to display all prompts and data in one

of six languages. The available languages are: English, Spanish,

Japanese, Italian, German and French. The default language

displayed is English:

• To change the language displayed:

Press

• To accept the displayed language:

Press

Once you have selected a language, the module immediately begins to

displayinthatlanguage.

Selecting the Node

Address

The node address is the communications identifier on the DH485

network for this module. Valid node addresses range from 0 through

31. The default node address displayed is 0.

• To change the node address:

Press [

]or[ ].

• To accept the displayed address:

Press

Select Language

ENGLISH

Important: Care must be taken when selecting a node address. Do

not duplicate the address of a processor or another

device on the DH485 network.

Select DTAM Addr
