3-6 Module Setup Procedure

Publication 1747-6.1

Backlighting the LCD

This selection controls the illumination for the LCD. The default

selection is On:

• To toggle between On and Off:

Press [

]or[ ].

• To accept the setting:

Press [

Setting the Monitor

Override Function

The Monitor Override feature allows you to write to selected data file

addresses while in the Monitor mode. Refer to chapter 5, Monitoring

and Modifying Data and chapter 6, Quick Recall Functions.The

default selection is Off:

• To toggle between On and Off:

Press [

]or[ ].

• To accept the setting:

Press [ ].

Set Backlighting

Monitor Override

OFF
