5-10 Monitoring and Modifying Data
Publication 1747-6.1
How to Display Different Word Addresses Within
Elements
When a Timer, Counter and Control address is displayed, the [ ]
and [
]keysworkasfollows:
1. To view the three words of counter C5:3, display the address as
described in the previous section. The display shows the most
significant bit of the control word:
Press [
].
2. The display shows the Preset word and the value stored there:
Press [ ].
3. The display shows the Accumulator word and its associated
value:
Press [
].
4. The display shows the Control word of the next highest Counter
in the file:
The [ ] key works in the same fashion.
The [ ]and[ ] keys can be used to display all valid addresses
contained within a data file. The keys do not allow you to cross file
boundaries. If the [ ] key is pressed when the highest address
within a file is displayed, the display rolls over to the lowest address
in that file. If the [
] key is pressed with the first address of a file
displayed, the display shows the highest address in that file.
C5:3.0/15
CU = 0
C5:3.PRE
500
C5:3.ACC
0
C5:4.0/15
CU =0
